TP-LINK DS1008X Omada 8-Port 10G Unmanaged Desktop/Rackmount Switch
Model # DS1008X
-
SKU: DS1008X
- Pick Up Available
- Australian Warranty
- Checkout Securely
TP-LINK DS1008X Omada 8-Port 10G Unmanaged Desktop/Rackmount Switch
- Eight 10 Gbps Ports. 8× 10-Gigabit ports unlock the highest performance of your 10G/Multi-Gig bandwidth and devices, and provide up to 160 Gbps of switching capacity.
- Lightning-Fast Connections. Provides lightning-fast connections to 10G NAS, Server, 10G PCIe Adapter/ NIC, gaming computer, 2.5G/5G/10G WiFi 6 AP, 8K video, and more.
- Ideal for Various Scenarios. Built for lightning-fast connections in business and home offices, workstations, LAN parties, and home entertainment.
- Optimal 5-Speed Connections. Auto-negotiation for 5-speed (100Mbps/1G/2.5G/5G/10G) connections provide optimal performance.
- Plug and Play. No configuration or central management required.
(DS1008X)
| Standards and Protocols | IEEE 802.3, 802.3u, 802.3ab, 802.3x, 802.1p, 802.3an, 802.3bz |
|---|---|
| Interface | • 8× 100Mbps/1Gbps/2.5Gbps/5Gbps/10Gbps Ports • Auto-Negotiation • Auto-MDI/MDIX |
| Fan Quantity | 1 |
| External Power Supply | 100–240 VAC, 50/60 Hz, 0.8A |
| LED Indicator | • System Power: 1 • Link/Act Indicators: 2 indicator per port built into each RJ45 port |
| Dimensions ( W x D x H ) | 11.6×7.1×1.7 in (294×180×44 mm) |
| Max Power Consumption | 31.2 W |
| PERFORMANCE | |
|---|---|
| Switching Capacity | 160 Gbps |
| Packet Forwarding Rate | 119.0 Mpps |
| MAC Address Table | 16 K |
| Packet Buffer Memory | 12 Mbit |
| Jumbo Frame | 12 KB |
| SOFTWARE FEATURES | |
|---|---|
| Advanced Features | • 802.3X Flow Control • 802.1p/DSCP QoS |
| Transfer Method | Store and Forward |
| OTHERS | |
|---|---|
| Certification | CE, FCC ,RoHS |
| Package Contents | • DS1008X • Power Cord • Installation Guide • Rackmount Kit • Rubber Feet |
| Environment | • Operating Temperature: 0–50 °C (32–122 °F) • Storage Temperature: -40–70 °C (-40–158 °F) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing |
| SKU | DS1008X |
| Barcode # | 840030712463 |
| Brand | TP-LINK |
| Shipping Weight | 0.7100kg |
