Eaton SKU 9SX700I-AU

Eaton 9SX700I-AU 700VA/630W Online Tower UPS

The Eaton 9SX700I-AU is a 9SX online double-conversion tower UPS with a structured load capacity of 700VA / 630W.

The supplied record lists 1 x IEC 60320 C14 input (description writes EC-320-C14), 4 x Australian 10A receptacles, a multilingual graphical LCD, USB HID, serial, EPO and SNMP-manageable operation.

700VA / 630WOnline double conversionTower UPS2-year warrantyDeviceDeal authorised Eaton reseller

Product overview

700VA / 630W

The structured specification lists 700VA / 630W.

Online double conversion

The source classifies the 9SX as a double-conversion online UPS for network, storage, IT, industrial, medical and telecommunications applications.

Local and remote management

The source lists a multilingual graphical LCD, LED indicators, USB HID, serial, EPO and SNMP-manageable operation.

Source review: The description writes the input as EC-320-C14, while the structured connector field states IEC 60320 C14. Both source forms are preserved; confirm the connector specification before publication.

Frequently asked questions

What capacity is listed for the Eaton 9SX700I-AU?

The supplied record lists 700VA / 630W.

Which power connections are listed?

The source lists 1 x IEC 60320 C14 input (description writes EC-320-C14) and 4 x Australian 10A receptacles.

Which monitoring interfaces are listed?

The source lists a multilingual graphical LCD, LED indicators, USB HID, a serial port, EPO and SNMP-manageable operation.

What warranty is supplied?

The source lists a two-year Eaton manufacturer warranty.

(9SX700I-AU)

Features

Eaton 9SX700I-AU 700VA/630W Online Tower UPS

Power protection

9SX online double-conversion topology
Structured rating: 700VA / 630W
230V AC nominal input
Input range: 120276V AC

Connections and management

1 x IEC 60320 C14 input (description writes EC-320-C14)
4 x Australian 10A receptacles
USB HID-compliant port
RS-232 serial port
Emergency power-off port

Installation and environment

Tower form factor
Dimensions (H x W x D): 252mm x 160mm x 357mm
Approximate weight: 11.50kg
Sound emission: 40dB
40°C maximum operating temperature

Review the supplied-source note and confirm the final connected load, input circuit and outlet requirements before purchase.

Technical specifications

Eaton 9SX700I-AU 700VA/630W Online Tower UPS

Product details
Brand	Eaton
Model / SKU	9SX700I-AU
Series	9SX
Product type	Double-conversion online UPS
Form factor	Tower
Structured load capacity	700VA / 630W
Power
Input voltage	230V AC
Input-voltage range	120276V AC
Input frequency field	70Hz
Output frequency field	60Hz
Description frequency	50/60Hz autoselect
Connections and management
Input connector	1 x IEC 60320 C14 input (description writes EC-320-C14)
Output receptacles	4 x Australian 10A receptacles
Serial port	Yes
USB HID-compliant port	Yes
Emergency power-off port	Yes
Network management	SNMP manageable
Status display	LED indicators; multilingual graphical LCD
Physical and environmental
Height	252mm
Width	160mm
Depth	357mm
Approximate weight	11.50kg
Sound emission	40dB
Maximum operating temperature	40°C
Applications listed
Application / usage	IT system; network; storage; industry; medical; telecommunications

SKU	9SX700I-AU
Barcode #	743172090911
Brand	EATON
Shipping Weight	13.9000kg
Shipping Width	0.390m
Shipping Height	0.320m
Shipping Length	0.570m
Shipping Cubic	0.071136000m3

Warranty information

Eaton 9SX700I-AU 700VA/630W Online Tower UPS

2-Year Eaton Manufacturer Warranty

DeviceDeal is an authorised Eaton reseller. This product is covered by a two-year Eaton manufacturer warranty in Australia, as listed in the supplied product information.
