StarTech 2S1P PCI Serial Parallel Combo Card - PCI2S1P
Model # PCI2S1P
-
SKU: PCI2S1P
- Pick Up Available
- Australian Warranty
- Checkout Securely
The PCI2S1P PCI Serial/Parallel Combo Card turns a PCI slot into two external 16C550 serial ports and one external EPP/ECP parallel port - an all-in-one solution that gives you both parallel and serial connections while taking up only one PCI slot.
Suitable for installation in a small form factor computer, the PCI serial/parallel card includes an optional low profile/half-height mounting bracket that makes installation easy.
The serial/parallel combo card is PCI plug and play ready and supports IRQ sharing for fast, simple installation. The combo card is supported in virtually any Microsoft Windows operating environment (Windows® 7, Server 2008 R2, Vista, XP, ME, 2000, 98, 95 and NT4), and is backed by a StarTech.com Lifetime Warranty and free lifetime technical support.
(PCI2S1P)
| Warranty Information | ||
|---|---|---|
| Warranty | Lifetime | |
| Hardware | ||
| Bus Type | PCI / PCI-X (5 / 3.3V) | |
| Card Type | Standard Profile (LP bracket incl.) | |
| Chipset ID | ASIX - MCS9835CV | |
| Interface | Parallel | |
| Serial | ||
| Port Style | Integrated on Card | |
| Ports | 2 | |
| Performance | ||
| FIFO | Serial: 32 Bytes Parallel: 16-Bytes | |
| Max Baud Rate | 115.2 Kbps | |
| Maximum Data Transfer Rate | Up to 1.5 Mbits/sec. | |
| Serial Protocol | RS-232 | |
| Connector(s) | ||
| Connector Type(s) | 1 - PCI / PCI-X (Universal 3.3 & 5V, 32-bit) Male | |
| External Ports | 1 - DB-25 (25 pin, D-Sub) Female | |
| 2 - DB-9 (9 pin, D-Sub) Male | ||
| Software | ||
| OS Compatibility | Windows® DOS, 95, 98SE, 2000, CE 5.0 / 6.0, Embedded System 2009, XP Embedded, POS Ready 2009, XP, Vista, 7, 8, 8.1, 10 Windows Server® 2003, 2008 R2, 2012, 2016, 2019 Linux 3.5.x to 4.11.x LTS Versions only | |
| Environmental | ||
| Humidity | 5~85% RH | |
| Operating Temperature | -10°C to 80°C (14°F to 176°F) | |
| Storage Temperature | -20°C to 100°C (-4°F to 212°F) | |
| Physical Characteristics | ||
| Product Height | 4.7 in [12 cm] | |
| Product Length | 4.7 in [12 cm] | |
| Product Width | 0.8 in [20 mm] | |
| Weight of Product | 2.3 oz [66 g] | |
| Packaging Information | ||
| Package Height | 1.3 in [32 mm] | |
| Package Length | 5.7 in [14.5 cm] | |
| Package Width | 6.9 in [17.5 cm] | |
| Shipping (Package) Weight | 7.1 oz [200 g] | |
| What's in the Box | ||
| Included in Package | 1 - PCI 2S1P Card | |
| 1 - DB9 Ribbon Cable | ||
| 3 - Low Profile Brackets | ||
| 1 - Driver CD | ||
| 1 - Instruction Manual | ||
| SKU | PCI2S1P |
| Barcode # | 65030781022 |
| Brand | Startech |
| Shipping Weight | 0.2400kg |
| Shipping Width | 0.100m |
| Shipping Height | 0.050m |
| Shipping Length | 0.170m |
| Shipping Cubic | 0.000850000m3 |
