Powerfully compact UniFi Cloud Gateway and WiFi 6 access point that runs UniFi Network. Powers an entire network or simply meshes as an access point.


Built-in WiF6 (2x2 MIMO)

140 m² (1,500 ft²) single-unit coverage

60+ connected WiFi devices

(1) GbE RJ45 WAN port

(1) GbE RJ45 LAN port to extend network

0.96" LCM status display








IconRuns UniFi Network IconPowerful Gateway Engine IconApplication-Aware Firewall IconScalable
Mesh WiFi
IconSD-WAN & VPN Ready

Impressively Compact
A complete UniFi networking stack in a sleek, plug-and-play form factor.

License-Free Site Management
Magically connect remote sites together with Site Magic SD-WAN.

UniFi Express Does It All
Featuring a full suite of gateway, security, and WiFi features for diverse use cases.


Flexible Deployment
UniFi Express powers an entire network or simply meshes as an access point.

Design Center

Powerful visualization and planning tool that allows you to simulate a complete UniFi system.

Start Your Project Here



(UX)

IconRuns UniFi Network IconPowerful Gateway Engine IconApplication-Aware Firewall IconScalable
Mesh WiFi
IconSD-WAN & VPN Ready
Mechanical
Dimensions 98 x 98 x 30 mm (3.6 x 3.6 x 1.2")
Weight 302 g (10.7 oz)
Enclosure material Polycarbonate
Hardware
Networking interface (1) GbE RJ45 WAN port
(1) GbE RJ45 LAN port
Management interface Ethernet
Bluetooth
Power method USB type C (5V DC/3A)
Max. power consumption 10W
Max. WiFi TX power
2.4 GHz
5 GHz

22 dBm
25 dBm
MIMO
2.4 GHz
5 GHz

2 x 2 (DL/UL MU-MIMO)
2 x 2 (DL/UL MU-MIMO)
Throughput rate
2.4 GHz
5 GHz

573.5 Mbps
2.4 Gbps
Antenna gain
2.4 GHz
5 GHz

4 dBi
5.15 dBi
Antennas (2) Internal 2.4G/5G WiFi dual-band antenna
(1) Internal 2.4G single-band BT antenna
LCM display 0.96" status display
Button Factory reset
Operating temperature -10 to 45° C (14 to 113° F)
Operating humidity 5 to 95% noncondensing
Certifications CE, FCC, IC
Software
WiFi standards 802.11a/b/g
WiFi 4/WiFi 5/WiFi 6
Wireless security WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)
BSSID 8 per radio
VLAN 802.1Q
Advanced QoS Per-user rate limiting
Guest traffic isolation Supported
Concurrent clients 60+
Zero wait DFS Yes
Supported Data Rates
802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b 1, 2, 5.5, 11 Mbps
802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n (WiFi 4) 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
802.11ac (WiFi 5) 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)
802.11ax (WiFi 6) 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)
SKU UX
Barcode # 810084691960
Brand UBIQUITI
Shipping Weight 1.3000kg
