StarTech.com | SV431DPUA2

4-port DisplayPort 1.2 KVM with 4K 60Hz

Switch up to four DisplayPort computers through one 4K 60Hz DisplayPort monitor, with USB 2.0 peripheral sharing, 7.1 digital audio and 3.5 mm stereo audio.

DisplayPort 1.24K 60HzUSB 2.0 hub3-year warranty

StarTech SV431DPUA2 4-port DisplayPort 1.2 KVM with 4K 60Hz

Key capabilities

4K 60Hz output

Supports up to 3840 × 2160 at 60Hz on one DisplayPort display.

Integrated USB 2.0 hub

Share two additional USB peripherals alongside the keyboard and mouse.

Full audio support

Supports 7.1 HD digital audio with compatible equipment plus 3.5 mm stereo audio.

Push-button and hotkeys

Select computers from the front panel or with keyboard hotkey commands.

What to know before buying

This is a single-monitor KVM. Its shared peripheral hub is USB 2.0, not USB 3.x. The product description states that Mac systems can be used with the required Mini DisplayPort adapter where applicable.

Australian version and manufacturer warranty

3-year StarTech.com manufacturer warranty. This SV431DPUA2 is the Australian version supplied by DeviceDeal and is covered by the official StarTech.com 3-year manufacturer warranty in Australia. Retain your DeviceDeal tax invoice as proof of purchase. Warranty coverage and claims are subject to StarTech.com warranty terms, eligibility requirements and product assessment.

Frequently asked questions

How many computers can SV431DPUA2 control?

Up to four computers.

How many monitors are supported?

One DisplayPort monitor.

What maximum resolution is supported?

Up to 3840 × 2160 4K at 60Hz.

What DisplayPort version is this KVM designed around?

The product is specified as a DisplayPort 1.2 KVM switch.

Does it include a USB hub?

Yes. It includes a USB 2.0 hub for sharing two additional peripherals.

Does it support audio?

Yes. It supports compatible 7.1 HD digital audio and separate 3.5 mm stereo audio.

Does it need drivers?

No. The supplied specification lists OS-independent operation with no software or drivers required.

What warranty applies in Australia?

The Australian version supplied by DeviceDeal is covered by the official StarTech.com 3-year manufacturer warranty in Australia, subject to StarTech.com terms and product assessment.

(SV431DPUA2)

Features and highlights

4K 60Hz output

Supports up to 3840 × 2160 at 60Hz on one DisplayPort display.

Integrated USB 2.0 hub

Share two additional USB peripherals alongside the keyboard and mouse.

Full audio support

Supports 7.1 HD digital audio with compatible equipment plus 3.5 mm stereo audio.

Push-button and hotkeys

Select computers from the front panel or with keyboard hotkey commands.

Key highlights

4K 60Hz output
Integrated USB 2.0 hub
Full audio support
Push-button and hotkeys

Warranty confidence

3-year manufacturer warranty
Official StarTech.com manufacturer warranty in Australia for this DeviceDeal-supplied Australian version, subject to StarTech.com warranty terms and product assessment.

Specifications

Technical specifications for StarTech SV431DPUA2. Values and conditions are organised from the supplied exact-product information and verified exact-SKU StarTech source where required.

Warranty Information

Warranty	3 Years

Connector(s)

Console Interface(s)	3.5 mm Mini-Jack (3 Position) Female DisplayPort (20 pin) Female USB Type-A (4 pin) USB 2.0 Female USB Type-A (4 pin; HID Port) USB 1.1 Female
Host Connectors	3.5 mm Mini-Jack (3 Position) Female DisplayPort (20 pin) Female USB B (4 pin) Female

Environmental

Humidity	0% ~ 40%
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-10°C to 60°C (14°F to 140°F)

Hardware

Audio	Yes
Cables Included	No
Daisy-Chain	No
KVM Ports	4
Number of Monitors Supported	1
PC Interface	USB
PC Video Type	DisplayPort
Rack-Mountable	Optional
U Height	1U

Indicators

LED Indicators	Green - Online indicator (One LED per port) Power Red - Select indicator (One LED per port)

Packaging Information

Package Height	87 mm [3.4 in]
Package Length	40.9 cm [16.1 in]
Package Width	21.2 cm [8.3 in]
Shipping (Package) Weight	1.6 kg [3.5 lb]

Performance

Auto Scan	3, 8, 15 & 30 seconds
Hot-Key Selection	Yes
IP Control	No
Maximum Data Transfer Rate	480 Mbps (USB 2.0)
Maximum Digital Resolutions	3840 x 2160 (Ultra HD 4K) @ 60hz
Maximum Number of Users	1
MTBF	138327 hours
On-Screen Display	No
Port Selection Support	Push Button and Hotkeys
Wide Screen Supported	Yes

Physical Characteristics

Color	Black
Enclosure Type	Steel
Product Height	4.5 cm [1.8 in]
Product Length	22 cm [8.7 in]
Product Width	13.1 cm [5.2 in]
Weight of Product	1 kg [2.3 lb]

Power

Center Tip Polarity	Positive
Input Current	0.6 A
Input Voltage	100 - 240 AC
Output Current	1.5 A
Output Voltage	12 DC
Plug Type	M
Power Consumption (In Watts)	18 W
Power Source	AC Adapter Included

Software

OS Compatibility	OS independent: No software or drivers required

What's in the Box

Included in Package	foot pads KVM switch quick-start guide universal power adapter (NA/JP, EU, UK, ANZ)

SKU	SV431DPUA2
Barcode #	65030826372
Brand	STARTECH
Shipping Weight	1.6000kg
Shipping Width	0.210m
Shipping Height	0.090m
Shipping Length	0.412m
Shipping Cubic	0.007787000m3
