MIKROTIK SXT LTE6 kit with RouterOS L3 license RBSXTR&R11e-LTE6
Model# RBSXTR&R11e-LTE6
-
SKU: RBSXTR-R11e-LTE6
- Pick Up Available
- Australian Warranty
- Checkout Securely
Integrated outdoor LTE client device for cellular network connectivity This is the ORIGINAL model of SXT-LTE6 (2023) - Looking for the new (2023) version? NOTE: This product ships with RouterOSv7 installed and can NOT be downgraded to run routerOSv6. SXT LTE6 kit is a device for remote locations that are within cellular network coverage. Due to its advanced LTE chip design and high gain antenna, it can provide connectivity for your building even where cell phones fail. The new SXT LTE6 features a CAT6 LTE modem, which enables carrier aggregation and allows the device to use multiple bands at the same time. A huge advantage when there are a lot of LTE users in the area. It provides better responsiveness in a crowded environment and higher efficiency for weaker signal situations in the countryside. We have seen Internet speed doubling in rural areas after switching to CAT6, so there is no need to wait for cable network expansions. The unit is equipped with two Ethernet ports (the second port has PoE-out functionality), so you can use it to power up another device. It also has two Micro SIM slots for backup link. Unit is shipped with a 24 V power supply, but can support full range 18-57 V and is 802.3af/at compliant. Brochure You might also consider the NanoBracket: swivel mounting kit for RB/SXT
(RBSXTR-R11e-LTE6)
Specifications Product code RBSXTR&R11e-LTE6 Architecture MIPSBE CPU QCA9531 CPU core count 1 CPU nominal frequency 650 MHz Switch chip model QCA9531 RouterOS license 3 Operating System RouterOS Size of RAM 64 MB Storage size 16 MB Storage type FLASH MTBF Approximately 200'000 hours at 25C Tested ambient temperature -30°C to 60°C Powering Number of DC inputs 1 (PoE-IN) Max power consumption 21 W Max power consumption without attachments 7 W Cooling type Passive PoE in 802.3af/at PoE in input Voltage 12-57 V Ethernet 10/100 Ethernet ports 2 Peripherals Number of SIM slots 2 Modem (Micro SIM) MiniPCI-e slots 1 Certification & Approvals Certification CE, EAC, ROHS IP IP54 Mobile 2G Category Class12 2G bands 2 (1900MHz) / 3 (1800MHz) / 5 (850MHz) / 8 (900MHz) 3G Category R7 (21Mbps Downlinks, 5.76Mbps Uplink) / R8 (42.2Mbps Downlink, 5.76Mbps Uplink) 3G bands 1 (2100MHz) / 2 (1900MHz) / 5 (850MHz) / 8 (900MHz) LTE Category 6 (300Mbit/s Downlink, 50Mbit/s Uplink) LTE FDD bands 1 (2100MHz) / 2 (1900MHz) / 3 (1800MHz) / 7 (2600MHz) / 8 (900 MHz) / 20 (800MHz) / 5 (850MHz) / 12 (700MHz) / 17 (700MHz) / 25 (1900MHz) / 26 (850MHz) LTE TDD bands 38 (2600MHz) / 40 (2300MHz) / 39 (1900MHz) / 41n (2500MHz) TAC 35666210 PoE-out PoE-out ports Ether2 PoE out Passive PoE up to 57V Max out per port output (input 18-30 V) 600 mA Max out per port output (input 30-57 V) 400 mA Max total out (A) 600 mA Other Mode button Yes
| SKU | RBSXTR-R11e-LTE6 |
| Brand | MIKROTIK |
| Shipping Weight | 3.3000kg |
Manufacturer Warranty
