CyberPower UPS RT33020KE RT33 3-Phase rackmount 20KVA/20KW
Model # RT33020KE
-
SKU: RT33020KE
- Pick Up Available
- Australian Warranty
- Checkout Securely
UPS Systems (3-Phase) RT33020KE
Overview
CyberPower RT33020KE guarantees power backup protection for IT equipment such as FTTx devices, networking devices and NAS/storage devices. The product adopts double conversion online topology, and it is typically integrated in the back office, server room, and data center environment. With integrated IGBT technology and intelligent DSP-based control, the RT33 UPS produces less input total harmonic distortion (THDi), achieving higher power efficiency. The system also intelligently controls the whole process of the charging and discharging, effectively improving the life time of the battery. The system can be configured to 3-in/3-out or 3-in/1-out according to the users' needs. The product is of rack modular design, compatible with 19” standard rack cabinet. Its 5.5” touchscreen color LCD with graphic display provides more information and is easier for customer to operate. The LCD display can also be configured to vertical or horizontal display through LCD setting.
Features
- Three-phase Design
- ECO Mode
- Flexible System Configuration
- Rack Modular Design
- Color LCD Panel
- Dual Inputs
- Generator Compatible
- Battery Cold Start
- SNMP/HTTP Remote Management Capability (Optional)
- Extended Battery Module (EBM)
- Online (Double Conversion) UPS Topology
- High Density Design
- High Output Power Factor
- Rack/Tower Convertible Configurations
- LCD Touch Panel
- UPS Parallel Expansion
- Pure Sine Wave Output
- Smart Battery Management (SBM)
- PowerPanel Management Software
What's in the Box
- RT33020KE
- Rackmount Rail
- Rackmount Ears
- Rail Kit
- Power Cord
- User's Manual
* Product contents may vary according to different regions. For detailed information, please refer to user's manual/quick start guide.
(RT33020KE)
Online Double-conversion Topology
The UPS adopts online double-conversion topology to provide the best power quality regardless of the conditions of incoming power. This topology also features a zero transfer time, ensuring optimal system operation.
ECO Mode
When the quality of utility power is good, the UPS switches to ECO mode to increase system efficiency. When the quality is unstable, the UPS switches to line mode to guarantee the best power quality.
High Density Design
The high-capacity UPS provides reliable and high-quality battery backup in a compact design, significantly optimizing space in a rack enclosure.
High Output Power Factor
The UPS’s output power factor is 1, which means that more critical devices with higher amount of total watts can be powered by the UPS, utilizing more loads efficiently.
Flexible System Configuration
Users can achieve flexible configuration with the system, which can be configured to 3-in/3-out and 3-in/1-out, making it convenient to customize IT solutions based on different needs.
Rack Modular Design
The product is compatible with 19” standard rack cabinet, which makes it convenient to be integrated with servers and data centers.
Color LCD with Touch Panel
The color LCD with touch panel is designed with friendly, intuitive, and graphical user-interface, allowing users to monitor power system and configure settings by simply touching the screen.
Dual Input Design
By allowing users to connect one input from AC power source and the second input from other power source, the dual power input design ensures high quality power and system continuity for connected equipment.
UPS Parallel Expansion
The UPS parallel expansion capability allows users to flexibly expand system capacity by connecting multiple UPS units, thus protecting more equipment.
Generator Compatible
Power continuity can be achieved with generators during a power outage. When UPS is running on generator's power, it can stabilize unstable voltages from the generator while providing reliable power.
Extended Battery Module (EBM)
The UPS can connect to extended battery modules (EBM) to prolong system runtime during power interruption. The EBM comes with plug-n-play DC connectors and supports EBM expansion, ensuring system's maximum power availability.
Smart Battery Management
The UPS adopts Smart Battery Management (SBM) technology to manage the battery charging process by using a 3-cycle approach and temperature compensation, which efficiently extends the battery lifespan.
Remote Management Capability
Remote management capability enables monitoring and controlling of devices through Remote Management Card. Users can also perform management tasks, such as scheduled shutdowns and reboots.
PowerPanel Business Software
The PowerPanel Management Software can perform power management and system graceful shutdown. This software has achieved VMware Ready™ status, and is compatible with VMware ESXi. It also supports Citrix XenServer and Microsoft Hyper-V.
General
Input
Line to Line (L-L): 228 ~ 478 Vac
Line to Line (L-L): 380 ~ 435 Vac
60 ± 3
Output
60 ± 0.1
Battery
Surge Protection & Filtering
Management & Communications
Physical
Physical Size - UPS Module
Shipping Dimensions
Environmental
Certifications
Special Features
| SKU | RT33020KE |
| Barcode # | 4712856275759 |
| Brand | CYBERPOWER |
| Shipping Weight | 34.0000kg |
Manufacturer Warranty
