Eaton SKU 9PX3000IRT3UANZ

Eaton 9PX3000IRT3UANZ 3000VA/3000W Online 3U Rack/Tower UPS

The Eaton 9PX3000IRT3UANZ 9PX is a single-phase online double-conversion UPS rated at 3000VA / 3000W in a 3U rack/tower format.

The supplied record lists multilingual graphical lcd display, USB HID and serial connectivity, with the rail kit included.

3000VA / 3000WOnline double conversion3U rack/towerEaton Manufacturer Warranty Source ReviewDeviceDeal authorised Eaton reseller

Product overview

3000VA / 3000W

The structured load capacity is 3000VA / 3000W.

Online double conversion

The supplied source classifies this model as a double-conversion online UPS.

3U rack/tower installation

The structured form factor is rack/tower with a listed rack height of 3U.

Source review: The supplied warranty column states two years, while the structured specification lists a three-year limited warranty. Both source values are preserved and require confirmation.

Frequently asked questions

What capacity is listed for the Eaton 9PX3000IRT3UANZ?

The structured specification lists 3000VA / 3000W.

Which output connections are listed?

The structured field lists 8 x IEC C13 10A; 2 x IEC C19 16A.

Which monitoring interfaces are listed?

The source lists multilingual graphical lcd display, USB HID and a serial port.

What warranty is supplied?

The supplied warranty column states two years, while the structured specification states three years; confirmation is required.

(9PX3000IRT3UANZ)

Features

Eaton 9PX3000IRT3UANZ 3000VA/3000W Online 3U Rack/Tower UPS

Power performance

Online double-conversion topology
Single phase
3000VA / 3000W

Connections and monitoring

Description input: 16A input required
Structured input: IEC 60320 C20 16A
Structured outputs: 8 x IEC C13 10A; 2 x IEC C19 16A
Multilingual graphical LCD display
USB HID
Serial port

Installation and support

3U rack/tower
Dimensions (H x W x D): 130mm x 440mm x 485mm
Approximate weight: 27.40kg
Rail kit: Included

Confirm the source-review notes, connected load and installation requirements before purchase.

Technical specifications

Eaton 9PX3000IRT3UANZ 3000VA/3000W Online 3U Rack/Tower UPS

Product details
Brand	Eaton
Model / SKU	9PX3000IRT3UANZ
Series	9PX
Product type	Double-conversion online UPS
Phase	Single phase
Status display	Multilingual graphical LCD display
Power
Load capacity	3000VA / 3000W
Input-voltage values listed	230V AC
Output-voltage values listed	200V AC; 208V AC; 220V AC; 230V AC; 240V AC
Input-voltage range	176276V AC
Input frequency	70Hz
Output frequency	60Hz
Connections
Input stated in description	16A input required
Structured plug / connector	IEC 60320 C20 16A
Structured receptacle detail	8 x IEC C13 10A; 2 x IEC C19 16A
Serial port	Yes
USB HID-compliant port	Yes
Battery
Hot swappable	Yes
External battery cabinets	4
Environment and additional fields
Sound emission	40dB
Maximum operating temperature	40°C
ENERGY STAR	Yes
Certification	TÜV
Physical properties
Form factor	Rack / tower
Rack height	3U
Height	130mm
Width	440mm
Depth	485mm
Approximate weight	27.40kg
Applications listed
Application / usage	CCTV camera; POS terminal; server; gate; storage

SKU	9PX3000IRT3UANZ
Barcode #	743172081391
Brand	EATON
Shipping Weight	34.7000kg
Shipping Width	0.028m
Shipping Height	0.076m
Shipping Length	0.058m

Warranty information

Eaton 9PX3000IRT3UANZ 3000VA/3000W Online 3U Rack/Tower UPS

Eaton Manufacturer Warranty Source Review

DeviceDeal is an authorised Eaton reseller. This product is supplied under the applicable Eaton manufacturer warranty in Australia. The supplied source contains conflicting warranty durations for SKU 9PX3000IRT3UANZ: the warranty column states 2 years while the structured specification states 3 years. Please contact DeviceDeal to confirm the applicable period and conditions before publication or purchase.
