Eaton SKU 9PXEBM48RT2U

Eaton 9PXEBM48RT2U 48V Extended Battery Module

The Eaton 9PXEBM48RT2U is an external 48V DC sealed lead-acid battery unit for extending supported Eaton 9PX UPS runtime.

The supplied record lists 9000mAh capacity, a rail kit, approximate 29.80kg weight and compatibility with Eaton 9PX1000IRT2UANZ and 9PX1500IRT2UANZ systems, plus the 9PX1500ITM marine model.

48V DC9000mAhSealed lead-acidRail kit includedDeviceDeal authorised Eaton reseller

Eaton 9PXEBM48RT2U 48V Extended Battery Module

Product overview

48V DC battery module

The structured source lists 48V DC output, 9000mAh battery capacity and sealed lead-acid chemistry.

Supported 9PX systems

Compatibility is listed for 9PX1000IRT2UANZ, 9PX1500IRT2UANZ and the 9PX1500ITM marine UPS system.

Rack installation

The description states that a rail kit is included; the listed dimensions are 86.5 x 440 x 450mm.

Source review: The supplied compatibility field is model-specific. Confirm the exact UPS model and battery-module connection before ordering.

Frequently asked questions

What battery type is used in the Eaton 9PXEBM48RT2U?

The supplied specification lists a sealed lead-acid battery with 9000mAh capacity and 48V DC output.

Which UPS models are listed as compatible?

The source lists Eaton 9PX1000IRT2UANZ, 9PX1500IRT2UANZ and 9PX1500ITM marine systems.

Is a rail kit included?

Yes. The supplied description states that the rail kit is included.

What warranty is supplied?

The source lists a two-year Eaton manufacturer warranty.

(9PXEBM48RT2U)

Features

Eaton 9PXEBM48RT2U 48V Extended Battery Module

Battery

48V DC output
9000mAh capacity
Sealed lead-acid chemistry
External battery unit

Compatibility

Eaton 9PX1000IRT2UANZ
Eaton 9PX1500IRT2UANZ
Eaton 9PX1500ITM marine UPS

Installation

Rail kit included
86.5 x 440 x 450mm
Approximate weight: 29.80kg
ENERGY STAR listed

Confirm UPS-model compatibility, available rack space and battery-module connection requirements before purchase.

Technical specifications

Eaton 9PXEBM48RT2U 48V Extended Battery Module

Product details
Brand	Eaton
Model / SKU	9PXEBM48RT2U
Product type	Battery unit / extended battery module
ENERGY STAR	Yes
Battery
Battery chemistry	Lead acid
Battery characteristics	Sealed
Output voltage	48V DC
Battery capacity	9000mAh
Compatibility
9PX UPS systems	9PX1000IRT2UANZ; 9PX1500IRT2UANZ
Marine UPS system	9PX1500ITM
Physical properties
Height	86.5mm
Width	440mm
Depth	450mm
Approximate weight	29.80kg
Rail kit	Included, as stated in the description

SKU	9PXEBM48RT2U
Barcode #	743172081650
Brand	EATON
Shipping Weight	35.0000kg
Shipping Width	0.023m
Shipping Height	0.058m
Shipping Length	0.055m

Warranty information

Eaton 9PXEBM48RT2U 48V Extended Battery Module

2-Year Eaton Manufacturer Warranty

DeviceDeal is an authorised Eaton reseller. This product is covered by a two-year Eaton manufacturer warranty in Australia, as listed in the supplied product information.
