Ubiquiti UX UniFi Express License-Free Site Management Cloud Gateway
Model# UX
-
SKU: UX
- Pick Up Available
- Australian Warranty
- Checkout Securely
Powerfully compact UniFi Cloud Gateway and WiFi 6 access point that runs UniFi Network. Powers an entire network or simply meshes as an access point.
Built-in WiF6 (2x2 MIMO)
140 m² (1,500 ft²) single-unit coverage
60+ connected WiFi devices
(1) GbE RJ45 WAN port
(1) GbE RJ45 LAN port to extend network
0.96" LCM status display
.jpg)
|
Runs UniFi Network
Powerful Gateway Engine
Application-Aware Firewall
Scalable
SD-WAN & VPN Ready
Impressively Compact
A complete UniFi networking stack in a sleek, plug-and-play form factor.
License-Free Site Management
Magically connect remote sites together with Site Magic SD-WAN.
UniFi Express Does It All
Featuring a full suite of gateway, security, and WiFi features for diverse use cases.
Flexible Deployment
UniFi Express powers an entire network or simply meshes as an access point.
Design Center
Powerful visualization and planning tool that allows you to simulate a complete UniFi system.
Start Your Project Here
(UX)
|
| Mechanical | |
|---|---|
| Dimensions | 98 x 98 x 30 mm (3.6 x 3.6 x 1.2") |
| Weight | 302 g (10.7 oz) |
| Enclosure material | Polycarbonate |
| Hardware | |
| Networking interface | (1) GbE RJ45 WAN port (1) GbE RJ45 LAN port |
| Management interface | Ethernet Bluetooth |
| Power method | USB type C (5V DC/3A) |
| Max. power consumption | 10W |
| Max. WiFi TX power 2.4 GHz 5 GHz |
22 dBm 25 dBm |
| MIMO 2.4 GHz 5 GHz |
2 x 2 (DL/UL MU-MIMO) 2 x 2 (DL/UL MU-MIMO) |
| Throughput rate 2.4 GHz 5 GHz |
573.5 Mbps 2.4 Gbps |
| Antenna gain 2.4 GHz 5 GHz |
4 dBi 5.15 dBi |
| Antennas | (2) Internal 2.4G/5G WiFi dual-band antenna (1) Internal 2.4G single-band BT antenna |
| LCM display | 0.96" status display |
| Button | Factory reset |
| Operating temperature | -10 to 45° C (14 to 113° F) |
| Operating humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
| Software | |
| WiFi standards | 802.11a/b/g WiFi 4/WiFi 5/WiFi 6 |
| Wireless security | WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3) |
| BSSID | 8 per radio |
| VLAN | 802.1Q |
| Advanced QoS | Per-user rate limiting |
| Guest traffic isolation | Supported |
| Concurrent clients | 60+ |
| Zero wait DFS | Yes |
| Supported Data Rates | |
| 802.11a | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| 802.11b | 1, 2, 5.5, 11 Mbps |
| 802.11g | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| 802.11n (WiFi 4) | 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40) |
| 802.11ac (WiFi 5) | 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160) |
| 802.11ax (WiFi 6) | 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160) |
| SKU | UX |
| Barcode # | 810084691960 |
| Brand | Ubiquiti |
| Shipping Weight | 1.3000kg |
