Critical Power, Cooling and Racks > Uninterruptible Power Supply (UPS) > Network and Server > APC Smart-UPS Battery Systems > SRT192RMBP

APC Smart-UPS On-Line SRT External Battery Pack, 3U Rack, 192Vdc

SKU: SRT192RMBP | Brand: APC Brand

Key Features

<a>Replacement battery (1)</a> is available
Battery pack for Smart-UPS On-line SRT series
Ideal for critical Smart-UPS applications
Predictable and consistent runtime performance
Graceful unattended shutdown of servers and workstations
Peace of mind with 2-year battery warranty

Description

This product is part of the Smart-UPS battery systems, providing extended runtime to SRT mission critical applications.
This extendable-run battery pack provides extended runtime during prolonged power outages.
Embedded monitoring at the cell, module, and cabinet level provides data of battery runtime and health.
It is a lead-acid battery with a 2-year warranty.
Its dimensions are 683mm (depth) x 432mm (height) x 130mm (width) and weighs 91.0kg.
Ideal for Smart-UPS on-line mission critical applications.
It conforms to OSHPD.

Product Images

Downloads & Documents

Compatible Products & Accessories

Mounting

SRTRK2

APC Smart-UPS SRT 19 inch Rail Kit for Smart-UPS SRT 5/6/8/1...

SRTRK3

APC Smart-UPS SRT 2 Post Mounting Rail Kit for Smart-UPS SRT

Replacement battery

APCRBC140

APC Replacement Battery Cartridge for Smart-UPS On-Line, 192...

UPS

SRT5KRMXLW-HW

APC Smart-UPS On-Line, 5kVA, Rackmount 3U, 208V/230V, Hard w...

(SRT192RMBP)

Specifications - SRT192RMBP

Overview

Lead time

Usually in Stock

Main

Product or component type	External battery pack
Number of rack unit	3U
Battery type	Lead-acid battery
Provided equipment	Installation guide Warranty card Rack mounting brackets
Range of product	Smart-UPS Battery Systems

Batteries & Runtime

Number of battery free slots	0
Number of battery filled slots	0
Device mounting	Stand alone battery stack
Battery voltage	192 V
Number of battery replacement quantity	2
Replacement battery	APCRBC140

Physical

Colour	Black
Height	130 mm
Width	432 mm
Depth	682.7 mm
Net weight	91 kg
Mounting mode	Rack-mounted
Two post mountable	1

Output

Battery capacity

10 Ah

Conformance

Standards

OSHPD

Environmental

Ambient air temperature for operation	0…40 °C
Operating altitude	0...10000 ft
Relative humidity	0…95 % non-condensing
Ambient air temperature for storage	-15…45 °C
Storage altitude	0…15240 m
Storage Relative Humidity	0…95 % non-condensing

Packing Units

Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Height	43.000 cm
Package 1 Width	60.000 cm
Package 1 Length	98.000 cm
Package 1 Weight	223.500 kg
Unit Type of Package 2	PAM
Number of Units in Package 2	2
Package 2 Height	57.000 cm
Package 2 Width	100.000 cm
Package 2 Length	120.000 cm
Package 2 Weight	460.000 kg
