Technical Speci?cation Main Processor High performace embedded processor Operating System Embedded LINUX OS Screen Type Capacitive screen Display 7-inch TFT screen Resolution 1024 × 600 Video Compression H.264 Audio Compression G.711A/G.711U/PCM Audio Input 1 channel all-direction microphone Audio Output Built-in 1.5W loudspeaker Audio Mode Support dual-way bidirectional talk Audio Enhancement Support echo cancellation/DNR Audio Bit Rate 16 kbps Communication Mode Full digital Information Release Support to receive and view notifications issued by center Leave Videos or Text Messages Support DND Mode Support to set DND period Sub-station Quantity 9 Alarm Input 6 channel (switch quantity) Alarm Output 1 channel Network 1 RJ-45 SOS Alarm Support Casing PC+ABS Appearance Color Appearance Color Power Supply Standard PoE DC 12V 1A Installation Wall mount Accessories Default bracket Default alarm cable Dimensions 119.6 mm × 221.5 mm × 21.5 mm (4.71" × 8.72" × 0.85") Operating Temperature -10°C to +55°C (+14°F to +131°F) Operating Humidity 10%RH-95%RH Power Consumption Standby?4W, work?6W Gross Weight 0.35 Kg (0.77 lb) Power supply mode PoE Storage Support Micro SD, maximum memory capacity 32 G, standard memory capacity 8 G
