StarTech HDMI KVM Extender over LAN, 4K 30Hz - SV565HDIP
Model # SV565HDIP
-
SKU: SV565HDIP
Stock Availability
🟢Live
Allow 1–2 business days for stock transfer
- Pick Up Available
- Australian Warranty
- Checkout Securely
StarTech SV565HDIP 4K30 HDMI KVM Extender over LAN
Extend HDMI video, USB control and audio over an IP-enabled local area network, or directly over Cat5e/Cat6 up to 100 m, with support for 4K 30Hz video.
Key features
4K 30Hz HDMI
The extender supports digital resolutions up to 3840 × 2160 at 30Hz.
LAN or point-to-point operation
Use an IP-enabled LAN or a direct Cat5e/Cat6 connection between transmitter and receiver.
Up to 100 m direct cabling
A direct transmitter-to-receiver Cat5e/Cat6 link can span up to 100 m (328 ft).
USB peripheral support
Four USB ports allow keyboard, mouse and additional USB devices at the remote workstation.
What to know
Australian version and official StarTech.com warranty
This is the Australian version supplied by DeviceDeal and is covered by the official StarTech.com 2-year manufacturer warranty in Australia. Retain your DeviceDeal tax invoice as proof of purchase. Warranty coverage and claims are subject to StarTech.com warranty terms, eligibility requirements and product assessment.
Frequently asked questions
What does the StarTech SV565HDIP do?
What is the maximum HDMI resolution?
How far can a direct cable connection run?
How many USB ports are available remotely?
Does it support audio?
Can I add more receivers?
What is included in the kit?
What warranty applies in Australia?
(SV565HDIP)
Features and highlights
4K 30Hz HDMI
The extender supports digital resolutions up to 3840 × 2160 at 30Hz.
LAN or point-to-point operation
Use an IP-enabled LAN or a direct Cat5e/Cat6 connection between transmitter and receiver.
Up to 100 m direct cabling
A direct transmitter-to-receiver Cat5e/Cat6 link can span up to 100 m (328 ft).
USB peripheral support
Four USB ports allow keyboard, mouse and additional USB devices at the remote workstation.
Audio and microphone connectivity
HDMI 7.1 audio plus analogue stereo audio and mono microphone support are listed.
Expandable display configurations
Additional receivers can be used for multi-display distribution or supported video-wall configurations.
Key highlights
- 4K 30Hz
- 100 m direct link
- 4 USB ports
- 2-year warranty
Warranty confidence
Official StarTech.com 2-year manufacturer warranty in Australia for this Australian-version product, subject to StarTech.com terms and assessment.
Specifications
StarTech SV565HDIP
General
| Warranty | 2 Years |
|---|
General
| Cables Included | Yes |
|---|---|
| DVI Support | Yes |
| Hot-Key Selection | No |
| IP Control | No |
| KVM Ports | 1 |
| Max Transfer Distance | 100 m (328 ft) |
| Number of Monitors Supported | 1 |
| On-Screen Display | Yes |
| PC Interface | USB |
| PC Video Type | HDMI |
Connector(s)
| Local Unit Connectors | 3.5 mm Audio Female 3.5 mm Mini-Jack (3 Position) Female HDMI (19 pin) RJ-11 Female RJ-45 USB Mini-B (5 pin) Female |
|---|---|
| Remote Unit Connectors | 3.5 mm Audio Female 3.5 mm Mini-Jack (3 Position) Female HDMI (19 pin) RJ-11 Female RJ-45 USB Type-A (4 pin) USB 2.0 Female USB Type-A (4 pin; HID Port) USB 1.1 Female |
Environmental
| Humidity | 0% to 80% |
|---|---|
| Operating Temperature | 0? to 40? (32°F to 104°F) |
| Storage Temperature | -10? to 60? (14°F to 140°F) |
Hardware
| Audio | Yes |
|---|---|
| Chipset ID | ASPEED - AST1520 |
| Daisy-Chain | No |
Indicators
| LED Indicators | Receiver: Flashing Orange - Network connection Receiver: Red - No Link; Blue - Good Link; Flashing Blue/Red - Linked but no video Transmitter: Flashing Orange - Network connection Transmitter: Green - No Link; Blue - Good Link; Flashing Blue/Green - Linked but no video |
|---|
Packaging Information
| Package Height | 23.5 cm [9.3 in] |
|---|---|
| Package Length | 19.5 cm [7.7 in] |
| Package Width | 36.5 cm [14.4 in] |
| Shipping (Package) Weight | 0.1 kg [0.2 lb] |
Performance
| Audio Specifications | 7.1 Surround Sound (HDMI) Analog Stereo Sound (3.5 mm) Analog Mono Microphone (3.5 mm) |
|---|---|
| Maximum Cable Length | 100 m [328 ft] |
| Maximum Data Transfer Rate | 12MBps |
| Maximum Digital Resolutions | 3840 x 2160 @ 30Hz (4K) |
| MTBF | 60000 hours |
| Supported Resolutions | 3840x2160 (4K) @ 30Hz 2560x1600 1920x1200 @ 60Hz 1920x1080 (1080p) 1280x720 (720p) |
| Wide Screen Supported | Yes |
Physical Characteristics
| Color | Black |
|---|---|
| Enclosure Type | Steel |
| Product Height | 2.8 cm [1.1 in] |
| Product Length | 13 cm [5.1 in] |
| Product Width | 11.7 cm [4.6 in] |
| Weight of Product | 610 g [21.5 oz] |
Power
| Center Tip Polarity | Positive |
|---|---|
| Input Current | 0.6 A |
| Input Voltage | 100 - 240 AC |
| Output Current | 1.5A |
| Output Voltage | 12 DC |
| Plug Type | M |
| Power Consumption (In Watts) | 18W |
| Power Source | 2 AC Adapters Included |
What's in the Box
| Included in Package | DB9 Serial Adapters Ethernet Cables HDMI Cable (1.2 m) Mounting Kits Plastic Screwdriver Quick-Start Guide Receiver Unit RJ11 Serial Cables Rubber Feet Transmitter Unit Universal Power Adapters (NA, JP, EU, UK, AU/NZ) USB Cable (1.5 m) |
|---|
| SKU | SV565HDIP |
| Barcode # | 65030877947 |
| Brand | Startech |
| Shipping Weight | 2.4500kg |
| Shipping Width | 0.230m |
| Shipping Height | 0.080m |
| Shipping Length | 0.365m |
| Shipping Cubic | 0.006716000m3 |
2-year official StarTech.com manufacturer warranty
This item is the Australian version supplied by DeviceDeal and is covered by the official StarTech.com 2-year manufacturer warranty in Australia.
Please retain your DeviceDeal tax invoice as proof of purchase.
Warranty coverage and claims are subject to StarTech.com warranty terms, eligibility requirements and product assessment.
