ATEN VE601T-AT-U DVI HDBaseT-Lite Transmitter (1080p@70m) (HDBaseT Class B)
Model # VE601T-AT-U
-
SKU: VE601T-AT-U
- Pick Up Available
- Australian Warranty
- Checkout Securely
The VE601T DVI HDBaseT-Lite Extender is able to extend a DVI 1080p display up to 70 m using an Ethernet cable. This combination of ATEN and HDBaseT technology even supports sharing 1920 x 1200 media up to 40 m away, offering a simple, adaptable, and cost-effective solution for any professional A/V installation.
The VE601 DVI HDBaseT-Lite Extender is the perfect solution for professional A/V installations that require video signal interference protection, such as in medical and military installations. With its lightweight and easy-to-mount design, not to mention slip-resistant DC Jack lock mechanism, the VE601 can be installed nearly anywhere while ensuring peace of mind with its unerring reliability.
* Compatible HDBaseT Receiver Units: VE601R, VE801R
Package Contents
- 1x VE601T DVI HDBaseT-Lite Transmitter
- 1x Power Adapters
- 1x User Instructions
(VE601T-AT-U)
| Video Input | |
| Interfaces | 1 x DVI-D Female (White) |
| Impedance | 100? |
| Max. Distance | Up to 1.8m |
| Video | |
| Max. Pixel Clock | 340 MHz |
| Max. Data Rate | 10.2Gbps (3.4Gbps per lane) |
| Compliance | DVI (3D, Deep Color) HDCP compatible |
| Max. Resolutions / Distance | Up to 1920x1200@35 m (Cat 5e/6) / 40 m (Cat 6a/ATEN 2L-2910 Cat6); 1080p@60 m (Cat 5e/6) / 70 m (Cat 6a/ATEN 2L-2910 Cat6) |
| Connectors | |
| Power | 1 x DC Jack with locking |
| Unit To Unit | 1 x RJ-45 Female |
| Power Consumption | DC5V:1.84W:9BTU |
| Environmental | |
| Storage Temperature | -20 - 60°C |
| Operating Temperature | 0-50°C |
| Humidity | 0% - 80% RH, Non-condensing |
| Physical Properties | |
| Housing | Metal |
| Weight | 0.25 kg ( 0.55 lb ) |
| Dimensions (L x W x H) with bracket | 10.20 x 8.70 x 3.00 cm (4.02 x 3.43 x 1.18 in.) |
| Dimensions (L x W x H) without bracket | 9.42 x 6.60 x 2.90 cm (3.71 x 2.6 x 1.14 in.) |
| SKU | VE601T-AT-U |
| Brand | ATEN |
| Shipping Weight | 0.2500kg |
