ATEN PSS PP v3.0 Secure KVM Switch (CS1184H) is specifically designed to meet the stringent security requirement of secure defense and intelligence installations. ATEN PSS PP v3.0 Secure KVM Switch (CS1184H) is compliant with PSS PP v3.0 (Protection Profile for Peripheral Sharing Switch, Version 3.0) standard certified by the National Information Assurance Partnership (NIAP).

ATEN PSS PP v3.0 Secure KVM Switch (CS1184H) provides isolation between computer sources and peripherals while sharing a single keyboard, mouse, monitor, speaker set, and Common Access Card (CAC) reader between connected computers of various security classifications. Compliance with PSS PP v3.0 ensures peripheral sharing capabilities provide maximum user data security when switching port focus, preventing unauthorized data flows or leakage between connected sources. Key protections include isolation and unidirectional data flow, restricted peripheral connectivity and filtering, user data protection, configurable device filtering and management, and always-on tamper-proof design, keeping sensitive assets isolated and providing advanced security and a user friendly design for instantly secure deployment.

With multi-layered security, ATEN PSS PP v3.0 Secure KVM Switch (CS1184H) ensures high-level desktop security and data safekeeping for applications such as government agencies, finance, and other organizations that often handle sensitive or confidential data on separate networks.

Package Contents

  • 1x CS1184H 4-Port USB HDMI Secure KVM Switch
  • 1x Power Cord
  • 1x User Instructions

(CS1184H-AT-U)

Computer Connections4
Port SelectionPushbutton
Connectors
Console Ports2 x USB Type-A Female (Black)
1 x 6-pin Mini-DIN Female (Purple)
1 x 6-pin Mini-DIN Female (Green)
1 x HDMI Female (Black)
1 x Mini Stereo Jack Female (Green; front panel)
KVM Ports8 x USB Type-B Female (White)
4 x HDMI Female (Black)
4 x Mini Stereo Jack Female (Green)
Power1 x 3-prong AC Socket
USB CAC Port1 x USB Type-A Female (White; front panel)
Switches
Port Selection4 x Pushbuttons
Reset1 x Semi-recessed Pushbutton
Power1 x Rocker
LEDs
Power1 (Blue)
Online / Selected (KVM Port)4 (Orange)
Online / Selected (CAC Port)4 (Green)
Video1 (Green)
Key Lock3 (Green)
Emulation
Keyboard / MouseUSB
VideoMax. 3840 x 2160 @ 30 Hz (UHD); 1920 x 1080 (FHD)
Maximum Input Power Rating100–240V~; 50-60 Hz; 1A
Power ConsumptionAC110V:3W:33BTU
AC220V:3.1W:34BTU
Environmental
Operating Temperature0-50°C
Storage Temperature-20-60°C
Humidity0 - 80% RH, Non-condensing
Physical Properties
HousingMetal
Weight1.76 kg ( 3.88 lb )
Dimensions (L x W x H)33.50 x 16.43 x 4.40 cm
(13.19 x 6.47 x 1.73 in.)
NoteFor some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.

SKU CS1184H-AT-U
Barcode # 4719264646546
Brand ATEN
Shipping Weight 1.0000kg
Manufacturer Warranty: 2 Years Manufacturer Warranty
