12-Port 10GbE Unmanaged Switch

QNAP QSW-1208-8C

The QNAP QSW-1208-8C is a 12-port unmanaged 10GbE switch designed to provide a cost-effective upgrade path for home and business networks. It combines four SFP+ ports with eight SFP+/RJ45 combo ports and supports 10GBASE-T and NBASE-T connectivity.

What is the QNAP QSW-1208-8C?

The QSW-1208-8C is an unmanaged 10GbE network switch with 12 ports in total. It provides four dedicated SFP+ ports and eight SFP+/RJ45 combo ports, giving users a choice of fibre or copper connectivity for different network devices and deployment requirements.

12 Ports Four SFP+ ports and eight SFP+/RJ45 combo ports

10GbE Supports 10GBASE-T and SFP+ connectivity

240Gbps Total switching capacity

Unmanaged Straightforward deployment without switch configuration

Flexible 10GbE Connectivity

Use fibre or copper connections to suit different devices and network layouts.

NBASE-T Ethernet

NBASE-T support allows existing network cabling to be used for higher transmission speeds, depending on cable type and length. Backwards compatibility is also provided for legacy devices.

SFP+ and RJ45 Ports

The switch combines SFP+ fibre and RJ45 copper interfaces, enabling a broad range of 10GbE-capable devices to connect to the same switch.

Eight Combo Ports

Eight SFP+/RJ45 combo ports provide deployment flexibility, while four additional SFP+ ports support fibre or direct attach copper connections.

Speed Up Workflows and Team Collaboration

10GbE connectivity supports faster file transfers and bandwidth-demanding network tasks.

A 10GbE network can support simultaneous real-time access to large files from multiple workstations, making the QSW-1208-8C suitable for supplied use cases such as video editing, multimedia workflows and virtualization.

The switch can connect 10GbE-capable workstations and servers to create a higher-speed network environment with cost-effective scalability.

10GBASE-T and NBASE-T Over Existing Cabling

Available speeds depend on cable category and cable length.

The QSW-1208-8C supports 10GbE and NBASE-T technologies, allowing higher transmission speeds over existing network cables. Its RJ45 combo ports support 10G, 5G, 2.5G, 1G and 100M speeds.

For 10GbE over RJ45, Cat 6a or higher cabling is supported. A Cat 6 cable may be used for 10Gbps when the distance between the switch and the connected device is shorter than 45 metres.

Cabling note: Actual connection speed depends on the cable type, cable length and the capabilities of the connected device.

Flexible Installation

A desktop form factor with rack installation support.

The QSW-1208-8C features a modern design for use in home or office environments. A rackmount kit is included for installing the switch in a rack.

The switch is made in Taiwan and is designed to provide a reliable 10GbE networking solution.

Frequently Asked Questions

Quick answers about the QNAP QSW-1208-8C.

Is the QSW-1208-8C a managed switch?

No. The QSW-1208-8C is an unmanaged switch.

How many 10GbE ports does it have?

It has 12 ports in total: four dedicated SFP+ ports and eight SFP+/RJ45 combo ports.

Which speeds are supported by the RJ45 combo ports?

The RJ45 combo ports support 10G, 5G, 2.5G, 1G and 100M speeds.

Can existing network cables be used?

Yes. NBASE-T support allows existing cabling to be used, with achievable speed depending on cable type and length.

Can Cat 6 cable be used for 10Gbps?

Yes. The supplied product information states that Cat 6 cable can be used for 10Gbps when the distance between the switch and device is shorter than 45 metres.

Is a rackmount kit included?

Yes. A rackmount kit is included at no extra cost.

What is the switching capacity?

The QSW-1208-8C has a switching capacity of 240Gbps and total non-blocking throughput of 120Gbps.

Product images are for illustrative purposes only and may differ from the actual product. Designs and specifications are subject to change without notice.

(QSW-1208-8C)

QNAP QSW-1208-8C Specifications

Review the port configuration, performance, power, physical and environmental specifications.

Specification	Details
Product Details
Model	QSW-1208-8C
Management Type	Unmanaged
Form Factor	Desktop
Ports and Networking
Number of Ports	12
10GbE SFP+ Ports	4 x 10GbE SFP+ ports (10G/1G)
10GbE SFP+/RJ45 Combo Ports	8The 10GbE SFP+ ports are backward compatible with 1GbE SFP. The RJ45 copper combo ports support 10G/5G/2.5G/1G/100M.
Supported Standards	IEEE 802.3ab 1000BASE-T Gigabit Ethernet IEEE 802.3bz 2.5G/5G BASE-T Multi-Gig Ethernet IEEE 802.3an 10GBASE-T 10G Ethernet IEEE 802.3ae 10GBASE-SR IEEE 802.3ae 10GBASE-LR IEEE 802.3x Full-duplex flow control
Jumbo Frames	9K
MAC Address Table	32K
Performance
Total Non-Blocking Throughput	120Gbps
Switching Capacity	240Gbps
Power and Cooling
Power Supply	Internal open frame
Maximum Power Consumption	50W
Input Power Type	AC
Input Voltage Range	100–240VAC, 50/60Hz
Fan System	2 x 4cm fans (12V DC)
Indicators and Physical Specifications
LED Indicators	Per port: Speed/Link/Activity Per system: Power/Status
Dimensions (H x W x D)	43 x 285 x 233mm
Net Weight	2.15kg
Gross Weight	2.2kg
Operating Environment
Operating Temperature	0°C to 40°C (32°F to 104°F)
Relative Humidity	10% to 85% RH non-condensing
Compliance and Warranty
Certifications	CE, FCC, VCCI, BSMI, RCM
Electromagnetic Compliance	Class A, UL62368
Warranty	2 years

QNAP reserves the right to replace partial parts or accessories if the original is no longer available from its manufacturer or supplier. Any replacement will be tested and verified to meet compatibility and stability guidelines and deliver identical performance to the original.

Product images are for illustrative purposes only and may differ from the actual product. Designs and specifications are subject to change without notice.

SKU	QSW-1208-8C
Model #	QSW-1208-8C
Barcode #	4713213511626
Brand	QNAP
Shipping Weight	2.5000kg
Shipping Width	0.290m
Shipping Height	0.040m
Shipping Length	0.230m
Shipping Cubic	0.002940000m3
