UPS Systems CP700EIPFCRM1U

VA
700
Watts
420
Output Voltage ( Vac )
230 ± 5%
Half Load Runtime ( min )
9.6
Outlets
IEC C13 x 6
Energy Saving Technology
Active PFC Compatible
Color LCD Panel
Hot-swappable Batteries

Overview

CyberPower CP700EIPFCRM1U with seamless Pure Sine Wave output provides complete protection for networking devices, security systems, and other electronic devices requiring active PFC power supply. Built in Automatic Voltage Regulation (AVR) function, this Line-Interactive UPS offers stabilized power output to connected devices. In addition, the UPS adopts CyberPower's patented GreenPower UPS™ technology, which greatly reduces UPS energy consumption and enhances its operating efficiency. The featured data line protection with high-speed transmission safeguards networking devices against surges and spikes while supporting data transmission speed up to 1Gbps. With short-depth chassis design, the UPS significantly optimizes space in a rack enclosure and can meet different space requirements. Besides, the UPS is designed with a color LCD panel for users to quickly confirm the status and monitor the power system. This product also allows users to perform remote management of the UPS via PowerPanel Management Software.

Features

  • Line-interactive UPS Topology
  • Active PFC Compatible
  • Automatic Voltage Regulation (AVR)
  • Critical/Non-critical Load Outlets
  • Color LCD Panel
  • USB Connectivity Port
  • PowerPanel Management Software
  • Surge and Spike Protection
  • Short-depth Chassis Design
  • Energy Saving Technology
  • Pure Sine Wave Output
  • Overload Protection
  • Hot-swappable Batteries
  • LED Status Indicator
  • High-speed Ethernet Data Transmission
  • SNMP/HTTP Remote Management Capability (Optional)
  • Network Protection

What's in the Box

  • CP700EIPFCRM1U UPS
  • Rackmount Ears
  • USB Cable

* Product contents may vary according to different regions. For detailed information, please refer to user's manual/quick start guide.

(CP700EIPFCRM1U)

Energy Saving Technology

The UPS adopts CyberPower's patented GreenPower UPS™ technology to enhance UPS operating efficiency, reduce heat generation, consume less power and save more energy costs than conventional UPS models.

Active PFC Compatible

The equipment with active power factor correction (PFC) design requires Pure Sine Wave source. The UPS provides Pure Sine Wave to meet the requirement of the equipment, enhancing system efficiency and saving electricity costs.

Automatic Voltage Regulation (AVR)

The UPS has built-in Automatic Voltage Regulation (AVR) function that keeps voltages at a safe level when incoming utility power fluctuates, thus providing consistent and reliable power to connected devices.

Color LCD Panel

The color LCD panel is designed with intuitive and graphical user-interface, allowing users to monitor power system and configure settings with ease.

Surge-protected Outlets

The UPS outlets absorb surges and spikes caused by thunder and lightning, hence providing complete protection for equipment and devices.

Data Line Protection with High-speed Transmission

The UPS provides data line protection to absorb surges and spikes, while supporting Ethernet data transmission speed up to 1Gbps for efficient data transfer.

Hot-swappable Batteries

Batteries can be safely replaced without shutting down the UPS or connected equipment, ensuring uninterrupted operation. Please read the safety precautions in the manual before battery replacement.

Short-depth Chassis Design

The UPS is designed with short-depth chassis to optimize space in a rack enclosure and meet different space requirements.

Remote Management Capability

Remote management capability enables monitoring and controlling of devices through Remote Management Card. Users can also perform management tasks, such as scheduled shutdowns and reboots. Optional Feature

PowerPanel Business Software

The PowerPanel Management Software can perform power management and system graceful shutdown. This software has achieved VMware Ready™ status, and is compatible with VMware ESXi. It also supports Citrix XenServer and Microsoft Hyper-V. Recommended Software

PowerPanel Cloud Solution

The solution offers a convenient cloud-based management which allows users to access and monitor the UPS systems through a secure web portal or mobile app anytime, anywhere. Free Trial Available

General

Form FactorRackmount
UPS TopologyLine-interactive
Energy Saving TechnologyGreenPower UPS™ Bypass Technology
Active PFC CompatibilityYes

Input

Nominal Input Voltage ( Vac )220
230
240
Input Voltage Range ( Vac )165 ~ 271
Adjustable Voltage Range ( Vac )189 ~ 207 Vac
253 ~ 271 Vac
Input Frequency ( Hz )50 ± 3
60 ± 3
Input Frequency DetectionAuto-sensing
Rated Input Current ( A )10
Input Connector TypeIEC C14
Plug StyleStraight
Detachable Power Cord Plug TypeAU x 1
IEC C14 x 4
Power Cord Length (ft.)6
Power Cord Length (m.)1.83

Output

Capacity (VA)700
Capacity (Watts)420
On Battery WaveformPure Sine Wave
On Battery Voltage(s) ( Vac )230 ± 5 % (Under a test load of＜60%. When the load＞60%, the output voltage range may＞5%.)
On Battery Frequency ( Hz )50 ± 1%
60 ± 1%
Power Factor0.6
Automatic Voltage Regulation (AVR)Single Boost
Overload ProtectionInternal Current Limiting, Circuit Breaker
Outlet(s) - Total6
Outlet TypeIEC C13 x 6
Outlet(s) - Battery & Surge Protected4
Outlet(s) - Surge-Only Protected2
Outlet(s) - Critical Load (CL)2
Outlet(s) - Non-critical Load (NCL)2
Typical Transfer Time ( ms )6 (Max 9ms at normal sensitivity)

Battery

Runtime at Half Load ( min )9.6
Runtime at Full Load ( min )2
Typical Recharge Time ( Hours )8 (Recover to 90% after full load discharge)
Start On BatteryYes
User-replaceableYes
Hot-swappableYes
Battery Cartridge (RBP)RBP0019
Battery Cartridge (RBP) Quantity ( pcs )1

Surge Protection & Filtering

Surge Suppression ( Joules )450
Network Protection RJ451-in, 1-out

Management & Communications

LCD PanelYes
LCD TypesColor LCD
LCD Information DisplayPower Status, Battery Status, Load Status, Fault & Warning
LCD Setting & ControlAlarm Setting, Input & Output, Battery Setting
LED IndicatorsPower On
HID Compliant USB Port(s)1
Serial PortContact Signals
Audible AlarmsBattery Mode, Low Battery, Overload, UPS Fault
Management Cable ( pcs )USB Cable x1
Ethernet Data Transmission SpeedUp to 1Gbps
Power Management SoftwarePowerPanel Business (Recommended)
SNMP/HTTP Remote MonitoringYes - with optional RMCARD205
PowerPanel Cloud ServiceYes - 90 Days Free Trial with PowerPanel Personal/Business

Physical

Enclosure ConstructionMetal
ColorSilver
Rackmount EarsYes

Physical Size - UPS Module

Dimensions (WxHxD) (in.)17.05 x 1.73 x 9.04
Dimensions (WxHxD) (mm.)433 x 44 x 229.7
Weight (lbs.)18.3
Weight (kg.)8.3
Installed Rack Height ( U )1

Shipping Dimensions

Dimensions (WxHxD) (in.)20.87 x 6.1 x 11.02
Dimensions (WxHxD) (mm.)530 x 155 x 280
Weight (lbs.)19.86
Weight (kg.)9.02

Environmental

Operating Temperature (°F)32 ~ 104
Operating Temperature (°C)0 ~ 40
Operating Relative Humidity (Non-condensing) ( % )0 ~ 95
Operating Elevation ( feet/meters )0-9,843 feet (0-3,000 meters)
Storage Temperature (°F)5 ~ 113
Storage Temperature (°C)-5 ~ 45
Storage Relative Humidity (Non-condensing) ( % )0 ~ 95
Storage Elevation ( feet/meters )0-49,213 feet (0-15,000 meters)
Online Thermal Dissipation ( BTU/hr )17

Certifications

CertificationsCE, RCM
RoHSYes
SKU CP700EIPFCRM1U
Brand CYBERPOWER
Shipping Weight 9.0000kg

Manufacturer Warranty
