System Main Processor Industrial embedded micro-processor Operating System Embedded Linux Operation Interface Web/local GUI Perimeter Protection by Camera Performance 24 channels AI Search Search pictures by channel, time, event type Face Recognition by Camera Performance 24 channels Face Attributes 6 attributes: Gender, age, glasses, expression, mouth mask, and beard AI Search Search pictures by channel, time and face attributes SMD Plus by Camera Performance 32 channels AI Search Search by target classification (Human, Vehicle) Video Metadata by Camera Performance 12 channels Human Body Top, top color, bottom, bottom color, hat, bag, gender, age, umbrella Vehicle Plate No., type, color, vehicle type, logo, plate color, ornament, calling, seatbelt, region Non-motor Vehicle Type, color, number of passengers, helmet AI Search Support search target video by metadata ANPR by Camera Performance 8 channels Stereo Analysis by Camera Performance 32 channels AI Search Search by target classification (Fall Detection, People Approach Detection, People No. Exception Detection, People Staying Detection, Violence Detection) Video Access Channel 64/128 Network Bandwidth 384 Mbps for access, 384 Mbps for storage and 384 Mbps for forwarding Resolution 12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/ 1080p/960p/720p/D1/CIF/QCIF Decoding Capability 16-ch@1080p (30 fps) Video Output VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 HDMI1/HDMI2: 3840 × 2160@30 fps, 3840 × 2160 @25 fps, 1920 × 1080, 1280 × 1024, 1280 × 720 1 channel VGA output, 2 channels HDMI output, VGA and HDMI 1 homologous output, double HDMI heterogeneous output. Support 4K display for both HDMI1 and HDMI2 Multi-screen Display 1st Screen: 1/4/8/9/16/25/36/64 2nd Screen: 1/4/8/9/16 Third Party Camera Access Panasonic, Sony, Samsung, Axis, Pelco, Arecont, Onvif, Canon and more Compression Video Smart H.265+/H.265/Smart H.264+/H.264/MPEG4/MJPEG Audio AAC/MP2/G726/G729/G722/G723/G711A/G711U/PCM Network Network Protocol HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, SNMP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, IP Search (Support Dahua IP camera, DVR, NVS, etc.), P2P Mobile Phone Access iOS, Android Interoperability ONVIF (profile T/S/G), CGI, SDK Browser Chrome, IE9 or later, Firefox Record Playback Multi-channel Playback 1/4/9/16 Record Mode Manual, Schedule (General, MD (Motion Detection), Alarm, MD & Alarm, Intelligent, POS) Storage Method Local HDD and network Backup Hard drive, USB device, eSATA device Playback Function 1. Play, pause, stop, fast forward, fast backward, rewind, play by frame 2. Full screen, backup (cut/file), partially enlarge, audio on/off Storage Disk Group Support Raid Support RAID 0/1/5/6/10 Alarm General Alarm Motion detection, privacy masking, video loss, local alarm, PIR alarm, IPC alarm Anomaly Alarm Camera offline, storage error, full storage, IP conflict, MAC conflict, login lock, network security anomaly Intelligent Alarm Perimeter protection, face detection, face recognition, SMD, video metadata (human, motor-vehicle, non-motor vehicle), ANPR, people counting, stereo analysis, crowd distribution, heatmap,video quality diagnosis Alarm Linkage Record, snapshot, IPC external alarm output, buzzer, log, preset, email External Port Audio Input 1 channel, RCA connector Audio Output 1 channel, RCA connector HDD 16 SATA III ports, up to 10 TB for a single HDD Alarm Input 16 channels Alarm Output 8 channels eSATA 1 eSATA SAS 1 Mini SAS Port, for Storage Expansion RS-232 1 channel, used to debug and pass through serial data RS-485 1 channel, used to control PTZ, and it supports multiple protocols USB 2 front USB 2.0 ports, 2 rear USB 3.0 ports HDMI 2 VGA 1 Network 6 in total, 4 × RJ45 10/100/1000 Mbps self-adaptive Ethernet ports and 2 × 1000 Mbps optical port General Parameter Power Supply Redundant, AC100V–240V, 50–60 Hz Power Consumption < 51 W (Without HDD) Net Weight 19.1 kg (42.1 lb) (Without HDD) Gross Weight 28.5 kg (62.8 lb) (Without HDD) Product Dimensions 485 mm × 516.5 mm × 133.2 mm (W × L × H) 19.09 inch × 20.34 inch × 5.24 inch (W × L × H)" Package Dimensions 648 mm × 723 mm × 445 mm (W × L × H) 25.51 inch × 28.46 inch × 17.52 inch (W × L × H) Operating Conditions –10°C to +55°C (+14°F to +131°F), +35°C (+95°F) when raid enabled Storage Conditions 0°C to +40°C (+32°F to +104°F) Operating Humidity 10%–93% (RH) Storage Humidity 30%–85% (RH) Operating Altitude 3000 m (9843 ft) Certifications CE: EN55022, EN55024, EN50130-4, EN60950-1 FCC: Part 15 Subpart B, ANSI C63.4-2014 UL: UL 60950-1 and CAN/CSA C22.2 No.60950-1

Manufacturer Warranty
