Up to 8K 60Hz
DisplayPort 1.4 video supports 8K 60Hz, plus 5K 60Hz and 4K 120Hz support with compatible source and display hardware.
Startech USB-C to DisplayPort Adapter, 8K 30Hz - CDP2DP14B
Model # CDP2DP14B
-
SKU: CDP2DP14B
- Pick Up Available
- Australian Warranty
- Checkout Securely
StarTech.com · CDP2DP14B
StarTech USB-C to DisplayPort 1.4 Adapter - 8K 60Hz
Add a DisplayPort 1.4 output to a compatible USB-C or Thunderbolt 3 host with a compact adapter supporting up to 8K 60Hz.
DisplayPort 1.4Up to 8K 60HzHBR3 · 32.4GbpsDP Alt Mode
Product overview
CDP2DP14B supports HBR3, HDR, DSC and HDCP 2.2/1.4 for one high-resolution DisplayPort display. It is bus powered and designed for driverless travel or desk use.
Features that matter
Direct USB-C to DisplayPort output
Connect a USB-C DisplayPort Alt Mode host directly to one DisplayPort display through the DisplayPort female port.
Active integrated conversion
Active integrated conversion supports a compact, driverless connection without a separate video converter.
Driverless multi-platform use
Plug-and-play operation supports compatible Windows, macOS, Linux, iPadOS, iOS, ChromeOS and Android systems without additional drivers.
What to know before ordering
Host and display requirements
The USB-C host must support DisplayPort Alt Mode. DisplayPort 1.4 support is required end to end for 8K output.
Resolution depends on the full setup
Maximum resolution and refresh rate require the source, display and DisplayPort 1.4 link to support the stated mode.
Known incompatibility
This adapter does not work with the Samsung Galaxy S8. It has no Power Delivery pass-through.
Warranty confidence in Australia
Australian version · Official StarTech.com warranty
This item is the Australian version supplied by DeviceDeal and is covered by the official 3 years StarTech.com manufacturer warranty in Australia. Retain your DeviceDeal tax invoice as proof of purchase. Coverage and claims are subject to StarTech.com warranty terms, eligibility requirements and product assessment.
Frequently asked questions
What is StarTech CDP2DP14B?
CDP2DP14B is a usb-c to displayport 1.4 adapter for connecting a USB-C DisplayPort Alt Mode host to one DisplayPort display.
What is the maximum resolution?
The verified maximum is 8K 60Hz, with 5K 60Hz and 4K 120Hz support. Actual output depends on the source, display and connection mode.
What must the USB-C port support?
The USB-C host must support DisplayPort Alt Mode. Both source and display must support DisplayPort 1.4 for the highest 8K mode.
Is the connection bidirectional?
No. It is designed for video from a USB-C DP Alt Mode host to a DisplayPort display.
Does it require drivers?
No. It is designed for plug-and-play use with compatible Windows, macOS, Linux, iPadOS, iOS, ChromeOS and Android systems.
Does it support Power Delivery?
No. It does not provide USB-C Power Delivery pass-through.
What is included in the package?
The package contains one USB-C to DisplayPort adapter.
What warranty applies in Australia?
CDP2DP14B is the Australian version supplied by DeviceDeal and is covered by the official 3 years StarTech.com manufacturer warranty in Australia, subject to StarTech.com terms, eligibility and product assessment.
(CDP2DP14B)
Features and highlights
CDP2DP14B key capabilities
Product-specific highlights verified for this exact StarTech.com model.
Up to 8K 60Hz
DisplayPort 1.4 video supports 8K 60Hz, plus 5K 60Hz and 4K 120Hz support with compatible source and display hardware.
Direct USB-C to DisplayPort output
Connect a USB-C DisplayPort Alt Mode host directly to one DisplayPort display through the DisplayPort female port.
Active integrated conversion
Active integrated conversion supports a compact, driverless connection without a separate video converter.
Driverless multi-platform use
Plug-and-play operation supports compatible Windows, macOS, Linux, iPadOS, iOS, ChromeOS and Android systems without additional drivers.
Key highlights
- integrated USB-C lead attached USB-C cable
- DisplayPort 1.4 with HBR3 · 32.4Gbps
- Up to 8K 60Hz
- USB-C host to DisplayPort display
- Official 3 years StarTech.com manufacturer warranty in Australia
Technical specifications
StarTech CDP2DP14B
Verified specifications and package details for the exact model.
General and Connectivity
Product type
USB-C to DisplayPort 1.4 adapter
Direction
USB-C host to DisplayPort display
Connectors
USB-C male to DisplayPort female
Number of displays
1
Warranty
3 Years
UPC
065030883634
Video and Audio
Maximum resolution
7680 x 4320 at 60Hz
Additional verified modes
5K 60Hz; 4K 120Hz; 1080p
Bandwidth
HBR3, up to 32.4Gbps
Video features
HDR; DisplayHDR; Display Stream Compression; HDCP 2.2/1.4
Audio
DisplayPort 7.1-channel audio
Maximum cable distance to display
5m
Power Delivery
No PD pass-through
Hardware and Requirements
Chipset
STM32F072
Host requirement
USB-C DisplayPort Alt Mode
8K requirement
Source and display must support DisplayPort 1.4
Known incompatibility
Samsung Galaxy S8
Driver requirement
No additional driver or software
Physical and Environmental
Colour
Black
Material
Plastic
Product weight
34g
Operating temperature
535°C
Storage temperature
25°C
Humidity
3060% RH
Packaging and In the Box
Package dimensions (W x D x H)
106 x 200 x 22mm
Shipping weight
42g
Package contents
1 x USB-C to DisplayPort adapter
| SKU | CDP2DP14B |
| Barcode # | 65030883634 |
| Brand | Startech |
| Shipping Weight | 0.0400kg |
| Shipping Width | 0.002m |
| Shipping Height | 0.014m |
| Shipping Length | 0.003m |
Official StarTech.com manufacturer warranty
3 Years
This item is the Australian version supplied by DeviceDeal and is covered by the official 3 years StarTech.com manufacturer warranty in Australia. Retain your DeviceDeal tax invoice as proof of purchase. Coverage and claims are subject to StarTech.com warranty terms, eligibility requirements and product assessment.
This warranty statement applies to StarTech CDP2DP14B.
