Camera Image Sensor 1/2.8" CMOS Pixel 4MP Max. Resolution 2560 (H) × 1440 (V) ROM 4GB RAM 1GB Electronic Shutter Speed 1/1 s–1/30000 s Scanning System Progressive Min. Illumination Color: 0.005Lux@F1.6 B/W: 0.0005Lux@F1.6 0Lux (IR light on) Illumination Distance 550 m (1804.46 ft) Illuminator On/Off Control Zoom Prio/Manual/SmartIR/Off Illuminator Number 2 IR lights 1 Laser Wiper Support Lens Focal Length 3.95 mm–177.7 mm Max. Aperture F1.6–F4.9 Field of View H: 70.3°–1.8°; V: 37°–1°; D: 69.3°–2° Optical Zoom 45x Focus Control Auto/Semi-Auto/Manual Close Focus Distance 0.01 m–3 m (0.03 ft–9.84 ft) Iris Control Auto DORI Distance Detect Observe Recognize Identify 3554 m (11660.10 ft) 1421.6 m (4664.04 ft) 710.8 m (2332.02 ft) 355.4 m (1166.01 ft) PTZ Pan/Tilt Range Pan: 0°–360° endless Tilt: –20°–+90°, auto flip 180° Manual Control Speed Pan: 0.1°–200°/s Tilt: 0.1°–120°/s Preset Speed Pan: 240°/s; Tilt: 200°/s Presets 300 Tour 8 (up to 32 presets per tour) Pattern 5 Scan 5 Power-off Memory Support Idle Motion Preset/Tour/Pattern/Scanning Protocol DH-SD Pelco-P/D (auto recognition) General Intelligence Event Trigger Motion detection, video tampering, scene changing, network disconnection, IP address conflict, illegal access, and storage anomaly IVS Object abandoned/missing Artificial Intelligence Smart Capture Support human, motor vehicle and non-motor vehicle image capture. Perimeter Protection Tripwire and intrusion. Support alarm triggering by target types (human and vehicle). Support filtering false alarms caused by animals, rustling leaves, bright lights, etc. Face Detection Support SMD PLUS Support Auto Tracking Support Video Compression H.265; H.264B; H.264M; H.264H; MJPEG; MPEG4; H.265+; H.264+; MJPEG (sub stream) Streaming Capability 3 streams Resolution 4M (2560 × 1440); 3M (2048 × 1536); 1080P (1920 × 1080); 720P (1280 × 960); D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240) Frame Rate Main stream: 4M/3M (1–25/30 fps), 1080P/1.3M/720P (1–25/30 fps) Sub stream 1: D1/CIF (1–25/30 fps) Sub stream 2: 1080P (1–25/30 fps), 720P (1–25/30 fps) Bit Rate Control Variable/Constant Bit Rate Main stream with default resolution: H.264: 3 Kbps–20480 Kbps H.265: 3 Kbps–20480 Kbps Day/Night Auto (ICR)/Color/B/W BLC Support WDR 120dB HLC Support White Balance Auto/Indoor/Outdoor/Tracking/Manual/Sodium lamp/Natural light/Street lamp Gain Control Auto/Manual Noise Reduction 2D/3D Motion Detection Support Region of Interest (RoI) Support Image Stabilization Electronic Defog Digital Digital Zoom 16x Flip 180° Privacy Masking Up to 24 areas, and up to 8 areas in the same view Audio Compression G.711a; G.711Mu; G.726; AAC; MPEG2-Layer2; G.722.1; G.729; G.723 Network Ethernet RJ-45 (10/100Base-T) Protocol IPv4; IPv6; HTTP; HTTPS; 802.1x; Qos; FTP; SMTP; UPnP; SNMPv1/v2c/v3 (MIB-2); DNS; DDNS; NTP; RTSP; RTP; TCP; UDP; IGMP; ICMP; DHCP; PPPoE; ARP; RTCP Interoperability ONVIF Profile S&G&T; CGI Streaming Method Unicast/Multicast User/Host 19 Storage FTP; Micro SD card (256G); P2P Browser IE7 and later versions Chrome 42 and earlier versions Firefox 52 and earlier versions Safari Management Software Smart PSS; DSS; DMSS; Easy4ip; IVSS Mobile Phone IOS; Android Certification Certifications CE: EN62368-1; EN55032; EN61000-3-2; EN61000-3-3; EN55024; EN55035; EN50130-4 FCC: 47 CFR FCC Part15, SubpartB, ClassA; ANSI C63.4: 2014 Port RS-485 1 (Baud rate range: 1200 bps–115200 bps) Audio Input 1 Audio Output 1 Alarm I/O 7/2 Power Power Supply DC36V/2.23A; HI-PoE Power Consumption Basic: 20W Max.: 36W (IR light and PTZ on at minimum voltage) Environment Operating Temperature –40°C ~ 70°C (-40°F to 158°F) Operating Humidity ?95% Protection IP67; TVS 8000V lightning proof; Surge protection Structure Casing Metal Dimensions 382 mm × ?240 mm (15.04" x ?9.45") Net Weight 6.8 kg (14.99 lb) Gross Weight 9.2 kg (20.28 lb)
