StarTech.com · LP4SATAFM6IN

StarTech LP4SATAFM6IN 6in SATA Power to LP4 Adapter Cable

6in SATA Power to LP4 Adapter Cable designed for professional IT, electronics, security or workstation use.

Quick answer: LP4SATAFM6IN powers an IDE drive or other LP4 device from a SATA power connector over a 6in cable.

Best forShort internal connections where a SATA-equipped power supply must power a compatible LP4 device.

Check before orderingConfirm the source is a SATA 15-pin power connector and the target device uses LP4 4-pin power; this cable does not carry data.

Answers before you buy

Frequently asked questions

What is StarTech LP4SATAFM6IN?

It is a internal SATA-to-LP4 power adapter that powers an IDE drive or other LP4 device from a SATA power connector over a 6in cable.

Which connections or mounting method are provided?

One SATA power 15-pin connection to one LP4 4-pin large-drive power connection

What performance is specified?

Passive power adaptation over a 152.4mm / 6in cable

How is the product constructed?

Black straight-connector PVC cable using 18AWG conductors

What is the cable length?

The cable is 152.4mm / 6in long.

Is it a data cable?

No. It adapts power only and does not provide a SATA data path.

What should be checked before ordering?

Confirm the source is a SATA 15-pin power connector and the target device uses LP4 4-pin power; this cable does not carry data.

What warranty applies?

LP4SATAFM6IN carries a StarTech.com limited lifetime manufacturer warranty, subject to the manufacturers terms and eligibility requirements.

Planning a broader setup? Browse the DeviceDeal buying guides.

(LP4SATAFM6IN)

Features & highlights

Why choose LP4SATAFM6IN?

?Purpose-built designOne SATA power 15-pin connection to one LP4 4-pin large-drive power connection

?Specified performancePassive power adaptation over a 152.4mm / 6in cable

?Professional constructionBlack straight-connector PVC cable using 18AWG conductors

?Key capabilityProvides a short, tidy route from SATA power to an LP4-powered device.

?Deployment advantageTAA-compliant adapter operates without drivers or software.

?Order with confidenceConfirm the source is a SATA 15-pin power connector and the target device uses LP4 4-pin power; this cable does not carry data.

Compatibility reminder: Confirm the source is a SATA 15-pin power connector and the target device uses LP4 4-pin power; this cable does not carry data.

StarTech LP4SATAFM6IN 6in SATA Power to LP4 Adapter Cable product image

Technical specifications

LP4SATAFM6IN specifications

Exact-model specifications for compatibility checking. Measurements may be rounded.

Warranty Information
Warranty	Lifetime
Connectors
Connector A	1 × SATA power 15-pin
Connector B	1 × LP4 4-pin large-drive power
Hardware
Cable Jacket	PVC
Wire Gauge	18AWG
Environmental
Operating Temperature	-20°C to 80°C
Storage Temperature	-20°C to 80°C
Physical Characteristics
Colour	Black
Connector Style	Straight
Cable Length	152.4mm / 6in
Product Dimensions	150 × 32 × 7mm
Product Weight	13g
Packaging Information
Package Dimensions	130 × 127 × 14mm
Package Weight	26g
What's in the Box
Included	6in SATA-to-LP4 power adapter, female/male

Sources: https://www.devicedeal.com.au/startech-6in-sata-to-lp4-power-cable-adapter-f-m and https://www.startech.com/

SKU	LP4SATAFM6IN
Barcode #	65030841627
Brand	Startech
Shipping Weight	0.0200kg
Shipping Width	0.100m
Shipping Height	0.050m
Shipping Length	0.110m
Shipping Cubic	0.000550000m3

Manufacturer warranty

Lifetime

This Australian-version product is supplied by DeviceDeal and is covered by the limited lifetime manufacturer warranty term listed for this exact product.

Keep your DeviceDeal tax invoice as proof of purchase.
Coverage is subject to StarTech.com warranty terms, eligibility and product assessment.
Warranty service does not replace rights that may apply under Australian Consumer Law.
