StarTech Extend HDMI over CAT5/CAT6 cabling to a remote location, with support for 4K 60Hz at 70 m (230 ft.) and 1080p 60Hz at 100 m (328 ft.) ST121HD
Model # ST121HDBT20L
-
SKU: ST121HDBT20L
- Pick Up Available
- Australian Warranty
- Checkout Securely
HDMI over CAT6 extender with 4K 60Hz to 70m
Extend 4K 60Hz HDMI up to 70m or 1080p 60Hz up to 100m over CAT5e/CAT6 with Power over Cable and 7.1 audio support.
Key capabilities
4K 60Hz to 70m
Supports UHD 4K 60Hz up to 230ft / 70m.
1080p to 100m
Supports 1080p 60Hz up to 328ft / 100m.
Power over Cable
Only one power adapter is required for the transmitter/receiver pair.
IR and 7.1 audio
IR accessories and 7.1 surround audio support are included in the exact product scope.
What to know before buying
The maximum distance changes with resolution: 4K 60Hz is specified to 70m, while 1080p 60Hz is specified to 100m.
Australian version and manufacturer warranty
This item is the Australian version supplied by DeviceDeal and is covered by the official StarTech.com 2-year manufacturer warranty in Australia.
Please retain your DeviceDeal tax invoice as proof of purchase. Warranty coverage and claims are subject to StarTech.com warranty terms, eligibility requirements and product assessment.
Frequently asked questions
How far can it extend 4K 60Hz?
How far can it extend 1080p 60Hz?
What cabling is supported?
Does it support Power over Cable?
Does it support 7.1 audio?
Are IR accessories included?
How many power adapters are required?
What warranty applies in Australia?
(ST121HDBT20L)
Features and highlights
4K 60Hz to 70m
Supports UHD 4K 60Hz up to 230ft / 70m.
1080p to 100m
Supports 1080p 60Hz up to 328ft / 100m.
Power over Cable
Only one power adapter is required for the transmitter/receiver pair.
IR and 7.1 audio
IR accessories and 7.1 surround audio support are included in the exact product scope.
- 4K 60Hz to 70m
- 1080p to 100m
- Power over Cable
- 2-year warranty
Specifications
Verified specifications for StarTech ST121HDBT20L.
Warranty Information
| Warranty | 2 Years |
|---|
Hardware
| Audio | Yes |
|---|---|
| Cabling | Cat 5e UTP or better |
| Daisy-Chain | No |
| Ports | 1 |
Performance
| Audio Specifications | 7.1 Surround Sound |
|---|---|
| Max Distance | 100 m / 330 ft |
| Maximum Cable Length | 328.4 ft [100.1 m] |
| Maximum Digital Resolutions | Up to 70 m: 4096 x 2160 (4K) @ 60 Hz Up to 100 m: 1080p @ 60Hz |
| Supported Resolutions | 3840x2160 (4K) @ 60 Hz 2560x1600 1920x1200 @ 60 Hz 1920x1080 (1080p) 1280x720 (720p) |
| Wide Screen Supported | Yes |
Connector(s)
| Local Unit Connectors | 1 - HDMI (19 pin) Female Input |
|---|---|
| Local Unit Connectors | 1 - RJ-45 Female Output |
| Remote Unit Connectors | 1 - RJ-45 Female Input |
| Remote Unit Connectors | 1 - HDMI (19 pin) Female Output |
Indicators
| LED Indicators | 1 - status LED (local) |
|---|---|
| LED Indicators | 1 - status LED (remote) |
Power
| Center Tip Polarity | Positive |
|---|---|
| Input Current | 0.6A |
| Input Voltage | 100 - 240 AC |
| Output Current | 1 A |
| Output Voltage | 18 DC |
| Plug Type | M |
| Power Consumption (In Watts) | 18 |
| Power Source | AC Adapter Included |
Environmental
| Humidity | 0% - 80 % RH (non-condensing) |
|---|---|
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Storage Temperature | -10°C to 60°C (14°F to 140°F) |
Physical Characteristics
| Color | Black |
|---|---|
| Enclosure Type | Aluminum |
| Product Height | 1 in [2.6 cm] |
| Product Length | 4 in [10.2 cm] |
| Product Width | 3 in [76 mm] |
| Weight of Product | 3.9 oz [110 g] |
Packaging Information
| Package Height | 2.4 in [62 mm] |
|---|---|
| Package Length | 11 in [28 cm] |
| Package Width | 8.1 in [20.6 cm] |
| Shipping (Package) Weight | 0.5 lb [0.2 kg] |
What's in the Box
| Included in Package | 1 - HDMI over CAT6 transmitter |
|---|---|
| Included in Package | 1 - HDMI over CAT6 receiver |
| Included in Package | 1 - universal power adapter (NA/JP, EU, UK, ANZ) |
| Included in Package | 1 - IR blaster |
| Included in Package | 1 - IR receiver |
| Included in Package | 2 - mounting brackets |
| Included in Package | 8 - rubber feet |
| Included in Package | 1 - quick-start guide |
| SKU | ST121HDBT20L |
| Barcode # | 65030877879 |
| Brand | STARTECH |
| Shipping Weight | 1.5700kg |
| Shipping Width | 0.100m |
| Shipping Height | 0.050m |
| Shipping Length | 0.290m |
| Shipping Cubic | 0.001450000m3 |
