StarTech.com SV231TDPU34K

2-port triple-monitor DisplayPort KVM with 4K 60Hz on three displays

Control two triple-DisplayPort computers across three 4K 60Hz displays, with USB 5Gbps peripheral sharing, HDR, HDCP 2.2, USB emulation and audio switching.

3 DisplayPort monitors4K 60Hz on all 3USB 5Gbps hub2-year warranty

StarTech SV231TDPU34K triple-monitor DisplayPort 4K60 KVM switch

Key capabilities

Triple 4K 60Hz displays

Drives three DisplayPort 1.2 monitors at up to 3840×2160 60Hz.

HDR and HDCP 2.2

Supports high-quality digital imaging and protected-content workflows.

USB 5Gbps peripheral hub

Two shared high-speed USB ports complement dedicated HID connections.

USB emulation and hotkeys

Helps reduce switching delays while supporting front-panel and keyboard host selection.

What to know before buying

To use all three monitors, each computer needs the appropriate three DisplayPort outputs. The desired 4K60/HDR modes also require compatible displays and cabling.

Australian version and manufacturer warranty

This item is the Australian version supplied by DeviceDeal and is covered by the official StarTech.com 2-year manufacturer warranty in Australia.

Please retain your DeviceDeal tax invoice as proof of purchase. Warranty coverage and claims are subject to StarTech.com warranty terms, eligibility requirements and product assessment.

Frequently asked questions

How many computers can SV231TDPU34K control?

Two.

How many monitors are supported?

Three DisplayPort monitors.

What maximum resolution is supported?

3840×2160 4K at 60Hz on all three displays.

What DisplayPort revision is listed?

DisplayPort 1.2.

Does it support HDR and HDCP 2.2?

Yes.

What USB peripheral speed is supported?

USB 3.2 Gen 1 / 5Gbps.

Which USB hub chipset is used?

Genesys Logic GL3523.

What warranty applies in Australia?

The Australian version supplied by DeviceDeal is covered by the official StarTech.com 2-year manufacturer warranty in Australia, subject to StarTech.com terms and product assessment.

(SV231TDPU34K)

Features and highlights

Triple 4K 60Hz displays

Drives three DisplayPort 1.2 monitors at up to 3840×2160 60Hz.

HDR and HDCP 2.2

Supports high-quality digital imaging and protected-content workflows.

USB 5Gbps peripheral hub

Two shared high-speed USB ports complement dedicated HID connections.

USB emulation and hotkeys

Helps reduce switching delays while supporting front-panel and keyboard host selection.

3 DisplayPort monitors
4K 60Hz on all 3
USB 5Gbps hub
2-year warranty

Warranty confidence: Official StarTech.com 2-year manufacturer warranty in Australia, subject to StarTech.com terms and assessment.

Specifications

Verified specifications for StarTech SV231TDPU34K.

Warranty Information

Warranty	2 Years

Hardware

KVM Ports	2
Monitors Supported	3
PC Video Type	DisplayPort 1.2
PC Interface	USB 3.2 Gen 1 5Gbps
USB Peripheral Hub	2 × USB-A 5Gbps
USB HID Ports	4
Chipset ID	Genesys Logic GL3523
TAA Compliant	Yes

Performance

Maximum Digital Resolution	3840 × 2160 @ 60Hz on all three displays
HDR	Yes
HDCP	2.2
USB Emulation	Yes
Port Selection	Push Button and Hotkeys
Auto Scan	3 / 8 / 15 / 30 seconds

Audio

DisplayPort Digital Audio	5.1-channel and 2-channel
Analogue Audio	3.5mm stereo

Power

Output	12V DC / 3A
Power Consumption	36W

SKU	SV231TDPU34K
Barcode #	65030881784
Brand	STARTECH
Shipping Weight	1.4200kg
Shipping Width	0.190m
Shipping Height	0.090m
Shipping Length	0.240m
