Zebra DS3678-XR Rugged Cordless 2D Scanner
Model # DS3678-XR6F003VZWW
-
SKU: DS3678-XR6F003VZWW
Don't pay: $1,590.86
$1,281.00
SAVE $309.86 (19%)
- Pick Up Available
- Australian Warranty
- Checkout Securely
Zebra DS3678-XR Ultra-Rugged Cordless Extended-Range 2D Scanner FIPS
An Industrial Green cordless extended-range area imager with FIPS, a green laser aimer and vibration feedback.
Product overview
Cordless extended-range capture with a high-visibility aimer
The Zebra DS3678-XR6F003VZWW is identified as a cordless, FIPS-enabled extended-range area imager with an SE58 engine, Industrial Green finish, green laser aimer and vibration motor.
The supplied page states capture of 1D, 2D, paper and mobile barcodes from less than 2 in./5 cm to over 105 ft./32 m. IntelliFocus and PRZM Intelligent Imaging are named in the source.
The ruggedness wording states 10 ft./3 m drops to concrete, 7,500 tumbles and dual IP65/IP68 sealing. The green aimer is described as visible throughout the decode range indoors and up to 10 ft./3 m in direct sunlight.
Product details
Technical specifications
| Supplied product information | |
|---|---|
| Brand | Zebra |
| SKU | DS3678-XR6F003VZWW |
| Product model | DS3678-XR |
| Product type as supplied | Cordless extended-range area imager |
| Scan engine | SE58 |
| Scanning capability | 1D and 2D, including paper and mobile barcodes |
| Reading range as supplied | Less than 2 in. / 5 cm to over 105 ft. / 32 m |
| Aimer | High-visibility green laser aimer |
| Aimer visibility statement | Up to seven times more visible than a red aiming dot |
| Direct-sunlight aimer visibility | Up to 10 ft. / 3 m, as stated |
| Drop specification | 10 ft. / 3 m to concrete |
| Tumble specification | 7,500 tumbles |
| Ingress protection | Dual IP65/IP68, as supplied |
| FIPS | Yes |
| Feedback | Vibration motor |
| Colour | Industrial Green |
Helpful answers
Frequently asked questions
Is this identified as cordless?
Yes. Cordless is stated in the supplied product identification.
What range is listed?
Less than 5 cm to over 32 m is stated.
What ruggedness details are supplied?
The page states 3 m drops, 7,500 tumbles and dual IP65/IP68 sealing.
Why is the scan engine wording flagged?
The source calls the product an area imager but separately uses the phrase laser scan engine.
(DS3678-XR6F003VZWW)
- Laser scan engine guarantees rapid error free data entry
- Wireless connectivity gives you the adaptability to transmit barcode data to your smart devices
- Bluetooth technology - Allows compatibility with most of your smart devices
Network & Communication
| Bluetooth | Yes |
Technical Information
| Connectivity Technology | Wireless |
| Features | Vibration |
| Notification LED | |
| Diagnostic Reporting | |
| Data Parser | |
| Data Formatter | |
| Beep | |
| Scanning Distance | 32 m |
| Light Source | Laser |
| Scanner Range | Extended Range |
| Scan Pattern | Area |
| Image Sensor Type | Imager |
| Illumination Type | LED |
| Scan Mode | Trigger |
| Illumination Color | White |
| Scan Engine Model | SE58 |
| Scanning Capability | 1D |
| 2D | |
| Field of View (Horizontal) | 42° |
| Field of View (Vertical) | 27° |
| Reading Angle (Skew) | 60° |
| Reading Angle (Pitch) | 60° |
| Reading Angle (Roll) | 360° |
| Maximum Ambient Light | 107639 lux |
| Minimum Print Contrast | 25% |
| Minimum Element Resolution (Code 39) | 0.13 mm |
| Maximum Element Resolution (Code 39) | 2.54 mm |
| Minimum Element Resolution (DataMatrix) | 0.25 mm |
| Maximum Element Resolution (DataMatrix) | 5.08 mm |
| Air Electrostatic Discharge (+/-) | 25kV |
Battery Information
| Battery Chemistry | Lithium Ion (Li-Ion) |
| Battery Capacity | 3100 mAh |
General Information
| Product Type | Barcode Scanner |
| Manufacturer Part Number | DS3678-XR6F003VZWW |
| Manufacturer Website Address | http://www.zebra.com/ap/en.html |
| Manufacturer | Zebra Technologies Corporation |
| Product Model | DS3678-XR |
| Product Name | DS3600 DS3678-XR Barcode Scanner |
| Product Series | 3600 |
| Brand Name | Zebra |
Miscellaneous
| Application/Usage | Manufacturing |
| Outdoor | |
| Warehouse | |
| Industrial | |
| Inventory | |
| Self-checkout | |
| Ingress Protection (IP) Rating | IP65 |
| IP68 |
Physical Characteristics
| Weight (Approximate) | 410 g |
| Durability | Dust Proof |
| Water Proof | |
| Height | 185.4 mm |
| Width | 76.2 mm |
| Depth | 142.2 mm |
| Product Color | Industrial Green |
| Color Family | Green |
| Rugged | Yes |
| SKU | DS3678-XR6F003VZWW |
| Brand | ZEBRA |
| Shipping Weight | 0.5000kg |
| Shipping Width | 0.108m |
| Shipping Height | 0.090m |
| Shipping Length | 0.215m |
