The KA7183 KVM Adapter empowers any Cat 5 KVM switch* to connect to and manage a USB-C compatible target computer. Via just a single USB-C plug, it is able to connect a target computer while fulfilling keyboard, video, mouse, and virtual media or smart card / CAC reader functions.

Advanced features provided by KA7183 include superior signal compensation and delay skew technologies for greatly enhanced video quality, as well as its user-friendly, compact and lightweight design.

*Please refer to the KVM Adapter Cable Compatibility List (https://www.aten.com/global/en/products/kvmtool/kacablecompatibility/) for details.

Package Contents

1x KA7183 USB-C Virtual Media KVM Adapter
1x USB holder kit
1x user instructions

(KA7183-AX)

Connectors
Link	1 x RJ-45 Female
Computer	1 x USB Type C Male
LEDs
Link	1 (Green)
Power	1 (Orange)
Power Consumption	DC5V:2.61W:12BTU
Environmental
Operating Temperature	0-50°C
Storage Temperature	-20–60°C
Physical Properties
Housing	Plastic
Weight	0.07 kg ( 0.15 lb )
Dimensions (L x W x H)	9.10 x 5.60 x 2.12 cm (3.58 x 2.2 x 0.83 in.)
Note	For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.
