The HDMI® over IP receiver works with the HDMI over IP Extender (ST12MHDLNHK) to distribute HDMI to an additional remote display. You can add multiple receivers (each sold separately) to easily distribute HDMI to multiple locations.

Customize your video distribution with a scalable solution

With additional receivers, you can scale your HDMI over IP kit installation to suit your needs. In a point-to-multipoint setup, you can route HDMI over IP to as many receivers as you need. For additional scalability, you can combine up to 99 different kits (ST12MHDLNHK) to create a multipoint-to-multipoint setup, where you can route different HDMI source signals to different displays. Mounting hardware and IR extenders are included for each transmitter and receiver to ensure tidy, professional installation and hassle-free remote operation.

Get brilliant video at HD 1080p

The receiver maintains your HD video signal, supporting resolutions up to 1080p. Maintaining your HD quality over IP makes it easy to distribute dynamic digital signage throughout your site to attract and engage customers.

Save your network bandwidth with video compression

Unlike some video-over-IP solutions that consume your bandwidth, this HDMI over IP solution uses video compression to distribute high-quality HDMI over your local area network, with minimal bandwidth requirements. Extending your HDMI using compression saves your network resources, avoiding the hassle of a separate video network.

The ST12MHDLNHR is backed by a 2-year StarTech.com warranty and free lifetime technical support.

(ST12MHDLNHR)

Specifications

Warranty Information Warranty 2 Years
Connector(s) 1 - Remote Unit Connectors HDMI (19 pin)
RJ-45
2.5 mm Mini-Jack (3 Position)
Infrared
Environmental Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -10°C to 60°C (14°F to 140°F)
Humidity 0% - 80 %
Hardware Ports 1
Cabling Cat 5e UTP or better
Audio Yes
Rack-Mountable Yes
Daisy-Chain Yes
Indicators 1 - LED Indicators status LED
Packaging Information Shipping (Package) Weight 26.8 oz [758.0 g]
Package Length 9.3 in [23.5 cm]
Package Width 6.1 in [15.5 cm]
Package Height 2.6 in [65.0 mm]
Performance Maximum Cable Length 50.0 ft [15.2 m]
Max Distance 15 m / 50 ft
Maximum Digital Resolutions 1920x1200 (1080p) 60Hz
Supported Resolutions 1920x1200 60Hz
Wide Screen Supported Yes
Audio Specifications 2-channel
Physical Characteristics Color Black
Material Aluminum
Product Length 5.1 in [13.0 cm]
Product Width 3.8 in [97.0 mm]
Product Height 0.9 in [24.0 mm]
Weight of Product 7.5 oz [213.0 g]
Power Power Source AC Adapter Included
Input Voltage 100 - 240 AC
Input Current 0.3 A
Output Voltage 5 DC
Output Current 1 A
Plug Type USB Mini-B (5 pin)
Special Notes / Requirements Note Your router must support IGMP snooping. Please refer to your network switch or router documentation to ensure IGMP snooping is supported and enabled
Each kit requires 6 to 12mbps of local area network bandwidth, when in operation
What's in the Box 1 - Included in Package HDMI over IP receiver
universal power adapter (NA, EU, UK, ANZ)
mounting bracket
CAT5 cables
plastic screwdriver
IR remote control
USB-A to Mini USB-B cable
DB9 to 2.5 mm serial adapter cable
IR receiver
4 - Included in Package rubber feet
1 - Included in Package instruction manual
SKU ST12MHDLNHR
Barcode # 65030879040
Brand Startech
Shipping Weight 0.7000kg
Manufacturer Warranty: 2 Years Limited Warranty
