NETGEAR WAC510 AC WiFi Business Access Point (WAC510)

with NETGEAR® Insight app for easy management

The NETGEAR® AC WiFi Business Access Point WAC510 delivers high performance with high client density for enterprises requiring ubiquitous and reliable wireless for all business applications. The WAC510 is managed by NETGEAR Insight app, for a more intuitive and innovative support, with no need for extra management hardware. The WAC510 features Multi-User MIMO (MU-MIMO) to achieve aggregate speeds up to 1.2 Gbps, option to configure as Router or Access Point modes, and comes with two Ethernet ports, including a Power-over-Ethernet (PoE) 1Gb port. WAC510 comes with lifetime limited warranty, and 24/7 support including lifetime chat.


Simple to manage with NETGEAR Insight App

  • Simple setup in minutes from NETGEAR Insight app
  • Centralized configuration and monitoring with complete visibility
  • No extra hardware required
  • QR code initial configuration for instant installation


Superior performance with 802.11ac Wave 2

  • Dual band concurrent operation between 2.4GHz and 5GHz frequency ranges
  • Maximum performance with multi-gigabit throughput (up to 1.2 Gbps)
  • Multi-User MIMO enable concurrent wireless transmit and receive with multiple clients
  • Improves coverage for multiple users in dense environment


Flexible seployment with Power over Ethernet and accessories

  • Standard based 802.3af Power over Ethernet (PoE)
  • Router mode for single device for small office
  • Access Point mode for multiple WAC510 for mid-size office environment
  • Ceiling and wall mount for ease of placement


Maximized security with all-in-one device

  • Business-class wireless security include WPA and WPA2
  • MAC based Access List for device specific security
  • Rogue Access Point detection to avoid network security compromises
  • Lifetime warranty for a peace of mind


Netgear WAC510 Dual Band Wireless-AC Business Access Point - IEEE 802.11ac, IEEE 802.11g, IEEE 802.11b, IEEE 802.11a - 2.4GHz and 5GHz concurrent operation - 300Mbps (2.4GHz), 867Mbps (5GHz) - Internal Antenna Gain: 3 dBi (2.4 GHz) / 6 dBi (5 GHz) - 2x WAN/LAN 10/100/1000BASE-T Gigabit Ethernet RJ-45 ports with Auto Uplink (Auto MDI-X) with WAN port supporting IEEE 802.3af or 802.3at Power over Ethernet - Limited Lifetime Warranty


Product Number
Product Thumbnail
  • IEEE 802.11ac specification
  • IEEE 802.11ac 2.0 specification
  • IEEE 802.11g
  • IEEE 802.11b
  • IEEE 802.11a
Frequency Band
  • 2.4GHz and 5GHz concurrent operation
Maximum Theoretical Throughput
  • 300Mbps (2.4GHz)
  • 867Mbps (5GHz)
Maximum Number of Clients
  • 200
Deployment options
  • Standalone
  • Netgear Insight app management
Access Point
  • Internal Antenna Gain: 3 dBi (2.4 GHz) / 6 dBi (5 GHz)
Advanced Wireless
  • WDS Point-to-point wireless bridge mode
  • WDS Point-to-multipoint wireless bridge mode
  • WiFi Protected Access Pre-shared Key (WPA-PSK, WPA2-PSK)
  • MAC Address filtering
  • 4 BSSIDs per Radio
  • Yes
Routing Function
  • Yes
802.11e WMM
  • (Wireless multimedia mode) for QoS
Simultaneous Bridge/Client Association
  • Yes
  • Power adapter (not included): 12V DC, 2.5A;
  • Power consumption: 9.3W
Physical Specifications
  • Dimensions (L x W x H): 7.75 x 7.75 x 1.45in (197.32 x 197.32 x 37mm)
  • Weight: 555.5g (1.22lb)
  • Desktop standable
  • Ceiling and wall mountable (mount included)
Physical Interfaces
  • Two (WAN/LAN) 10/100/1000BASE-T Gigabit Ethernet (RJ-45) ports with Auto Uplink (Auto MDI-X) with WAN port supporting IEEE 802.3af or 802.3at Power over Ethernet
  • Six (6) LED: Power, Link/ACT, LAN1, LAN2, 2.4 GHz, 5 GHz
Default Reset
  • Yes
Operating Temperature
  • 32° to 104°F (0° to 40°C)
Storage Temperature
  • -4° to 158°F (-20° to 70°C)
Operating Relative Humidity
  • 10-90%
Storage Humidity
  • 5-95%
  • @ 25°C > 978,210 Hours
Package Contents
  • AC WiFi Business Access Point (WAC510)
  • Wall/ceiling mount kit
  • Installation guide
Safety Certification
  • FCC, CE (EN60950)
Optional Support
  • PMB0351: 5 years OnCall 24x7
  • PMB0331: 3 years OnCall 24x7
  • PMB0311: 1 year OnCall 24x7
Product Ordering Information
  • WAC510-100NAS
  • WAC510-10000S


Barcode # 606449119824
Brand Netgear
Shipping Weight 0.8800kg
Shipping Width 0.230m
Shipping Height 0.070m
Shipping Length 0.226m
Shipping Cubic 0.003639000m3
Manufacturer Warranty
Limited Product Lifetime Warranty
Manufacturer Contact Info
(02) 8117 6800
