Resolution-based range
4K and 1080p distances vary by cable category, with the longest stated ranges requiring Cat6a.
ATEN VE901-AT-U DisplayPort HDBaseT-Lite Extender (4K@40m; 1080p@70m) (HDBaseT Class B)
Model # VE901-AT-U
-
SKU: VE901-AT-U
- Pick Up Available
- Australian Warranty
- Checkout Securely
ATEN SKU VE901-AT-U
ATEN VE901-AT-U DisplayPort HDBaseT-Lite Extender
The ATEN VE901-AT-U extends DisplayPort video and audio over one Cat5e, Cat6 or Cat6a cable using HDBaseT Class B technology.
The structured source lists 4K up to 35m on Cat5e/6 or 40m on Cat6a and 1080p up to 60m on Cat5e/6 or 70m on Cat6a.
DisplayPort HDBaseT-Lite4K up to 40m1080p up to 70m2-year warrantyDeviceDeal authorised ATEN reseller
Product overview
DisplayPort extension
The transmitter and receiver each provide DisplayPort connectivity for compatible source and display equipment.
Installation security
A lightweight mountable design and locking DC power jacks support reliable professional installation.
Source review: The supplied narrative contains a corrupted trademark symbol, and the specification shows the video-impedance unit as a question mark. Both artifacts are excluded rather than inferred.
Frequently asked questions
How far can the VE901 extend 4K?
Up to 35m on Cat5e/6 or 40m on Cat6a is listed.
How far can it extend 1080p?
The source lists up to 60m on Cat5e/6 or 70m on Cat6a.
Which 4K timing is stated?
4096 x 2160 or 3840 x 2160 at 30Hz with 4:4:4 chroma is listed.
Does it carry audio?
Yes. DisplayPort audio input and output are included in the structured specification.
What warranty is supplied?
The source lists a two-year ATEN manufacturer warranty.
(VE901-AT-U)
Features
ATEN VE901-AT-U DisplayPort HDBaseT-Lite Extender
Video extension
- DisplayPort over HDBaseT-Lite
- 4K up to 35m on Cat5e/6
- 4K up to 40m on Cat6a
- 1080p up to 70m
Performance
- 10.2Gbps maximum data rate
- 297MHz maximum pixel clock
- DisplayPort Deep Color and 4K stated
- HDCP compatible
Installation
- Transmitter and receiver
- Locking DC power jacks
- Metal housing
- Mountable compact design
Use the specified cable category for the target resolution and distance.
Technical specifications
ATEN VE901-AT-U DisplayPort HDBaseT-Lite Extender
| Product details | |
|---|---|
| Brand | ATEN |
| Model / SKU | VE901-AT-U |
| Product type | DisplayPort HDBaseT-Lite extender |
| Units | VE901T transmitter; VE901R receiver |
| Video and audio | |
| Transmitter input | 1 x DisplayPort female, black |
| Receiver output | 1 x DisplayPort female, black |
| Maximum data rate | 10.2Gbps; 3.4Gbps per lane |
| Maximum pixel clock | 297MHz |
| 4K distance | Up to 35m on Cat5e/6; up to 40m on Cat6a |
| 1080p distance | Up to 60m on Cat5e/6; up to 70m on Cat6a |
| 4K timing | 4096 x 2160 / 3840 x 2160 at 30Hz, 4:4:4 |
| Physical and environment | |
| Housing | Metal |
| Weight | Receiver 0.27kg; transmitter 0.24kg |
| Dimensions with bracket | 9.77 x 8.70 x 3.00cm per unit |
| Dimensions without bracket | 9.42 x 6.60 x 2.90cm per unit |
| Operating temperature | 040°C |
| Storage temperature | -2060°C |
| Humidity | 080% RH, non-condensing |
| Power | |
| Connection | 1 x locking DC jack per unit |
| Consumption stated | Receiver: DC5V, 5.72W, 27BTU; transmitter: DC5V, 2.84W, 13BTU |
| SKU | VE901-AT-U |
| Barcode # | 4719264645204 |
| Brand | Aten |
| Shipping Weight | 1.0000kg |
Warranty information
ATEN VE901-AT-U DisplayPort HDBaseT-Lite Extender
2-Year ATEN Manufacturer Warranty
DeviceDeal is an authorised ATEN reseller. This product is covered by a two-year ATEN manufacturer warranty in Australia, as listed in the supplied product information.
