Camera Image Sensor 1/2.7” 5Megapixel progressive CMOS Effective Pixels 2592(H) x1944(V) RAM/ROM 512MB/32MB Scanning System Progressive Electronic Shutter Speed Auto/Manual, 1/3~1/100000s Minimum Illumination 0.02Lux/F1.6( Color,1/3s,30IRE) 0.2Lux/F1.6( Color,1/30s,30IRE) 0Lux/F1.6(IR on) S/N Ratio More than 50dB IR Distance Distance up to 60m(197ft) IR On/Off Control Auto/ Manual IR LEDs 4 Lens Lens Type Motorized(-ZS),Manual(-VFS) Mount Type Board-in Focal Length 2.7mm~13.5mm Max. Aperture F1.4 Angle of View H:95°~27°, V:70°~20° Focus Control Motorized(-ZS),Manual(-VFS) Close Focus Distance 0.3m DORI Distance Lens Detect Observe Recognize Identify W 64m(210t) 26m(85ft) 13m(43ft) 6m(20ft) T 222m(728ft) 89m(292ft) 44m(144ft) 22m(72ft) PTZ Pan/Tilt Range Pan:0° ~360° ;Tilt:0° ~90° ;Rotation:0° ~360° Intelligence Event Trigger Motion detection, Video tampering , Scene changing , Network disconnection , IP address conflict, Illegal Access,Storage anomaly IVS Tripwire, Intrusion Video Compression H.265/H.264H/MJPEG(Sub Stream) Smart Codec Support H.265+/H.264+ Streaming Capability 2 Streams Resolution 5M(2592×1944)/4M(2688x1520)/3M(2304×1296/2 048x1536)/1080P(1920×1080)/720P(1280×720)/ D1(704×576/704×480)/VGA(640×480)/ CIF(352×288/352×240) Frame Rate Main Stream: 5M (1 ~ 15fps)/3M(1 ~ 25/30fps) Sub Stream: D1/CIF(1 ~ 25/30fps) Bit Rate Control CBR/VBR Bit Rate H.265: 12K ~ 8448Kbps H.264: 32K ~ 10240Kbps Day/Night Auto(ICR) / Color / B/W BLC Mode BLC / HLC / WDR(120dB) White Balance Auto/Natural/Street Lamp/Outdoor/Manual Gain Control Auto/Manual Noise Reduction 3D DNR Motion Detection Off / On (4 Zone, Rectangle) Region of Interest Off / On (4 Zone) Electronic Image Stabilization(EIS) N/A Smart IR Support Digital Zoom 16x Flip 0°/90°/180°/270° Mirror Off / On Privacy Masking Off / On (4 Area, Rectangle) Audio Compression G.711a/ G.711Mu/ AAC/ G.726 Network Ethernet RJ-45 (10/100Base-T) Protocol HTTP;HTTPS;TCP;ARP;RTSP;RTP;RTCP;UDP;SMTP; FTP;DHCP;DNS;DDNS;PPPoE;IPV4/V6;QoS;UPnP; NTP;Bonjour;IEEE 802.1X;Multicast;ICMP;IGMP;TLS Interoperability ONVIF Profile S&G, API Streaming Method Unicast / Multicast Max. User Access 10 Users / 20 Users Edge Storage NAS Local PC for instant recording Micro SD Card 128GB Web Viewer IE, Chrome, Firefox, Safari Management Software Smart PSS, DSS, DMSS Smart Phone IOS, Android Certifications Certifications CE (EN 60950:2000) UL:UL60950-1 FCC: FCC Part 15 Subpart B Interface Video Interface N/A Audio Interface N/A RS485 N/A Alarm N/A Electrical Power Supply DC12V,PoE+ (IEEE 802.3at)(Class 4) Power Consumption <15W(-ZS), <13W(-VFS) Environmental Operating Conditions -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH Storage Conditions -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH Ingress Protection IP67 Vandal Resistance N/A Construction Casing Metal Dimensions 244.1mm×79mm×75.9mm (9.61”×3.11”×2.99”) Net Weight 0.815kg (1.80lb) Gross Weight 1.08kg (2.38lb)
