Up to 4K 60Hz
Supports one DisplayPort display at up to 3840 x 2160 at 60Hz with HBR2 and HDCP 2.2/1.4.
StarTech Use this USB Type-C to DisplayPort adapter to output DP video and charge your laptop using a single USB-C port CDP2DPUCP
Model # CDP2DPUCP
-
SKU: CDP2DPUCP
- Pick Up Available
- Australian Warranty
- Checkout Securely
StarTech.com · CDP2DPUCP
StarTech USB-C to DisplayPort Adapter with 60W Power Delivery
Connect a 4K 60Hz DisplayPort monitor and charge a compatible USB-C laptop through the same port with up to 60W PD.
DisplayPort 1.2Up to 4K 60HzHBR2 · 21.6Gbps60W PD
Product overview
CDP2DPUCP combines HBR2 video, a signal booster and a separate USB-C charging input in a compact adapter. A compatible charger is required for pass-through charging.
Features that matter
Integrated signal booster
The active signal booster supports a DisplayPort cable up to 2m between the adapter and display.
Video with pass-through charging
The separate USB-C power input supports up to 60W pass-through charging with compatible equipment.
Verified compatibility and limits
The USB-C host must support DisplayPort Alt Mode. The adapter has no USB data port, and the charger is not included.
What to know before ordering
Host requirement
The USB-C or Thunderbolt 3 host must support DisplayPort Alt Mode video output.
One-display connection
Connect one DisplayPort display. The adapter is not bidirectional and does not provide an additional USB data connection.
Charging equipment required
A compatible USB-C charger and charging cable are required. The host negotiates the actual charging level.
Warranty confidence in Australia
Australian version · Official StarTech.com warranty
This item is the Australian version supplied by DeviceDeal and is covered by the official 3 years StarTech.com manufacturer warranty in Australia. Retain your DeviceDeal tax invoice as proof of purchase. Coverage and claims are subject to StarTech.com warranty terms, eligibility requirements and product assessment.
Frequently asked questions
What is StarTech CDP2DPUCP?
CDP2DPUCP is a usb-c to displayport 1.2 adapter with power delivery for connecting a USB-C DP Alt Mode host to one DisplayPort display while retaining charging.
What is the maximum resolution?
undefined
What must the USB-C port support?
The USB-C or Thunderbolt 3 host must support DisplayPort Alt Mode video output.
How long can the DisplayPort cable be?
The verified maximum cable distance from the adapter to the display is 2m.
Does it carry audio?
Yes. The verified specification lists up to 7.1-channel audio over DisplayPort.
Does it support Power Delivery?
Yes. It supports up to 60W pass-through charging with compatible charging equipment and a supported host.
What is included in the package?
The package contains one USB-C to DisplayPort adapter.
What warranty applies in Australia?
CDP2DPUCP is the Australian version supplied by DeviceDeal and is covered by the official 3 years StarTech.com manufacturer warranty in Australia, subject to StarTech.com terms, eligibility and product assessment.
(CDP2DPUCP)
Features and highlights
CDP2DPUCP key capabilities
Product-specific highlights verified for this exact StarTech.com model.
Up to 4K 60Hz
Supports one DisplayPort display at up to 3840 x 2160 at 60Hz with HBR2 and HDCP 2.2/1.4.
Integrated signal booster
The active signal booster supports a DisplayPort cable up to 2m between the adapter and display.
Video with pass-through charging
The separate USB-C power input supports up to 60W pass-through charging with compatible equipment.
Verified compatibility and limits
The USB-C host must support DisplayPort Alt Mode. The adapter has no USB data port, and the charger is not included.
Key highlights
- 100mm attached USB-C cable
- HBR2 · 21.6Gbps
- Up to 4K 60Hz
- 7.1-channel DP audio
- Official 3 years StarTech.com manufacturer warranty in Australia
Technical specifications
StarTech CDP2DPUCP
Verified specifications and package details for the exact model.
General and Connectivity
Product type
USB-C to DisplayPort 1.2 adapter with charging
Host connector
USB-C male
Outputs
DisplayPort female; USB-C power input
Attached cable length
100mm
Displays supported
1
Warranty
3 Years
UPC
065030872171
Video and Audio
Maximum resolution
3840 x 2160 at 60Hz
Bandwidth
HBR2, 21.6Gbps
Content protection
HDCP 2.2/1.4
HDR support
No
Audio
DisplayPort 7.1-channel audio
Maximum cable distance to display
2m
Power and Hardware
Power Delivery
Up to 60W pass-through
Chipsets
Pericom PI3DPX1203; VIA/VLI VL100
Host requirement
USB-C DisplayPort Alt Mode
Driver requirement
No additional driver or software
Physical and Environmental
Colour
Black
Material
Plastic
Product dimensions (L x W x H)
187 x 43 x 12mm
Product weight
22g
Operating temperature
040°C
Storage temperature
-2070°C
Humidity
090% RH
Packaging and In the Box
Package dimensions (W x D x H)
173 x 145 x 32mm
Shipping weight
90g
Package contents
1 x USB-C to DisplayPort adapter
| SKU | CDP2DPUCP |
| Barcode # | 65030872171 |
| Brand | STARTECH |
| Shipping Weight | 0.0900kg |
| Shipping Width | 0.100m |
| Shipping Height | 0.050m |
| Shipping Length | 0.170m |
| Shipping Cubic | 0.000850000m3 |
Official StarTech.com manufacturer warranty
3 Years
This item is the Australian version supplied by DeviceDeal and is covered by the official 3 years StarTech.com manufacturer warranty in Australia. Retain your DeviceDeal tax invoice as proof of purchase. Coverage and claims are subject to StarTech.com warranty terms, eligibility requirements and product assessment.
This warranty statement applies to StarTech CDP2DPUCP.
