StarTech.com · HD2DP

Active HDMI to DisplayPort Adapter, 4K 30Hz

Connect an HDMI source to a DisplayPort monitor or projector with an active USB-powered adapter supporting up to 4K 30Hz.

HDMI inputDisplayPort output4K 30HzUSB powered

StarTech HD2DP Active HDMI to DisplayPort Adapter, 4K 30Hz

Built for dependable use

HDMI-to-DisplayPort conversion

Connects an HDMI computer, player or camera to a DisplayPort display.

Ultra HD output

Supports resolutions up to 3840 × 2160 at 30Hz and remains compatible with lower-resolution displays.

High-refresh Full HD

Supports 1920 × 1080 at up to 120Hz when the source and display support it.

USB-powered operation

Uses USB power and requires no external AC adapter or additional driver.

What to know before you connect

Signal direction is HDMI source to DisplayPort display only.
The adapter does not support HDCP 2.2.
Maximum 4K refresh rate is 30Hz.
A USB power connection is required.

Australian version with official warranty

Supplied by DeviceDeal and covered by the official StarTech.com 2 years manufacturer warranty in Australia. Keep your DeviceDeal tax invoice as proof of purchase; coverage is subject to StarTech.com terms, eligibility and product assessment.

Helpful StarTech video

Frequently asked questions

What does the StarTech HD2DP do?

It converts an HDMI source signal for connection to a DisplayPort monitor or projector.

What connections does the HD2DP provide?

It has an HDMI input, DisplayPort output and USB power connection.

What is the maximum verified performance?

It supports up to 3840 × 2160 at 30Hz, 1920 × 1200, and 1920 × 1080 at up to 120Hz.

How is the HD2DP powered?

It is USB powered and includes a 2ft USB extension cable; no AC adapter is required.

What compatibility should I check?

It works from an HDMI source to a DisplayPort display and carries up to 7.1-channel audio without extra drivers.

Does the HD2DP support HDCP 2.2 or reverse conversion?

No. It does not support HDCP 2.2, and it converts HDMI source output to a DisplayPort display only.

What is included in the package?

The package includes one HDMI-to-DisplayPort adapter and one 2ft USB extension cable.

What warranty applies in Australia?

The Australian-version HD2DP supplied by DeviceDeal is covered by a 2 years official StarTech.com manufacturer warranty in Australia, subject to StarTech.com terms and assessment.

Not sure this is the right product for your setup? Visit the DeviceDeal Buying Guides.

(HD2DP)

Features and highlights

HDMI-to-DisplayPort conversion

Connects an HDMI computer, player or camera to a DisplayPort display.

Ultra HD output

Supports resolutions up to 3840 × 2160 at 30Hz and remains compatible with lower-resolution displays.

High-refresh Full HD

Supports 1920 × 1080 at up to 120Hz when the source and display support it.

USB-powered operation

Uses USB power and requires no external AC adapter or additional driver.

Audio pass-through

Carries up to 7.1-channel surround audio through the DisplayPort output.

Key highlights

Active MegaChips STDP2600 conversion
Plug-and-play installation
2ft USB extension cable included
Compact 25.5cm total length

Official StarTech.com 2 years manufacturer warranty in Australia.

Technical specifications

StarTech HD2DP · Active HDMI to DisplayPort Adapter, 4K 30Hz

Warranty Information

Warranty

2 Years

Hardware

Adapter Type

Active

AV Input

HDMI

AV Output

DisplayPort

Audio

Yes

Chipset ID

MegaChips - STDP2600

Performance

Maximum Digital Resolution

3840 × 2160

Supported Resolutions

3840 × 2160 at 30Hz; 1920 × 1200; 1920 × 1080 at 120Hz; 1280 × 720

Audio

7.1-channel surround sound

Widescreen Support

Yes

Connectors

Input

1 × HDMI male

Output

1 × DisplayPort female

System Requirements and Notes

HDCP Limitation

HDCP 2.2 is not supported

Direction

HDMI source to DisplayPort display only

Power

Power Source

USB Powered

Input Voltage

5V DC

Output Voltage

5V DC

Environmental

Operating Temperature

0°C to 45°C

Storage Temperature

-10°C to 70°C

Humidity

10%85% RH

Physical Characteristics

Colour

Black

Product Length

10.0in [25.5cm]

Product Width

0.9in [2.3cm]

Product Height

0.5in [1.3cm]

Weight

2.5oz [70g]

Packaging Information

Quantity

Package Length

5.6in [14.3cm]

Package Width

6.9in [17.4cm]

Package Height

1.3in [3.3cm]

Shipping Weight

4.0oz [114g]

What's in the Box

Included

1 × HDMI-to-DisplayPort adapter

Included

1 × 2ft USB extension cable
