40m USB reach
Extend a USB 1.1 device up to 40m (131ft) over a direct Cat5e-or-better UTP cable.
StarTech 1 Port USB over Cat5 / Cat6 Extender - USB110EXT2
Model # USB110EXT2
-
SKU: USB110EXT2
- Pick Up Available
- Australian Warranty
- Checkout Securely
StarTech.com | USB110EXT2
StarTech 1-Port USB 1.1 over Cat5/Cat6 Extender
Extend one USB 1.1 connection up to 40 m over direct Cat5e-or-better cabling without an external power adapter or software installation.
40m extensionUSB 1.1 up to 12MbpsNo external power
Key features at a glance
Direct, product-specific information to help confirm whether this model fits the intended setup.
Bus-powered remote unit
The efficient design can provide up to 300mA remotely when the host supplies 500mA.
Driverless setup
The extender is OS independent and requires no additional driver or software.
ESD protection
The official specification lists 8kV contact and 16kV air electrostatic-discharge protection.
Australian version with official 3 Years warranty
Supplied by DeviceDeal and covered by the official StarTech.com manufacturer warranty in Australia. Retain your DeviceDeal tax invoice; coverage and claims are subject to StarTech.com warranty terms, eligibility requirements and product assessment.
Frequently asked questions
Quick answers based on the supplied product information and specifications.
What does the StarTech USB110EXT2 do?
It extends one USB 1.1 connection up to 40m over direct Cat5e-or-better cabling.
What data rate is supported?
It supports USB 1.1 full-speed bandwidth up to 12Mbps.
Does it work through a network switch?
No. The Cat5e/Cat6 cable is a direct point-to-point link between the two extender units, not an IP network connection.
Does it need external power?
No. It is powered by the host USB port.
How much power is available remotely?
Up to 300mA is stated when the host supplies 500mA.
Does it require a driver?
No. It is OS independent and requires no additional software.
What cabling is required?
Use a direct Cat5e UTP or better cable up to 40m.
What warranty applies in Australia?
The Australian-version product supplied by DeviceDeal is covered by a three-year official StarTech.com manufacturer warranty in Australia, subject to StarTech.com terms, eligibility and product assessment.
(USB110EXT2)
Features and highlights
StarTech USB110EXT2
40m USB reach
Extend a USB 1.1 device up to 40m (131ft) over a direct Cat5e-or-better UTP cable.
Bus-powered remote unit
The efficient design can provide up to 300mA remotely when the host supplies 500mA.
Driverless setup
The extender is OS independent and requires no additional driver or software.
ESD protection
The official specification lists 8kV contact and 16kV air electrostatic-discharge protection.
- One USB 1.1 port
- Up to 12Mbps bandwidth
- Integrated USB cables
- Local and remote RJ45 connections
Warranty confidence: Australian-version product with a 3 years official StarTech.com manufacturer warranty in Australia, subject to StarTech.com terms and assessment.
Technical specifications
StarTech USB110EXT2 specifications organised from the supplied product data.
Warranty Information
| Warranty | 3 Years |
|---|
Hardware
| Ports | 1 |
|---|---|
| Cabling | Cat5e UTP or better |
| ESD Protection | 8kV contact; 16kV air |
Performance
| Maximum Data Transfer Rate | 12Mbps |
|---|---|
| Maximum Distance | 40m [131ft] |
| Remote Power | Up to 300mA when 500mA is supplied by the host |
Connector(s)
| Local Unit | 1 × RJ45; 1 × USB Type-A USB 1.1 |
|---|---|
| Remote Unit | 1 × RJ45; 1 × USB Type-A USB 1.1 |
Software
| OS Compatibility | OS independent; no additional drivers or software required |
|---|
Special Notes / Requirements
| Requirements | Available USB port; direct Cat5e UTP or better cable |
|---|
Power
| Power Source | USB-powered; no external adapter required |
|---|
What's in the Box
| Included in Package | 1 × local extender; 1 × remote extender; integrated USB cables; documentation |
|---|
| SKU | USB110EXT2 |
| Barcode # | 65030847896 |
| Brand | STARTECH |
| Shipping Weight | 0.0900kg |
| Shipping Width | 0.100m |
| Shipping Height | 0.050m |
| Shipping Length | 0.120m |
| Shipping Cubic | 0.000600000m3 |
Australian version and official StarTech.com warranty
This is the Australian-version product supplied by DeviceDeal and is covered by the official StarTech.com manufacturer warranty in Australia for 3 years.
Please retain the DeviceDeal tax invoice as proof of purchase. Warranty coverage and claims are subject to StarTech.com warranty terms, eligibility requirements and product assessment.
