Hardware Ethernet Port 4 Optical Port 1 Ethernet Port Speed 100 Mbps Data Transmission Port Port 1–4: 4 × RJ-45 10/100 Mbps (PoE) Port 5: 1 × RJ-45 10/100/1000 Mbps (Uplink) Port 6: 1 × SFP 100/1000 Mbps (Uplink) Power Supply 53 VDC Operaing Temperature –30 °C to +65 °C (–22 °F to +149 °F) Operating Humidity 5%–95% (RH) Storage Temperature –30 °C to +70 °C (–22 °F to +158 °F) Storage Humidity 5%–95% (RH) Power Consumption Idling: 2.5 W Full load: 60 W Performance Capacity 6.80 Gbps Packet Forwarding Rate 3.57 Mpps Packet Buffer Memory 1 Mbit MAC Table Size 8K Communication Standard IEEE802.3; IEEE802.3u; IEEE802.3X; IEEE 802.3ab; IEEE 802.3z PoE PoE Standard IEEE802.3af; IEEE802.3at; Hi-PoE PoE Power 60 W Power Consumption Management Yes PoE Pin Assignment PoE/Hi-PoE: 1, 2, 4, 5 (V+), 3, 6, 7, 8 (V-) Long Distance PoE 250 m long distance PoE transmission General Statics Protection Air discharge: 15 kV Contact discharge: 8 kV Thunder-proof Common mode: 4 kV Differential mode: 2 kV Net Weight 0.45 kg (0.99 lb) Gross Weight 1.10 kg (2.43 lb) Product Dimensions 150 mm × 100 mm × 30 mm (5.91" × 3.94" × 1.18") (L × W × H) Packing Dimensions Packing box: 270 mm × 240 mm × 75 mm (10.63" × 9.45" × 2.95") (L × W × H) Protective box: 544 mm × 253 mm × 331 mm (21.42" × 9.96" × 13.03") (L × W × H)
