Eaton SKU 5S550AU

Eaton 5S550AU 550VA/330W Line-Interactive Tower UPS

The Eaton 5S550AU is a 5S Series line-interactive UPS identified as 550VA / 330W in the supplied product name, with an Australian 10A input plug and USB connectivity.

The supplied record lists 230V AC input, 230V AC output, tower / under-monitor installation and a black enclosure measuring 250 x 87 x 260mm.

550VA / 330WLine-interactive UPSTower / under-monitor2-year warrantyDeviceDeal authorised Eaton reseller

Eaton 5S550AU 550VA/330W Line-Interactive Tower UPS

Product overview

Power rating

The supplied record lists 550VA / 330W.

Australian connection

The structured specification lists an Australian 10A plug and a USB interface.

Installation format

The supplied form factor is tower / under-monitor, with an approximate weight of 4.96kg.

Source review: Confirm the required outlet arrangement, connected load and runtime for the intended equipment before purchase.

Frequently asked questions

What capacity is listed for the Eaton 5S550AU?

The supplied rating information is 550VA / 330W.

Does this UPS include USB connectivity?

Yes. The structured specification lists USB.

Which input plug is listed?

The source lists an Australian 10A plug.

What warranty is supplied?

The source lists a two-year limited Eaton manufacturer warranty.

(5S550AU)

Features

Eaton 5S550AU 550VA/330W Line-Interactive Tower UPS

Power and connectivity

Line-interactive topology
Rating: 550VA / 330W
Input voltage: 230V AC
Output voltage: 230V AC
Australian 10A plug

Battery, management and protection

USB interface
Automatic battery test
Deep-discharge protection
Cold-start capable
Replaceable batteries
Half-load runtime: 12 minutes
Full-load runtime: 4 minutes
Dataline protection: RJ-45; RJ-11
Protection types: Over-voltage; brownout; sag; surge; power failure

Physical and environmental

Tower / under-monitor
Black finish
Dimensions (H x W x D): 250mm x 87mm x 260mm
Approximate weight: 4.96kg
Maximum operating temperature: 40°C
Sound emission: 40dB(A)

Confirm outlet configuration and runtime requirements for the intended connected load.

Technical specifications

Eaton 5S550AU 550VA/330W Line-Interactive Tower UPS

Product details
Brand	Eaton
Model / SKU	5S550AU
Series	5S
Product type	Line-interactive UPS
Product-name rating	550VA / 330W
Structured load capacity	550VA / 330W
Power and connections
Power rating	550VA / 330W
Input voltage	230V AC
Output voltage	230V AC
Input plug	Australian 10A
USB	Yes
Output current	10A
Battery and runtime
Battery management	Automatic battery test; deep-discharge protection; cold-start capable; replaceable batteries
Backup time at half load	12 minutes
Backup time at full load	4 minutes
Protection and environment
Dataline protection	RJ-45; RJ-11
Protection types	Over-voltage; brownout; sag; surge; power failure
Maximum operating temperature	40°C
Sound emission	40dB(A)
Physical properties
Form factor	Tower / under-monitor
Height	250mm
Width	87mm
Depth	260mm
Approximate weight	4.96kg
Product colour	Black
Standards and package
Certifications and standards	IEC/EN 62040-1; IEC/EN 62040-2; CB Report; CE Mark
Package contents	5S 550VA tower UPS; USB cable

SKU	5S550AU
Barcode #	743172436276
Brand	EATON
Shipping Weight	5.9300kg
Shipping Width	0.320m
Shipping Height	0.160m
Shipping Length	0.330m
Shipping Cubic	0.016896000m3

Warranty information

Eaton 5S550AU 550VA/330W Line-Interactive Tower UPS

2-Year Limited Eaton Manufacturer Warranty

DeviceDeal is an authorised Eaton reseller. This product is covered by a two-year limited Eaton manufacturer warranty in Australia, as listed in the supplied product information.
