Duplicate one SATA Hard Drive onto three Hard Drives simultaneously


The SATDOCK4U3RE USB 3.0 and eSATA 1-to-3 Hard Drive Duplicator docking station enables you to duplicate/clone a single SATA hard drive to up to three other SATA drives simultaneously, as a standalone device. The duplicator can also function as a regular 4-bay hard drive docking station, by connecting to a host computer system. Large capacity drives (tested with up to 4TB 3.5" and 1TB 2.5" drives per bay) can be used to greatly enhance your computer's storage/backup capabilities.

Able to perform 1:3 sector duplication, including HPA, from a single SATA drive onto three others simultaneously (at a rate of up to 72 MBps), the duplicator/docking station can save you time and effort. As an external HDD dock, it can be connected to your host computer through USB 3.0 or eSATA, providing data transfer speeds up to 5 Gbps or 3Gbps respectively, from the hard drives to your computer system.

Features Quick and Secure Erase functions and support for IDE hard drives using the included SATA to IDE hard drive adapter (SAT2IDEADP).


Applications

  • Creating multiple exact replicas of a source drive onto a new drive for large deployment of identical computer systems
  • Law enforcement and forensic technicians who need one or more exact copies of the original hard drive for testing or investigation
  • SMB, OEM, System Integrators, IT and service technicians requiring quick access to bare external hard drive contents, or the ability to clone data for data / disk recovery.

The StarTech.com Advantage

  • Create 3 exact copies of a source SATA drive simultaneously, without having to connect to a computer
  • Access up to 4 SATA hard drives simultaneously over a single USB 3.0 or eSATA connection
  • Dual, variable speed fans allows you to adjust the amount of cooling for any kind of environment or drive type

(SATDOCK4U3RE)

Warranty Information
Warranty 2 Years
Hardware
Chipset ID JMicron - JMB394
JMicron - JMS539
Compatible Drive Types SATA
Drive Size 2.5in & 3.5in
Fans 2 - 60 mm
Number of Drives 4
Performance
Duplication Modes Sector by Sector (Whole Drive)
Duplication Speed 4.2GBpm
Erase Modes Quick Erase
Secure Erase (NIST SP 800-88 Rev 1 - Purge)
Insertion Rating 15,000 cycles per bay
Max Drive Capacity Currently tested with up to 4TB 5400 RPM 3.5" hard drives per bay (16TB total) and 1TB 5400 RPM 2.5" hard drives (4TB total)
Maximum Data Transfer Rate 3Gbps
Port Multiplier Yes
Type and Rate USB 3.0 - 5 Gbit/s
SATA II (3 Gbps)
Connector(s)
Drive Connectors 4 - SATA Data & Power Combo (7+15 pin) Receptacle
Host Connectors 1 - eSATA (7 pin, Data) Receptacle
1 - USB Type-B (9 pin) USB 3.0 Female
Software
OS Compatibility OS independent; No software or drivers required
Indicators
LED Indicators 4 - Drive Power/Activity
Power
Input Current 2.0 A
Input Voltage 100 - 240 AC
Output Current 6.5 A
Output Voltage 12 DC
Power Consumption (In Watts) 78
Power Source AC Adapter Included
Environmental
Humidity 8%~90% RH
Operating Temperature 5¡C to 80¡C (41¡F to 176¡F)
Storage Temperature -40¡C to 70¡C (-40¡F to 158¡F)
Physical Characteristics
Color Black
Enclosure Type Plastic
Product Height 3.8 in [9.6 cm]
Product Length 11.2 in [28.4 cm]
Product Width 6.8 in [17.2 cm]
Weight of Product 2.4 lb [1.1 kg]
Packaging Information
Package Height 8.5 in [21.5 cm]
Package Length 13.5 in [34.3 cm]
Package Width 6.7 in [17 cm]
Shipping (Package) Weight 6 lb [2.7 kg]
What's in the Box
Included in Package 1 - SATA Duplicator Dock
1 - SATA to IDE Adapter
1 - 40-pin IDE Cable
1 - 44-Pin to 40-Pin IDE Cable
1 - eSATA Cable
1 - Package of Mounting Screws
1 - SP4 to LP4 Power Cable
1 - USB 3.0 Cable
1 - Universal Power Adapter (NA/JP, UK, EU, ANZ)
1 - Instruction Manual
SKU SATDOCK4U3RE
Barcode # 65030843881
Brand Startech
Shipping Weight 2.7400kg
Shipping Width 21.800m
Shipping Height 18.400m
Shipping Length 33.800m
