Eaton SKU 9SX2000I-AU

Eaton 9SX2000I-AU 2000VA/1800W Online Tower UPS

The Eaton 9SX2000I-AU is a 9SX online double-conversion tower UPS with a structured load capacity of 2000VA / 1800W.

The supplied record lists 1 x IEC 60320 C14 input, 5 x Australian 10A receptacles; 1 x IEC 60320 C19, a multilingual graphical LCD, USB HID, serial, EPO and SNMP-manageable operation.

2000VA / 1800WOnline double conversionTower UPS2-year warrantyDeviceDeal authorised Eaton reseller

Product overview

2000VA / 1800W

The structured specification lists 2000VA / 1800W. The description separately states 2000VA / 1500W in the description body.

Online double conversion

The source classifies the 9SX as a double-conversion online UPS for network, storage, IT, industrial, medical and telecommunications applications.

Local and remote management

The source lists a multilingual graphical LCD, LED indicators, USB HID, serial, EPO and SNMP-manageable operation.

Source review: The product name and structured load-capacity field state 2000VA / 1800W, while the product-description body states 2000VA / 1500W. Both source values are preserved and require confirmation.

Frequently asked questions

What capacity is listed for the Eaton 9SX2000I-AU?

The structured specification lists 2000VA / 1800W, while the product description also states 2000VA / 1500W in the description body.

Which power connections are listed?

The source lists 1 x IEC 60320 C14 input and 5 x Australian 10A receptacles; 1 x IEC 60320 C19.

Which monitoring interfaces are listed?

The source lists a multilingual graphical LCD, LED indicators, USB HID, a serial port, EPO and SNMP-manageable operation.

What warranty is supplied?

The source lists a two-year Eaton manufacturer warranty.

(9SX2000I-AU)

Features

Eaton 9SX2000I-AU 2000VA/1800W Online Tower UPS

Power protection

9SX online double-conversion topology
Structured rating: 2000VA / 1800W
Description rating: 2000VA / 1500W in the description body
230V AC nominal input
Input range: 140276V AC

Connections and management

1 x IEC 60320 C14 input
5 x Australian 10A receptacles; 1 x IEC 60320 C19
USB HID-compliant port
RS-232 serial port
Emergency power-off port

Installation and environment

Tower form factor
Dimensions (H x W x D): 346mm x 214mm x 412mm
Approximate weight: 33.40kg
Sound emission: 45dB
40°C maximum operating temperature

Review the supplied-source note and confirm the final connected load, input circuit and outlet requirements before purchase.

Technical specifications

Eaton 9SX2000I-AU 2000VA/1800W Online Tower UPS

Product details
Brand	Eaton
Model / SKU	9SX2000I-AU
Series	9SX
Product type	Double-conversion online UPS
Form factor	Tower
Structured load capacity	2000VA / 1800W
Additional description rating	2000VA / 1500W in the description body
Power
Input voltage	230V AC
Input-voltage range	140276V AC
Input frequency field	70Hz
Output frequency field	60Hz
Connections and management
Input connector	1 x IEC 60320 C14 input
Output receptacles	5 x Australian 10A receptacles; 1 x IEC 60320 C19
Serial port	Yes
USB HID-compliant port	Yes
Emergency power-off port	Yes
Network management	SNMP manageable
Status display	LED indicators; multilingual graphical LCD
Physical and environmental
Height	346mm
Width	214mm
Depth	412mm
Approximate weight	33.40kg
Sound emission	45dB
Maximum operating temperature	40°C
Applications listed
Application / usage	Industry; telecommunications; medical; storage; network; IT system

SKU	9SX2000I-AU
Barcode #	743172091161
Brand	EATON
Shipping Weight	33.3000kg
Shipping Width	0.032m
Shipping Height	0.057m
Shipping Length	0.049m

Warranty information

Eaton 9SX2000I-AU 2000VA/1800W Online Tower UPS

2-Year Eaton Manufacturer Warranty

DeviceDeal is an authorised Eaton reseller. This product is covered by a two-year Eaton manufacturer warranty in Australia, as listed in the supplied product information.
