SYNOLOGY PS500

Synology PS500 5-Port Unmanaged Gigabit PoE+ Switch

A compact five-port unmanaged Gigabit Ethernet switch with four PoE+ ports, up to 30W per powered port and a 60W total PoE budget for plug-and-play device deployment.

5 Gigabit ports4 PoE+ ports60W total PoE budgetFanless metal housing

Product overview

Product details and key benefits

The PS500 is designed to power Synology Cameras and other PoE-enabled devices without software configuration, making it suitable for small-scale surveillance deployments.

Passive cooling, a metal enclosure and compact desktop form factor support quiet operation, with both desktop and wall-mount installation.

Plug-and-play unmanaged design

No software setup is required; connect compatible devices to provide network and PoE connectivity.

Four PoE+ ports

Up to 30W per PoE+ port with a total power budget of 60W.

Compact fanless construction

Metal housing with passive cooling for quiet operation.

Surveillance-oriented deployment

Five-port layout for Synology Cameras and other PoE-enabled devices in smaller monitoring setups.

Important product details

The unmanaged design operates without software configuration.
The 60W total PoE budget is shared across the four PoE+ ports.

Warranty and purchase confidence

DeviceDeal is an authorised reseller. This product is supported by a 2-year SYNOLOGY manufacturer warranty. Keep your DeviceDeal tax invoice as proof of purchase. Warranty eligibility, assessment and claims are subject to the manufacturers terms and conditions.

Buying information

Frequently asked questions

How many ports does the Synology PS500 have?

It has five Gigabit Ethernet ports.

How many ports provide PoE+?

Four ports provide PoE+.

What is the PoE power budget?

Each PoE+ port supports up to 30W, with a 60W total PoE budget.

Does the switch require configuration?

No. It is an unmanaged plug-and-play switch with no software setup required.

Is the PS500 fanless?

Yes. It uses passive cooling in a metal housing.

What type of installation is supported?

It supports desktop or wall-mount installation.

What warranty applies?

It includes a 2-year warranty.

(PS500)

Features and highlights

Synology PS500 5-Port Unmanaged Gigabit PoE+ Switch

Plug-and-play unmanaged design

No software setup is required; connect compatible devices to provide network and PoE connectivity.

Four PoE+ ports

Up to 30W per PoE+ port with a total power budget of 60W.

Compact fanless construction

Metal housing with passive cooling for quiet operation.

Surveillance-oriented deployment

Five-port layout for Synology Cameras and other PoE-enabled devices in smaller monitoring setups.

Key highlights

5-port Gigabit Ethernet switch
4 PoE+ ports
Up to 30W per PoE+ port
60W total PoE budget
Unmanaged plug-and-play operation
Passive fanless cooling
Desktop form factor
Desktop or wall-mount installation
NDAA and TAA compliance
2-year manufacturer warranty

DeviceDeal is an authorised reseller. This product is supported by a 2-year SYNOLOGY manufacturer warranty.

Technical specifications

Synology PS500 5-Port Unmanaged Gigabit PoE+ Switch

Product details

DeviceDeal SKU	PS500
Product type	Unmanaged Gigabit PoE+ switch
Form factor	Desktop
Main port type	Ethernet
Port count	5
Cooling	Passive / fanless
Housing	Metal

PoE

PoE+ ports	4
Maximum per-port power	Up to 30W
Total PoE budget	60W

Deployment

Configuration	Plug-and-play; no software setup required
Installation	Desktop or wall mount
Use case	Small-scale surveillance with Synology Cameras and other PoE-enabled devices
Compliance	NDAA and TAA
