ASUSTOR Lockerstor 12R Pro AS7216RDX 16-Bay NAS, AMD Ryzen 7 Pro 3.8GHz up to 5.3GHz, 16GB DDR5, PCIe 5.0 x4, SATA, 4x USB 3.2 Gen 1 Type-A

The Lockerstor 12R Pro and 16R Pro Gen2 Bring Rising and Ryzen Speeds!

  • Powered by the AMD Ryzen 7 Pro 7745 processor with 8 cores and 16 threads
  • Equipped with 16 GB ECC DDR5-4800 memory, expandable up to 192 GB
  • Dual 10GbE + Dual Gigabit Ethernet
  • Expansion slots: PCIe 5.0 x8 and PCIe 5.0 x4
  • Supports PCIe Gen5 SSDs
  • Dual redundant 80 PLUS Platinum power supplies
  • Supports Wake on LAN on the Gigabit Ethernet ports

(AS7216RDX)

Hardware Specifications

CPU

 CPU Model AMD Ryzen 7 Pro 7745
  CPU Architecture x64 64-bit
  CPU Frequency 3.8GHz up to 5.3GHz

Memory

 Memory 16GB ECC DDR5-4800 UDIMM
  Memory Module Pre-installed 16GB (1x 16GB)
  Total Memory Slots 4
  Memory Expandable up to 192GB (4x 48GB)
  • Support mixed capacity
  Flash Memory 32GB SATA DOM

Storage

 Drive Bays 12
  M.2 Drive Slots 1
  Compatible Drive Type
  • 3.5" SATA HDD
  • 2.5" SATA HDD
  • 2.5" SATA SSD
  • M.2 2280 NVMe
  M.2 PCIe Interface  PCIe 5.0 x4
  Maximum Drive Bays with  40
  Supports Hot Swappable Drives

External Ports

 Expansion 4x USB 3.2 Gen 1 Type-A
  Network
  • 2 x Gigabit Ethernet (1G/100M, WOL)
  • 2 x 10Gigabit Ethernet (10G/1G)



 PCIe Expansion Slots 1 x Gen5 x8 slot (x8 link); 1 x Gen5 x4 slot (x4 link)
for optional 10/25/40/50 GbE card and SAS card



 Multimedia Output HDMI x1 (for service only)

Others

 System Fan 3x 60mm
  Power Supply Unit / Adapter 550W x2
  Input Power Voltage 100V to 240V AC
  Redundant power supply
  Service LED Indicator
  Certification FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, UKCA
  Warranty 5 Years

Operation

 Power Consumption 187W (Operation);
128W (Disk Hibernation);
  Noise Level N/A
  Operation Temperature 0°C~40°C (32°F~104°F)
  Storage Temperature -20°C~70°C (-4°F~158°F)
  Humidity 5% to 95% RH

Size and Weight

 Size 116(H) x 439(W) x 576(D) mm
  Weight 15.3kg / 33.7lb
SKU AS7216RDX
Brand ASUSTOR
Shipping Weight 15.3000kg

Manufacturer Warranty : 5 years Manufacturer Warranty
