Expansion Unit

DX1222

Name: Synology Expansion Unit DX1222 12-Bay 3.5" Diskless NAS for Scalable Models (SMB/ENT)
Brand: SYNOLOGY
SKU: DX1222
Price: 2069 AUD
Availability: InStock

Enterprise-grade expansion unit storage solution

Use Synology Expansion Unit DX1222 to add 12 additional bays to your deployment while keeping your storage and services online and uninterrupted.Download Datasheet

Uncompromising performance

Scalability

12 drive bays

Fast setup

Your additional storage will be ready to use in a matter of moments after you connect it to your host NAS.Online volume expansion enables you add a new volume or expand RAID volumes without reformatting drives through DiskStation Manager (DSM).

Backed by Synology drives

Engineered to handle intensive 24/7 workloads, Synology drives consistently deliver top-grade performance.

Centrally manage all your drives

Benefit from unified drive management after connecting the DX1222 to your primary NAS. Maintenance, monitoring, and administration of drives on both units is simple with Synology DSM.

5-year warranty

At Synology, we are committed to product innovation and quality. Synology guarantees a robust and reliable data management experience with a 5-year limited warranty,providing responsive technical support and hardware replacement services to maximize your return on investment.Learn more

(DX1222)

Technical Specifications

Complete hardware and software specifications

Applied Models

Supports creating volumes across different units 22 series: DS3622xs+, DS2422+

Notes To have better performance, we recommend creating storage volumes physically located within the same NAS or Expansion Unit, rather than creating volumes across your NAS and Expansion Unit.

Storage

Drive Bays 12

Drive Type(See all supported drives) 3.5" SATA HDD 2.5" SATA HDD 2.5" SATA SSD

Hot Swappable Drive* Yes

RAID Management through Synology DSM Yes

Notes Synology only guarantees full functionality, reliability, and performance for Synology drives listed on the compatibility list . The use of non-validated components may limit certain functionality and result in data loss and system instability.

External Ports

Expansion Port 1

Appearance

Size (Height x Width x Depth) 270 mm x 300 mm x 340 mm

Weight 9.02 kg

Power

Power Recovery Synchronized with the Synology DiskStation

Power Supply Unit / Adapter 550 W

AC Input Power Voltage 100V to 240V AC

Power Frequency 50/60 Hz, Single Phase

Power Consumption* 57.71 W (Access) 16.25 W (HDD Hibernation)

British Thermal Unit 194.96 BTU/hr (Access) 55.48 BTU/hr (HDD Hibernation)

Notes Power consumption is measured when it is fully loaded with Western Digital 1TB WD10EFRX hard drive(s).

Temperature

Operating Temperature 0°C to 40°C (32°F to 104°F)

Storage Temperature -20°C to 60°C (-5°F to 140°F)

Operating Humidity 8% to 80% RH

Storage Humidity 5% to 95% RH

Others

System Fan 120 mm x 120 mm x 2 pcs

Easy Replacement System Fan Yes

Noise Level* 24.6 dB(A)

Notes Noise Level Testing Environment: Fully loaded with Seagate ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology expansion unit at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%.

Certification

Certification UL FCC CE BSMI UKCA EAC VCCI RCM KC BIS

Warranty

Warranty 5 Years

Notes The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)

Environment

Environment RoHS Compliant

Packaging Content

Packaging Content Main Unit X 1 Accessory Pack X 1 AC Power Cord X 1 Expansion Cable: MiniSAS-HD X 1 Quick Installation Guide X 1

Optional Accessories

Optional Accessories Enterprise Series 3.5" SATA HDD: HAT5300 Series Plus Series 3.5" SATA HDD: HAT3300 Series Enterprise Series 2.5" SATA SSD: SAT5200 Series

SKU	DX1222
Barcode #	4711174724192
Brand	SYNOLOGY
Shipping Weight	12.2700kg
Shipping Width	0.440m
Shipping Height	0.470m
Shipping Length	0.430m
