QNAP TS-h1065eU-RP-8G 8+2 Bay Redundant PSU NAS

8+2 bay 2U short-depth rackmount NAS

QNAP TS-h1065eU-RP-8G 8+2 Bay Short-Depth NAS with Redundant Power

The QNAP TS-h1065eU-RP-8G is a 297.4mm-deep 2U rackmount NAS with eight front SATA bays, two rear E1.S/M.2 NVMe slots, an Intel 4-core processor, 8GB DDR5, dual 2.5GbE, PCIe expansion and two 300W power supplies.

8 + 2 drive positions297.4mm depthDual 2.5GbE2 × 300W PSU

QNAP TS-h1065eU-RP-8G 8+2 bay short-depth NAS with redundant power

What is the QNAP TS-h1065eU-RP-8G?

It is a compact QuTS hero NAS for space-constrained racks that combines SATA and NVMe storage positions, multi-gigabit networking and a redundant power design.

8 + 2 BaysSATA plus E1.S/M.2 NVMe

8GB DDR5Expandable to 16GB

2 × 2.5GbEPort trunking or SMB Multichannel

2 × 300WRedundant power supplies

Need help choosing a NAS?

Explore the DeviceDeal NAS Buying Guide

Compare NAS types, storage considerations and practical features before selecting your next network storage system.

Read NAS Buying Guide

Mixed SATA and NVMe storage positions

Eight front 3.5-inch bays support compatible 3.5-inch SATA hard drives and 2.5-inch SATA solid state drives.

Two rear E1.S/M.2 NVMe Gen 3 x1 slots support compatible E1.S NVMe SSDs or M.2 NVMe SSDs.

The supplied specifications list the storage positions as hot-swappable.
SSD cache acceleration is supported.
The separate M.2 slot specification is listed as optional through a compatible PCIe adapter.

Intel processing, DDR5 memory and QuTS hero

The supplied specifications identify an Intel 4-core, 64-bit x86 processor with AES-NI encryption and hardware-accelerated transcoding.

This configuration includes 8GB SODIMM DDR5 memory and supports up to 16GB through one memory slot.

The supplied description states support for In-Band ECC.
QuTS hero uses the ZFS file system and includes self-healing of static data, WORM, deduplication and snapshot backups.
Use compatible QNAP memory and refer to the hardware user manual before installation.

Dual 2.5GbE and PCIe expansion

Two 2.5GbE ports support 2.5G, 1G, 100M and 10M speeds, with Port Trunking or SMB Multichannel available to accelerate transfers and backups.

One PCIe Gen 3 x2 slot supports compatible 5GbE or 10GbE network cards and QM2 expansion cards.

One Type-A USB 3.2 Gen 2 port provides up to 10Gbps connectivity.
Three USB 2.0 ports are also listed.
Wake on LAN and Jumbo Frame support are included.

Short-depth chassis and redundant power

The 2U chassis measures 88.6 × 432 × 297.4mm and is designed for smaller cabinets and depth-constrained installations.

Two 300W power supply units with 100240V input provide a redundant power design.

Supplied deployment examples include factories, small offices, surveillance rooms, audiovisual rooms and in-vehicle applications.
The supplied information states planned product availability and support up to 2031.
Maximum concurrent CIFS connections are listed as 1,500 with maximum memory installed.

Important purchasing and deployment notes

The supplied information does not identify whether storage drives are included; confirm the configured package.
The detailed supplied specifications identify a 2U short-depth chassis with eight SATA bays and two rear E1.S/M.2 NVMe slots.
The processor is specified only as an Intel 4-core model.
Confirm compatibility for E1.S/M.2 media, rail hardware, network cards and QM2 cards.

Frequently asked questions

What is the QNAP TS-h1065eU-RP-8G?

It is a 2U short-depth QuTS hero NAS with eight front SATA bays, two rear E1.S/M.2 NVMe slots, dual 2.5GbE and redundant power.

Are storage drives included?

The supplied information does not identify whether drives are included, so the configured package should be confirmed before purchase.

Which drives are supported?

The front bays support compatible 3.5-inch SATA hard drives and 2.5-inch SATA solid state drives, while the rear slots support E1.S and M.2 NVMe SSDs.

Which processor is installed?

The supplied specifications identify an Intel 4-core, 64-bit x86 processor but do not provide a more specific model.

How much memory is installed and supported?

It includes 8GB SODIMM DDR5 memory and supports up to 16GB using one 16GB module.

How are the drive positions arranged?

It has eight front 3.5-inch SATA bays and two rear E1.S/M.2 NVMe Gen 3 x1 slots.

Which network ports are included?

It includes two 2.5GbE ports supporting 2.5G, 1G, 100M and 10M speeds.

Can 5GbE or 10GbE be added?

Yes. The supplied specifications list optional 5GbE and 10GbE through compatible network adapters or a PCIe expansion card.

Which operating system is installed?

The supplied product information identifies the ZFS-based QuTS hero operating system.

How deep is the chassis?

The 2U short-depth chassis measures 297.4mm deep.

Does it include redundant power supplies?

Yes. The supplied specifications list two 300W power supply units.

What manufacturer warranty applies?

The supplied specifications list a three-year QNAP manufacturer warranty.

(TS-h1065eU-RP-8G)

Features and highlights

Key capabilities below are organised from the supplied product information for TS-h1065eU-RP-8G.

Eight SATA plus two NVMe slots

Eight front bays and two rear E1.S/M.2 positions support flexible storage configuration.

297.4mm short-depth 2U

The compact chassis supports rack installations with limited depth.

8GB DDR5 memory

Installed memory supports expansion to a maximum of 16GB.

Dual 2.5GbE networking

Port Trunking or SMB Multichannel can accelerate transfers and backups.

PCIe Gen 3 x2 expansion

Compatible 5GbE, 10GbE and QM2 cards can be installed.

Redundant 300W power

Two power supply units help reduce interruption risk from a single power-unit failure.

Important: Drive inclusion is not identified in the supplied data. Confirm compatibility for E1.S/M.2 media, rail hardware, network adapters and QM2 expansion cards.

TS-h1065eU-RP-8G specifications

Specifications below are organised from the supplied QNAP product information for TS-h1065eU-RP-8G.

Processor and Memory

CPU	Intel 4-core processor
CPU Architecture	64-bit x86
Encryption Engine	Yes (AES-NI)
Hardware-Accelerated Transcoding	Yes
System Memory	8GB SODIMM DDR5
Maximum Memory	16GB (1 x 16GB)
Memory Slot	1 x SODIMM DDR5

Storage

Drive Bays	Front: 8 x 3.5-inch Rear: 2 x E1.S/M.2 NVMe Gen3 x1 slots
Drive Compatibility	3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA solid state drives E1.S/M.2 slots: E1.S NVMe SSD M.2 NVMe SSD
Hot-Swappable	Yes
M.2 Slot	Optional via a PCIe adapter
SSD Cache Acceleration Support	Yes

Networking

2.5 Gigabit Ethernet	2 x ports (2.5G/1G/100M/10M)
5 Gigabit Ethernet	Optional via network adaptor
10 Gigabit Ethernet	Optional via network adaptor Optional via PCIe expansion card
Wake on LAN	Yes
Jumbo Frame	Yes

Expansion and Connectivity

PCIe Slot	1 x PCIe Gen3 x2 Slot 1: PCIe Gen 3 x2 Card dimensions for PCIe slot 1: 210 x 68.9 x 18.76mm / 8.27 x 2.71 x 0.74 inches.
USB 2.0 Ports	3
USB 3.2 Gen 2 Port	1 x Type-A USB 3.2 Gen 2 (10Gbps)

Physical Specifications

Form Factor	2U short-depth rackmount
LED Indicators	HDD 1-8, E1.S/M.2 1-2, status, LAN, expansion and power
Buttons	Power and reset
Dimensions (H x W x D)	88.6 x 432 x 297.4mm
Net Weight	9.21kg
Gross Weight	10.71kg

Power and Cooling

Power Supply Unit	300W x 2, 100-240V
Power Consumption: Disk Standby Mode	31.742W
Power Consumption: Operating Mode, Typical	55.83W Tested with drives fully populated.
Fan	3 x 60mm, 12VDC
System Warning	Buzzer

Environmental

Operating Temperature	0-40 °C (32 °F-104 °F)
Storage Temperature	-20-70 °C (-4 °F-158 °F)
Relative Humidity	5-95% RH non-condensing, wet bulb: 27 °C (80.6 °F)

Warranty and Connections

Standard Warranty	3 years
Maximum Concurrent CIFS Connections	1500 with maximum memory installed

SKU	TS-h1065eU-RP-8G
Brand	QNAP
Shipping Weight	14.0000kg
Shipping Width	0.150m
Shipping Height	0.350m
Shipping Length	0.500m
Shipping Cubic	0.026250000m3

3 YearsQNAP manufacturer warranty

3-year QNAP manufacturer warranty

The supplied specifications list a 3-year standard manufacturer warranty for the QNAP TS-h1065eU-RP-8G.

Warranty coverage, eligibility and claim assessment are subject to QNAPs applicable warranty terms. Please retain your DeviceDeal tax invoice as proof of purchase.
