Eaton SKU 9SXEBM96T

Eaton 9SXEBM96T 96V Tower Extended Battery Module

The Eaton 9SXEBM96T is a 96V DC tower extended battery module for the listed Eaton 9SX UPS systems.

The supplied record lists Sealed lead-acid, 12V / 9Ah batteries, 16 batteries, approximate 48.70kg weight and compatibility with Eaton 9SX2000I; Eaton 9SX3000I; Eaton 9SX3000IM; Eaton 9SX3000INB; 2000VA and 3000VA 9SX systems.

96V DCTower battery moduleSealed lead-acid, 12V / 9Ah batteries2-year warrantyDeviceDeal authorised Eaton reseller

Eaton 9SXEBM96T 96V Tower Extended Battery Module shown in the supplied second product image

Product overview

96V DC module

The supplied product record identifies 96V DC for this extended battery module.

Model-specific 9SX compatibility

The listed compatible systems are Eaton 9SX2000I; Eaton 9SX3000I; Eaton 9SX3000IM; Eaton 9SX3000INB; 2000VA and 3000VA 9SX systems.

Tower installation

The module uses a tower form factor and measures 346mm x 214mm x 412mm.

Source review: The structured source labels 3kVA as a backup/run-time value. Because kVA is not a duration, the value is retained under its original field label and is not presented as a runtime claim.

Frequently asked questions

What battery specification is listed for the Eaton 9SXEBM96T?

96V DC; Sealed lead-acid, 12V / 9Ah batteries; quantity 16.

Which UPS systems are listed as compatible?

The supplied source lists Eaton 9SX2000I; Eaton 9SX3000I; Eaton 9SX3000IM; Eaton 9SX3000INB; 2000VA and 3000VA 9SX systems.

What form factor is listed?

The supplied record identifies a free-standing tower extended battery module.

What warranty is supplied?

The source lists a two-year Eaton manufacturer warranty.

(9SXEBM96T)

Features

Eaton 9SXEBM96T 96V Tower Extended Battery Module

Battery

96V DC
Sealed lead-acid, 12V / 9Ah batteries
Battery quantity: 16
Extended battery module

Compatibility

Eaton 9SX2000I
Eaton 9SX3000I
Eaton 9SX3000IM
Eaton 9SX3000INB
2000VA and 3000VA 9SX systems

Physical and support

Tower form factor
346mm x 214mm x 412mm
Approximate weight: 48.70kg
Two-year manufacturer warranty

Confirm the exact UPS model, battery connector and installation space before purchase.

Technical specifications

Eaton 9SXEBM96T 96V Tower Extended Battery Module

Product details
Brand	Eaton
Model / SKU	9SXEBM96T
Series	9SX
Product type	Battery unit / extended battery module
Form factor	Tower
Battery
Output / battery voltage	96V DC
Battery specification stated	Sealed lead-acid, 12V / 9Ah batteries
Battery quantity	16
Backup / run-time field in structured source	3kVA
Compatibility
Compatible Eaton 9SX systems	Eaton 9SX2000I; Eaton 9SX3000I; Eaton 9SX3000IM; Eaton 9SX3000INB; 2000VA and 3000VA 9SX systems
Physical properties
Height	346mm
Width	214mm
Depth	412mm
Approximate weight	48.70kg

SKU	9SXEBM96T
Barcode #	743172091178
Brand	EATON
Shipping Weight	48.7000kg
Shipping Width	0.033m
Shipping Height	0.057m
Shipping Length	0.049m

Warranty information

Eaton 9SXEBM96T 96V Tower Extended Battery Module

2-Year Eaton Manufacturer Warranty

DeviceDeal is an authorised Eaton reseller. This product is covered by a two-year Eaton manufacturer warranty in Australia, as listed in the supplied product information.
