StarTech.com · MDP2DPMF6IN

StarTech MDP2DPMF6IN 15cm Mini DisplayPort to DisplayPort Adapter

15cm Mini DisplayPort to DisplayPort Adapter designed for professional IT, electronics, security or workstation use.

Quick answer: MDP2DPMF6IN adds a standard DisplayPort connection to a Mini DisplayPort-equipped computer using a short flexible lead.

Best forConnecting an existing full-size DisplayPort cable or display to a laptop, workstation or compatible Thunderbolt video source.

Check before orderingThis is a Mini DisplayPort male to DisplayPort female adapter; a separate DisplayPort cable is required for most display connections.

Answers before you buy

Frequently asked questions

What is StarTech MDP2DPMF6IN?

It is a Mini DisplayPort male to full-size DisplayPort female video adapter that adds a standard DisplayPort connection to a Mini DisplayPort-equipped computer using a short flexible lead.

Which connections or mounting method are provided?

Mini DisplayPort 20-pin male to DisplayPort 20-pin female

What performance is specified?

DisplayPort 1.2 overview support including 4K 60Hz, HBR2, MST and multi-channel audio with compatible equipment

How is the product constructed?

Black 152.4mm 32AWG PVC adapter with gold-plated straight connectors and strain relief

How long is the attached cable?

The attached cable is 152.4mm, or 6 inches, long.

Is the DisplayPort end male or female?

The full-size DisplayPort end is female for connection to a separate DisplayPort cable.

What should be checked before ordering?

This is a Mini DisplayPort male to DisplayPort female adapter; a separate DisplayPort cable is required for most display connections.

What warranty applies?

MDP2DPMF6IN carries a StarTech.com limited lifetime manufacturer warranty, subject to the manufacturers terms and eligibility requirements.

Planning a broader setup? Browse the DeviceDeal buying guides.

(MDP2DPMF6IN)

Features & highlights

Why choose MDP2DPMF6IN?

?Purpose-built designMini DisplayPort 20-pin male to DisplayPort 20-pin female

?Specified performanceDisplayPort 1.2 overview support including 4K 60Hz, HBR2, MST and multi-channel audio with compatible equipment

?Professional constructionBlack 152.4mm 32AWG PVC adapter with gold-plated straight connectors and strain relief

?Key capabilityShort flexible lead reduces port strain compared with a rigid adapter body.

?Deployment advantagePassive, driver-free design works with compatible Mini DisplayPort and DisplayPort-over-Thunderbolt video sources.

?Order with confidenceThis is a Mini DisplayPort male to DisplayPort female adapter; a separate DisplayPort cable is required for most display connections.

Compatibility reminder: This is a Mini DisplayPort male to DisplayPort female adapter; a separate DisplayPort cable is required for most display connections.

StarTech MDP2DPMF6IN 15cm Mini DisplayPort to DisplayPort Adapter product image

Technical specifications

MDP2DPMF6IN specifications

Exact-model specifications for compatibility checking. Measurements may be rounded.

Warranty Information
Warranty	Lifetime
Connectors
Connector A	1 × Mini DisplayPort 20-pin male
Connector B	1 × DisplayPort 20-pin female
Hardware
Conductors	20
Connector Plating	Gold
Jacket	PVC
Wire Gauge	32AWG
Fire Rating	CMG
Performance
Product Overview	DisplayPort 1.2; HBR2; MST; multi-channel audio
Maximum Resolution	Up to 4K at 60Hz with compatible equipment
Physical Characteristics
Colour	Black
Cable Length	152.4mm / 6in
Cable Diameter	5mm
Product Weight	15g
What's in the Box
Included	15cm Mini DisplayPort-to-DisplayPort adapter, male/female

Sources: https://www.devicedeal.com.au/startech-mini-displayport-to-displayport-adapter and https://www.startech.com/

SKU	MDP2DPMF6IN
Barcode #	65030843300
Brand	Startech
Shipping Weight	0.0200kg
Shipping Width	0.020m
Shipping Height	0.010m
Shipping Length	0.180m
Shipping Cubic	0.000036000m3

Manufacturer warranty

Lifetime

This Australian-version product is supplied by DeviceDeal and is covered by the limited lifetime manufacturer warranty term listed for this exact product.

Keep your DeviceDeal tax invoice as proof of purchase.
Coverage is subject to StarTech.com warranty terms, eligibility and product assessment.
Warranty service does not replace rights that may apply under Australian Consumer Law.
