PowerShield SAFEGUARD 1000VA/600W - PSG1000
Model # PSG1000
-
SKU: PSG1000
- Pick Up Available
- Australian Warranty
- Checkout Securely
SAFEGUARD
1000VA | 600W
The PowerShield SafeGuard UPS Series remains one of the most popular UPS choices for workstations, telephone systems and security applications. Both the 750VA and 1000VA models are line interactive, simulated sinewave UPS that provides automatic voltage regulation, battery backup and surge protection in a convenient, wall mountable compact design.
FEATURES
HOT SWAPPABLE BATTERY
Easy hot swappable, user replaceable battery that extends the service life of your UPS.
OFF-MODE CHARGING
SafeGuard UPS will continue to charge internal batteries whether the unit is on or off.
WALL MOUNTABLE / FREESTANDING STYLE
The SafeGuard Series are designed in a parallelogram style that is ideal for physically restricted areas and can be conveniently wall mounted.
AUTOMATIC VOLTAGE REGULATION (AVR)
The AVR automatically regulates fluctuations and unstable fluctuating utility voltages, bringing it within 10% of normal wall voltage and avoiding unnecessary battery drain.
COLD START FUNCTION
SafeGuard UPS can turn on equipment when there is no AC, simplifying powering equipment and turning the UPS on. This is useful when there is a blackout or brownout.
INBUILT BATTERY MANAGEMENT (ABM)
Plug and play on any computer or NAS/CCTV. Allows for orderly shutdown without software installation.
EXCEPTIONAL SURGE PROTECTION
SafeGuard UPS offers best in class surge protection.
USB CHARGING PORT
The SafeGuard 1000 features a 1A USB charging port for mobile devices.
Applications include:
- Small Office & home office equipment
- Small server powerstation
- Modems/routers
- Telephony systems
- Point of sale equipment
(PSG1000)
SAFEGUARD RANGE SELECTION GUIDE
| MODEL | SAFEGUARD 1000 |
|---|---|
| Model Number | PSG1000 |
| Capacity | 1000VA / 600W |
| Topology | Line Interactive |
| INPUT | |
| Voltage | 240VAC (Nominal) |
| Voltage Range | 161–286VAC (auto sensing) |
| Frequency Range | 50Hz (auto sensing) |
| OUTPUT | |
| Output Voltage | 240VAC ± 10% |
| Frequency Range (Batt. Mode) | 50Hz ± 0.5% / 1% |
| Transfer Time | 2–6ms (Typical) |
| Waveform (Batt. Mode) | Simulated Sine Wave |
| Australian Outlets – UPS & Surge Protection | 4 |
| Australian Outlets – Surge Protection | 2 |
| BATTERY | |
| Battery Type | Battery: Mains, Low Battery Mode, Fault |
| Typical Recharge Time | 8–9 hours recover to 90% capacity |
| PROTECTION | |
| Full Protection | Discharge, Overcharge, short circuit and thermal protection |
| Surge Protection | 470Joules / 6500Amps |
| COMMUNICATIONS & MANAGEMENT | |
| Interface – Standard Communications | HID AC Mode, Battery Mode, Low Battery, Overload, Fault |
| Software | NetGuard® supports – Windows®, Linux, Unix and Mac (Free Download) |
| PHYSICAL | |
| Dimension L x W x H (mm) | 340 x 204 x 148 |
| Net Weight (kgs) | 8.2 |
| OPERATING ENVIRONMENT | |
| Humidity | 0–90% non-condensing |
| Noise Level | <40dB (1m Test) |
| COMPLIANCE | |
| Safety/EMC | EN62040-1, EN62040-2, EN55 |
| WARRANTY | |
| Standard Warranty | 2 years |
Product specifications are subject to change without prior notice.
| SKU | PSG1000 |
| Barcode # | 9346909001269 |
| Brand | PowerShield |
| Shipping Weight | 6.7000kg |
| Shipping Width | 0.150m |
| Shipping Height | 0.420m |
| Shipping Length | 0.270m |
Manufacturer Warranty: 2 Years Manufacturer Warranty
