Lithium-ion battery
The structured source identifies lithium-ion battery chemistry and a hot-swappable battery design.
Eaton 9PX Li-Ion 3000VA/2400W 230V On Line 2U Rack/Tower UPS - 9PX3000IRTANZ-L
Model # 9PX3000IRTANZ-L
-
SKU: 9PX3000IRTANZ-L
- Pick Up Available
- Australian Warranty
- Checkout Securely
Eaton SKU 9PX3000IRTANZ-L
Eaton 9PX3000IRTANZ-L 3000VA/2400W Lithium-Ion 2U Online UPS
The Eaton 9PX3000IRTANZ-L 9PX is a 3000VA / 2400W online double-conversion UPS with lithium-ion battery technology in a 2U rack/tower format.
The source lists 1 x IEC C20 16A input, 8 x IEC C13 10A outputs and 2 x IEC C19 16A outputs, adjustable 200/208/220/230/240V output, RS-232 serial, USB and a communication-card slot.
3000VA / 2400WLithium-ion battery2U rack/tower5-year warrantyDeviceDeal authorised Eaton reseller
Product overview
3000VA / 2400W
The structured load capacity is 3000VA / 2400W. The description also states 3000W with EBM.
2U rack/tower deployment
The supplied form factor is 2U rack/tower, with communications and network-management options listed in the specifications.
Source review: The structured load capacity is 3000VA / 2400W, while the description additionally states 3000W with EBM. Both statements are preserved and the conditional power claim requires confirmation.
Frequently asked questions
What power rating is listed for the Eaton 9PX3000IRTANZ-L?
The structured rating is 3000VA / 2400W; the description additionally states 3000W with EBM.
Which battery chemistry is supplied?
The structured specification lists lithium-ion battery chemistry.
Which power connections are listed?
The source lists 1 x IEC C20 16A input and 8 x IEC C13 10A outputs and 2 x IEC C19 16A outputs.
What warranty is supplied?
The source lists a five-year Eaton manufacturer warranty.
(9PX3000IRTANZ-L)
Features
Eaton 9PX3000IRTANZ-L 3000VA/2400W Lithium-Ion 2U Online UPS
Power and battery
- Online double conversion
- 3000VA / 2400W
- Lithium-ion battery
- Hot-swappable battery
Connections and management
- 1 x IEC C20 16A input
- 8 x IEC C13 10A outputs and 2 x IEC C19 16A outputs
- RS-232 serial
- USB HID
- Communication-card slot
- Network management: Modbus RTU; Modbus TCP
Installation and environment
- 2U rack/tower
- 86.5 x 440 x 605mm
- Approximate weight: 22.80kg
- 40dB sound emission
- 40°C maximum operating temperature
- Five-year warranty
Confirm the conditional power statement in the description before publication or purchase.
Technical specifications
Eaton 9PX3000IRTANZ-L 3000VA/2400W Lithium-Ion 2U Online UPS
| Product details | |
|---|---|
| Brand | Eaton |
| Model / SKU | 9PX3000IRTANZ-L |
| Series | 9PX Lithium-ion |
| Product type | Double-conversion online UPS |
| Phase | Single phase |
| Form factor | Rack / tower |
| Rack height | 2U |
| Load capacity | 3000VA / 2400W |
| Additional description power statement | 3000W with EBM |
| Power and connections | |
| Input voltage | 230V |
| Output-voltage values | 200V AC; 208V AC; 220V AC; 230V AC; 240V AC |
| Input connector | 1 x IEC C20 16A input |
| Output receptacles | 8 x IEC C13 10A outputs and 2 x IEC C19 16A outputs |
| Description input-frequency range | 4770Hz |
| Description output frequency | 50/60Hz autosensing |
| Structured input frequency | 70Hz |
| Structured output frequency | 60Hz |
| Serial port | Yes |
| USB HID-compliant port | Yes |
| Network management | Modbus RTU; Modbus TCP |
| Battery | |
| Battery chemistry | Lithium ion |
| Hot swappable | Yes |
| Half-load runtime | 21 minutes |
| Full-load runtime | 10.5 minutes |
| Typical recharge time | 3 hours |
| Physical and environmental | |
| Height | 86.5mm |
| Width | 440mm |
| Depth | 605mm |
| Approximate weight | 22.80kg |
| Sound emission | 40dB |
| Maximum operating temperature | 40°C |
| ENERGY STAR | Yes |
| Package contents | 9PX lithium-ion UPS; all necessary hardware for rack and tower mounting |
| Applications listed | |
| Application / usage | Edge computing; mining; mission-critical equipment; healthcare; storage; telecommunication; network; data centre; IT infrastructure; virtual platform; server; non-critical device |
| SKU | 9PX3000IRTANZ-L |
| Barcode # | 743172104687 |
| Brand | EATON |
| Shipping Weight | 29.3000kg |
| Shipping Width | 0.024m |
| Shipping Height | 0.077m |
| Shipping Length | 0.058m |
Warranty information
Eaton 9PX3000IRTANZ-L 3000VA/2400W Lithium-Ion 2U Online UPS
5-Year Eaton Manufacturer Warranty
DeviceDeal is an authorised Eaton reseller. This product is covered by a five-year Eaton manufacturer warranty in Australia, as listed in the supplied product information.
