CyberPower Online S OLS6KE Double Conversion Online UPS
Model # OLS6KE
-
SKU: OLS6KE
- Pick Up Available
- Australian Warranty
- Checkout Securely
CyberPower Online S OLS6KE Double Conversion Online UPS - 6 kVA/6 kW - Tower - 4 Hour Recharge - 5.60 Minute Stand-by - 230 V AC, 120 V AC Input - 200 V AC, 208 V AC, 220 V AC Output - 1 x Hardwire Terminal Block - Pure Sine Wave - Serial Port - USB - LCD Display - Dry Contact, SNMP/HTTP Remote Monitoring
The online double-conversion UPS with tiltable Colour LCD panel and Extended Battery Module auto-detection for effcient power management
Designed for oce and data centre applications, the Online S (Premium) Series adopts double-conversion topology to provide seamless Pure Sine Wave output. With an output power factor of 1, this series provides more usable power for critical devices. The tiltable Colour LCD panel provides an intuitive interface, enabling users to easily monitor the system and configure the settings. The auto-detection of Extended Battery Modules (EBM) helps estimate UPS's runtime by identifying the number of connected EBMs. Furthermore, the battery charging current is adjustable via LCD setting to shorten charging time. The products also provide relay-type dry contacts to support local management from specific UPS signals. In addition, Remote Cloud Card is included for selected products to make remote monitoring and multi-location management much easier.
SERIES FEATURES
- Online (Double Conversion) UPS Topology
- ECO Mode
- High Output Power Factor
- Pure Sine Wave Output
- UPS Parallel Expansion
- Overload Protection
- Maintenance Bypass Switch
- Adjustable Charging Current
- Extended Battery Module Auto-detection
- Colour LCD Panel
- Tiltable LCD Panel
- Relay-type Dry Contact
- Emergency Power Off (EPO) Port
- PowerPanel Management Software
- Built-in Remote Cloud Card by Ethernet
- Zero Transfer Time
Features
- Keep your sensitive devices powered with a backup of up to 5.60 minute at full load
- 6 kVA load capacity - work without any interruption during power outages
- 6 kVA load capacity provides sufficient backup during power failures
- 6 kW load capacity - backup power for your valuable electronics
- Prevent critical data loss by staying powered during a blackout with up to 6 kW load capacity
(OLS6KE)
| -sensing |
Rated Input Current ( A )
| 30 |
Input Power Factor
| 0.99 |
Input Connector Type
| Hardwire Terminal Block |
OUTPUT
Capacity (VA)
| 6000 |
Capacity (Watts)
| 6000 |
On Battery Waveform
| Pure Sine Wave |
On Battery Voltage(s) ( Vac )
| 200 ± 1 % |
| 208 ± 1 % |
| 220 ± 1 % |
| 230 ± 1 % |
| 240 ± 1 % |
Output Voltage Setting
| Configurable |
On Battery Frequency ( Hz )
| 50 ± 0.5% |
| 60 ± 0.5% |
Output Frequency Setting
| Configurable |
Power Factor
| 1 |
ECO Mode Voltage Tolerance
| ± 10 % |
Overload Protection
| Internal Current Limiting, Circuit Breaker, Fuse |
Overload Protection (Line Mode)
| 105~130% Load for 10 sec, >130% Load for 1.5 sec |
Overload Protection (Battery Mode)
| 105~130% Load for 10 sec, >130% Load for 1.5 sec |
Overload Protection (Bypass Mode)
| 110~120% Load for 30 min, 120~130% Load for 2 min, 130~150% Load for 15 sec, >150% Load Immediately |
Crest Factor
| 3 : 1 |
Harmonic Distortion (Linear Load)
| THD＜1.5% |
Harmonic Distortion (Non-linear Load)
| THD＜2% |
Internal Bypass
| Automatic Bypass, Manual Bypass |
Maintenance Bypass
| Yes |
Outlet(s) - Total
| 1 |
Outlet Type
| Hardwire Terminal Block x 1 |
Typical Transfer Time ( ms )
| 0 |
BATTERY
Runtime at Half Load ( min )
| 17.7 |
Runtime at Full Load ( min )
| 5.6 |
Typical Recharge Time ( Hours )
| 4 |
Maximum Charging Current ( A )
| 4 |
Adjustable Charging Current ( A )
| 1 ~ 4 |
Start On Battery
| Yes |
Smart Battery Management (SBM)
| Yes |
Battery Type
| Sealed Lead-acid |
Compatible Extended Battery Module (EBM)
| BPS240V7A |
Extended Battery Module Auto-detection
| Yes |
Max. EBM Quantity ( pcs )
| 10 |
SURGE PROTECTION & FILTERING
Surge Suppression ( Joules )
| 1335 |
EMI/RFI Filtration
| Yes |
MANAGEMENT & COMMUNICATIONS
LCD Panel
| Yes |
LCD Types
| Color LCD |
Tiltable LCD Panel
| 15° |
LCD Information Display
| Operation Type, Power Status, Battery Status, Load Status, Fault & Warning, Other Information, Event & Log |
LCD Setting & Control
| Mode Setting, Alarm Setting, Input & Output, Battery Setting, Fault & Warning, Communication, Event & Log, Security Setting |
LED Indicators
| Power On |
HID Compliant USB Port(s)
| 1 |
Serial Port
| RS232 |
Dry Contact (with Relay)
| Yes |
Emergency Power Off (EPO) Port
| Yes |
Audible Alarms
| Battery Mode, Low Battery, Overload, Overcharge, Overheat, UPS Fault, Replace Battery |
Management Cable ( pcs )
| USB Cable x1, Phone Line x1, Parallel Cable x1 |
Power Management Software
| PowerPanel Business (Recommended) |
SNMP/HTTP Remote Monitoring
| Yes - with optional RMCARD205 |
Remote Cloud Card
| Yes - Built-in Remote Cloud Card by Ethernet included |
PowerPanel Cloud Service
| Yes - 90 Days (UPS) Free Trial + 3 Years (Remote Cloud Card) Free Service |
PHYSICAL
Enclosure Construction
| Metal |
Color
| Black |
Rackmount Rail
| Yes |
Rackmount Ears
| Yes |
PHYSICAL SIZE - UPS MODULE
Dimensions (WxHxD) (mm.)
| 270 x 520 x 460 |
ENVIRONMENTAL
Operating Temperature (°F)
| 32 ~ 104 |
Operating Temperature (°C)
| 0 ~ 40 |
Operating Relative Humidity (Non-condensing) ( % )
| 0 ~ 95 |
Operating Elevation ( feet/meters )
| 0-4,921 feet (0-1,500 meters) |
Storage Temperature (°F)
| 5 ~ 113 |
Storage Temperature (°C)
| -15 ~ 45 |
Storage Relative Humidity (Non-condensing) ( % )
| 0 ~ 95 |
Storage Elevation ( feet/meters )
| 0-49,213 feet (0-15,000 meters) |
Online Thermal Dissipation ( BTU/hr )
| 1777 |
CERTIFICATIONS
Certifications
| CE, RCM |
RoHS
| Yes |
| SKU | OLS6KE |
| Brand | CYBERPOWER |
Manufacturer Warranty
