Expansion Unit

RX1223RP

Name: Synology RX1223RP 12-Bay Diskless Rackmount Expansion Unit
Brand: SYNOLOGY
SKU: RX1223RP
Price: 4254 AUD
Availability: InStock

Enterprise-grade expansion unit storage solution

RX1223RP is ready to use as soon as it is connected to a host device.

Uncompromising performance

Scalability

12 drive bays

Seamless 12-bay capacity expansion

Add up to 96 storage bays to compatible units with Synology Expansion Unit RX1223RP. Enlarge or create new volumes without system or service downtime thanks to online storage expansion.

Expand storage on the fly

RX1223RP provides simple storage expansion with 12 drive bays for 3.5”/2.5” SATA HDD/SDD drives.

Redundant design for high reliability

Modular drive trays and system fans enable easy and quick replacement, reducing the impact of maintenance on service availability. Redundant power supply units keep your data online in the event one power source fails.

Simple deployment and management

Plug-and-play design means the RX1223RP is ready to use as soon as it is connected to a host device.

Backed by Synology drives

Leverage high sustained performance and reliability with enterprise-grade drives with built-in data protection designed for Synology systems.

Synology has you covered

The RX1223RP is backed by Synology's 5-year limited warranty,including technical support and hardware replacement services to maximize your return on investment and ensure continued high-quality performance.Learn more

(RX1223RP)

Technical Specifications

Complete hardware and software specifications

Applied Models

Supports creating volumes across different units SA series: SA6400 23 series: RS2423RP+, RS2423+

Notes To have better performance, we recommend creating storage volumes physically located within the same NAS or Expansion Unit, rather than creating volumes across your NAS and Expansion Unit.

Storage

Drive Bays 12

Drive Type(See all supported drives) 3.5" SATA HDD 2.5" SATA SSD

Hot Swappable Drive* Yes

RAID Management through Synology DSM Yes

Notes Synology only guarantees full functionality, reliability, and performance for Synology drives listed on the compatibility list . The use of non-validated components may limit certain functionality and result in data loss and system instability. "Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.

External Ports

Expansion Port 1

Appearance

Size (Height x Width x Depth) 88 mm x 430.5 mm x 692 mm

Size (Height x Width x Depth) (with server ears) 88 mm x 482 mm x 724 mm

Weight 13.9 kg

Rack Installation Support* 4-post 19" rack (Synology Rail Kit - RKS-02 )

Notes The rail kit is sold separately

Power

Power Recovery Synchronized with the Synology RackStation

Power Supply Unit / Adapter 550 W

AC Input Power Voltage 100V to 240V AC

Power Frequency 50/60 Hz, Single Phase

Power Consumption* 93.59 W (Access) 30.73 W (HDD Hibernation)

British Thermal Unit 319.34 BTU/hr (Access) 104.86 BTU/hr (HDD Hibernation)

Redundant Power Supply Yes

Notes For more information on how power consumption is measured, refer to this article .

Temperature

Operating Temperature 0°C to 35°C (32°F to 95°F)

Storage Temperature -20°C to 60°C (-5°F to 140°F)

Operating Humidity 8% to 80% RH

Storage Humidity 5% to 95% RH

Others

System Fan 80 mm x 80 mm x 4 pcs

Easy Replacement System Fan Yes

Noise Level* 54.3 dB(A)

Notes Noise Level Testing Environment: Fully loaded with Synology SAT5200-480G SSD in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%

Certification

Certification UL FCC CE BSMI UKCA EAC VCCI RCM KC BIS

Warranty

Warranty 5 Years

Notes The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)

Environment

Environment RoHS Compliant

Packaging Content

Packaging Content Main Unit X 1 Accessory Pack X 1 AC Power Cord X 2 Expansion Cable: MiniSAS-HD X 1 Quick Installation Guide X 1

Optional Accessories

Optional Accessories Enterprise Series 3.5" SATA HDD: HAT5300 Series Plus Series 3.5" SATA HDD: HAT3300 Series Enterprise Series 2.5" SATA SSD: SAT5200 Series Rail Kit Sliding: RKS-02
