Camera Image Sensor 1/1.8” 4Megapixel progressive scan CMOS Effective Pixels 2688 (H) × 1520 (V) RAM/ROM 512 MB/128 MB Scanning System Progressive Electronic Shutter Speed Auto/Manual, 1/3 s–1/100000 s Minimum Illumination 0.002 Lux@F1.6 IR Distance Distance up to 50 m (164 ft) IR On/Off Control Auto/Manual IR LEDs 2 Lens Lens Type Fixed-focal Mount Type Board-in Focal Length 2.8 mm, 3.6 mm, 6.0 mm Max. Aperture F1.6 Angle of View H: 113°, V: 60°/H: 89°, V: 48°/H: 56°, V: 31° Aperture Type Fixed Close Focus Distance 1.3 m (4.27 ft)/1.9 m (6.23 ft)/3.8 m (12.47 ft) DORI Distance Lens Detect Observe Recognize Identify 2.8mm 58m(190ft) 23m(75ft) 12m(39ft) 6m(20ft) 3.6mm 72m(236ft) 29m(95ft) 14m(46ft) 7m(23ft) 6.0mm 113m(371ft) 45m(148ft) 23m(75ft) 11m(36ft) Pan/Tilt/Rotation Pan/Tilt/Rotation Range Pan: 0?–360?; Tilt: 0?–78?; Rotation: 0?–360? Artificial Intelligence Face Detection Support face image capture Perimeter Protection Tripwire, intrusion (Recognition of vehicle and people), fast moving, loitering detection, parking detection and people gathering People Counting Support Line crossing/Region/Queueing people counting; Support 4 accesses independent detection, 4 areas independent detection General Intelligence Event Trigger Motion detection, Video tampering , Scene changing, Network disconnection , IP address conflict, Illegal Access, Storage anomaly General Intelligence Object Abandoned/Missing Heat Map Yes Video Compression H.265,H.264,H.264B,H.264H, MJPEG (sub stream) Smart Codec Yes Streaming Capability 3 Streams Resolution 2688 × 1520/2560 × 1440/2304 × 1296/1080P (1920 × 1080)/1.3M (1280 × 960)/720P (1280 × 720)/D1 (704 × 576/704 × 480)/VGA (640 × 480)/CIF (352 × 288/352 × 240) Frame Rate Main Stream: 2688 × 1520 (1 fps–25/30 fps) 2560 × 1440 (1 fps–25/30 fps) 1920 × 1080 (1 fps–50/60 fps) Sub Stream: D1 (1 fps–25/30 fps) D1 (1 fps–50/60 fps) Third Stream: 1080P (1 fps–16 fps) Bit Rate Control CBR/VBR Bit Rate H.264: 32 Kbps–8192 Kbps H.265: 19 Kbps–8192 Kbps Day/Night Auto(ICR)/Color/B/W BLC Mode BLC/HLC/WDR (140 dB) White Balance Auto/Natural/Street Lamp/Outdoor/Manual Gain Control Auto/Manual Noise Reduction 3D DNR Motion Detection Off/On (4 Zone, Rectangle) Region of Interest Off/On (4 Zone) Electronic Image Stabilization (EIS) N/A Smart IR Yes Defog Yes Flip 0°/90°/180°/270° Mirror Off/On Privacy Masking Off/On (4 Area, Rectangle) Audio Compression G.711a, G.711Mu, G.726, AAC, G.723 Network Ethernet RJ-45 (10/100 Base-T) Protocol IPv4;IPv6;HTTP;HTTPS;TCP;UDP;ARP;RTP;RTSP;RTCP;RTMP;SMTP;FTP;SFTP;DHCP;DNS;DDNS;QoS;UPnP;NTP;Multicast;ICMP;IGMP;NFS;PPPoE;802.1x;SNMP Interoperability ONVIF (Profile S/Profile G/Profile T), CGI, Milstone, Genetec, P2P Streaming Method Unicast / Multicast Max. User Access 20 Users Edge Storage NAS;FTP;SFTP Micro SD card 256 GB Web Viewer IE (versions newer than IE8), Chrome, Firefox, Safari (versions newer than Safari 12) Management Software Smart PSS, DSS, DMSS Smart Phone iOS, Android Certifications Certifications CE-LVD: EN60950-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU FCC: 47 CFR FCC Part 15, Subpart B UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07 Interface Audio Interface Built-in MIC RS485 N/A Alarm N/A Electrical Power Supply DC 12V (±30%), PoE (802.3af) (Class 0) Power Consumption <7.2W Environmental Operating Conditions -30° C to +60° C (-22° F to +140° F)/Less than 95% RH Storage Conditions -30° C to +60° C (-22° F to +140° F) Ingress Protection IP67 Construction Casing Metal Dimensions ?106 mm × 99.2 mm (4.17” × 3.91”) Net Weight 0.55 kg (1.21 lb) Gross Weight 0.71 kg (1.57 lb)
