StarTech 2 Port PCI USB 3.0 Card w/ SATA Power - PCIUSB3S22
Model # PCIUSB3S22
-
SKU: PCIUSB3S22
- Pick Up Available
- Australian Warranty
- Checkout Securely
The PCIUSB3S22 2-Port PCI to USB 3.2 Gen 1 Card enables you to connect USB 3.2 Gen 1 peripherals to a PC through a legacy PCI host bus, which doubles the data transfer speeds when used with USB 3.2 Gen 1 peripherals than would be possible with a USB 2.0 host connection - up to 1.3 Gbps (PCI bus limit).
The card features an optional SATA power connection, which enables each port to supply up to 900mA of power to USB 3.2 Gen 1 bus-powered devices.
By supporting a legacy (PCI) host connection, the card adds updated peripheral connectivity, without having to upgrade to a PCIe-equipped motherboard or rely on the backward compatibility of USB 3.2 Gen 1 peripherals.
Guaranteed to provide reliable performance, the PCIUSB3S22 PCI USB 3.2 Gen 1 card is backed by lifetime warranty and free lifetime technical support.
(PCIUSB3S22)
| Warranty Information | ||
|---|---|---|
| Warranty | Lifetime | |
| Hardware | ||
| Bus Type | PCI / PCI-X (5 / 3.3V) | |
| Card Type | Standard Profile (LP bracket incl.) | |
| Chipset ID | Renesas/NEC - µPD720202 | |
| Interface | USB 3.0 | |
| Ports | 2 | |
| Performance | ||
| Maximum Data Transfer Rate | 1.3 Gbps (PCI Bus) | |
| Type and Rate | USB 3.0 - 5 Gbit/s | |
| UASP Support | Yes | |
| Connector(s) | ||
| Connector Type(s) | 1 - PCI / PCI-X (Universal 3.3 & 5V, 32-bit) Male | |
| External Ports | 2 - USB Type-A (9 pin) USB 3.0 Female | |
| Internal Ports | 1 - SATA Power (15 pin) Plug | |
| Software | ||
| OS Compatibility | Windows® XP, Vista, 7, 8, 8.1, 10 Windows Server® 2003, 2008 R2, 2012, 2012 R2, 2016, 2019 | |
| Special Notes / Requirements | ||
| System and Cable Requirements | Available PCI slot | |
| Available SATA power connector | ||
| Environmental | ||
| Humidity | 15% ~ 90% RH | |
| Operating Temperature | 5°C to 50°C (41°F to 122°F) | |
| Storage Temperature | -25°C to 70°C (13°F to 158°F) | |
| Physical Characteristics | ||
| Color | Red | |
| Product Height | 2.2 in [5.6 cm] | |
| Product Length | 4.8 in [12.3 cm] | |
| Product Width | 0.4 in [10 mm] | |
| Weight of Product | 2.1 oz [60 g] | |
| Packaging Information | ||
| Package Height | 1.3 in [32 mm] | |
| Package Length | 6.9 in [17.5 cm] | |
| Package Quantity | 1 | |
| Package Width | 5.7 in [14.4 cm] | |
| Shipping (Package) Weight | 5.2 oz [146 g] | |
| What's in the Box | ||
| Included in Package | 1 - PCI USB 3.0 Card | |
| 1 - Low Profile Bracket | ||
| 1 - Driver CD | ||
| 1 - Instruction Manual | ||
| SKU | PCIUSB3S22 |
| Barcode # | 65030849463 |
| Brand | Startech |
| Shipping Weight | 0.1500kg |
| Shipping Width | 0.100m |
| Shipping Height | 0.050m |
| Shipping Length | 0.170m |
| Shipping Cubic | 0.000850000m3 |
