Critical Power, Cooling and Racks > IT Power Distribution > Rack Power Distribution > NetShelter Basic Rack PDUs > AP7551

Rack PDU,Basic,ZeroU,16A,230V,(20)C13 & (4)C19; IEC309

SKU: AP7551 | Brand: APC Brand

Key Features

Provides 20 C13 and 4 C19 outlets for extensive power distribution
Vertical mounting to save rack space
Supports up to 16A, 230V power distribution
Includes toolless mounting kit for quick setup

Description

It is a basic rack PDU with a Zero U vertical mounting design.
It supports a maximum input current of 16A and operates at 230V.
The PDU features 20 IEC 60320 C13 outlets and 4 IEC 60320 C19 outlets, providing flexibility for connecting various IT equipment.
It includes a 3-foot power cord with an IEC 60309 16A plug.
The unit is designed for reliable power distribution and includes an installation guide, rack mounting brackets, and a toolless mounting kit.

Downloads & Documents

Compatible Products & Accessories

Mounting

AR7711

NetShelter Zero U Accessory Mounting Bracket

PDU

AP9569

Cord Retention Bracket for Basic Rack PDUs

EPDU1016B

APC Easy Rack PDU, Basic, 1U, 1 Phase, 3.7kW, 230V, 16A, 8 x...

EPDU1016M

APC Easy Rack PDU, Metered, 1U, 1 Phase, 3.7kW, 230V, 16A, 8...

EPDU1016S

APC Easy Rack PDU, Switched, 1U, 1 Phase, 3.7kW, 230V, 16A, ...

(AP7551)

Specifications - AP7551

Overview

Lead time

Usually in Stock

Main

Colour	Black
Product or component type	PDU
PDU type	Basic
Cord length	0.9 m
Number of cables	1
Provided equipment	Installation guide Toolless mounting kit

Complementary

Input Voltage	200 V 208 V 230 V
Height	1619 mm
Width	56 mm
Output Voltage	230 V
Depth	44 mm
Net weight	4.86 kg
Mounting location	Side
Mounting preference	No preference
Input Plug Type	IEC 60309 16 A 2P + E
Mounting mode	Rack-mounted
Rack units	0U
Mounting position	Vertical
Input current limits	16 A
Load capacity	3680 VA
Network frequency	50/60 Hz
Outlet type and quantity	20 IEC 60320 C13 4 IEC 60320 C19

Environment

Product certifications	CE GOST IRAM VDE
Ambient air temperature for operation	0…45 °C
Relative humidity	5…95 %
Operating altitude	0...10000 ft
Ambient air temperature for storage	-25…65 °C
Storage Relative Humidity	5…95 %
Storage altitude	0…15240 m
