Zebra ZQ610 Plus mobile label and receipt printer

The Zebra ZQ610 Plus is a 1.89-inch mobile direct thermal label and receipt printer with 203dpi output, USB, 802.11ac Wi-Fi and Bluetooth connectivity.

1.89-inch format203dpi802.11ac Wi-Fi3250mAh battery
Connected mobile operation

The supplied information lists 802.11ac Wi-Fi, Bluetooth Classic and Bluetooth Low Energy for compatible mobile workflows.

Clear printer status

A large colour display, user-friendly interface and customisable Link-OS menu support printer configuration and operation.

Instant wake-up

The printer can enter sleep mode while idle and wake when a print job is sent over Wi-Fi or Bluetooth.

Mobile label and receipt output

Direct thermal printing supports compatible barcodes, text and graphics, with peel-and-present mode, a label-present sensor and a tear bar.

Battery and charging

The supplied ZQ610 Plus family information lists a 3250mAh battery, a built-in battery charger and Power Smart Print Technology.

Programming and storage

CPCL, EPL and ZPL programming languages are listed, together with 512MB Flash and 128MB available for user storage.

Key specifications

Print methodDirect thermal
Print width1.89 inches
Resolution203dpi
OutputBarcodes, text and graphics
ConnectivityUSB, 802.11ac Wi-Fi, Bluetooth Classic and Bluetooth Low Energy
Wi-Fi roaming802.11r fast roaming
Programming languagesCPCL, EPL and ZPL
Flash memory512MB
User storage128MB available
Battery3250mAh
ChargingBuilt-in battery charger
Media sensingBlack mark and gap sensing with fixed centre-position sensors
Media handlingPeel-and-present mode, label-present sensor and tear bar

Frequently asked questions

Which wireless connections are included?

The supplied information lists 802.11ac Wi-Fi, Bluetooth Classic and Bluetooth Low Energy.

What battery capacity is listed?

The supplied ZQ610 Plus information lists a 3250mAh battery.

Which programming languages are supported?

CPCL, EPL and ZPL are listed.

(ZQ61-AAWAA04-00)

Battery Information
Battery Capacity 3250 mAh
Display & Graphics
Display Screen Yes
Memory
Standard Memory 256 MB
Power Description
Power Source Battery
Software
Operating System Supported Link-OS
Fonts & Emulation
Language Emulation CPCL
  ZPL
  ZBI 2.0
  EPL
Miscellaneous
Platform Supported Android
  iOS
  PC
Certifications & Standards

Emissions:

  • FCC Part 15
  • Subpart B
  • EN55022 Class-B
  • EN60950
  • EN55024
  • VCCI class B


Susceptibility:

  • EN55024
  • EN61000-4-2
  • EN61000-4-3
  • EN61000-4-4
  • EN61000-4-5


Safety:

  • CE
  • TUV
  • CSA
Network & Communication
Bluetooth Yes
Wireless LAN Yes
Wireless LAN Standard IEEE 802.11ac
Near Field Communication (NFC) Yes
Physical Characteristics
Weight (Approximate) 600 g
Height 72.4 mm
Width 91.4 mm
Depth 170.9 mm
General Information
Product Type Direct Thermal Printer
Manufacturer Part Number ZQ61-AAWAA04-00
Manufacturer Website Address http://www.zebra.com/ap/en.html
Manufacturer Zebra Technologies Corporation
Product Model ZQ610 Plus
Product Name ZQ610 Plus Direct Thermal Printer
Product Series ZQ600
Brand Name Zebra
Media Types & Handling
Media Thickness 165.1 µm
Maximum Roll Diameter 55.88 mm
Media Type Tag
  Receipt
  Black Mark
  Linered Media
  Label
  Gap
  Black Bar
  Die-cut Label
Media Sensor Gap Sensor
  Black Mark Sensor
Maximum Label Width 55.37 mm
Maximum Label Length 812.80 mm
Technical Information
Application/Usage Industrial
  Mobile
  Desktop
Barcode Symbology Supported Code 128
  Code 39
  Code 93
  Data Matrix
  EAN-13
  EAN-8
  FIM
  Interleaved 2 of 5
  Maxi Code
  Micro PDF-417
  MSI PLESSEY
  PDF417
  POSTNET
  QR Code
  TLC 39
  UCC/EAN 128
  UPC E with 2 and 5 add on
  UPC-A
  Codabar (NW-7)
  AZTEC
  2 and 5 Digits Add-on
  GS1 DataBar
Maximum Print Width 48 mm (1.89")
Recommended Use Label/Receipt Print
Features Water Resistant
  Shoulder Strap
  Dust Resistant
  Belt Clip
Print Technology Direct Thermal
Mobile Device Printing Yes
Print Color Capability Monochrome
Maximum Print Length 813 mm
Character Sets Universal Font Scaling Technology (UFST)
  Agfa Monotype
Optional Connectivity Serial (RS-232)
  Ethernet
  USB
Ingress Protection (IP) Rating IP54
Maximum Print Resolution (dpi) 203
SKU ZQ61-AAWAA04-00
Brand Zebra
Shipping Weight 0.7400kg
Shipping Width 0.009m
Shipping Height 0.020m
Shipping Length 0.011m

Manufacturer Warranty

Be The First To Review This Product!

Help other Device Deal users shop smarter by writing reviews for products you have purchased.

Write a product review

Zebra ZQ610 Plus 1.89-inch Mobile Direct Thermal Label and Receipt Printer 203dpi USB Wi-Fi Bluetooth

Model # ZQ61-AAWAA04-00

  • SKU: ZQ61-AAWAA04-00

$1,308.00
$1,912.00
SAVE $604.00 (32%)
Only 3 left!
