System Main Processor Industrial embedded micro-processor Operating System Embedded Linux Operation Interface Web; local GUI Perimeter Protection by Camera Performance 16/20/20 channels AI Search Search for pictures by channel, time and event type Face Recognition by Camera Performance 14 channels Face Attributes 6 attributes: Gender; age; glasses; expression; mouth mask; beard AI Search Search for pictures by channel, time and face attributes SMD Plus by Camera Performance 16/32/64 channels AI Search Search by target classification (human, vehicle) Video Metadata by Camera Performance 16 channels Human Body Top; top color; bottom; bottom color; hat; bag; gender; age; umbrella Vehicle Plate No.; type; color; vehicle type; logo; plate color; ornament; calling; seatbelt; region Non-motor Vehicle Type; color; number of passengers; helmet AI Search Supports searching for target video by metadata ANPR by Camera Performance 4 channels Stereo Analysis by Camera Performance 16 channels AI Search Search by target classification (fall detection; people approach detection; people No. exception detection; people staying detection; violence detection) Video Access Channel 16/32/64 Network Bandwidth 320 Mbps for access, 320 Mbps for storage and 320 Mbps for forwarding Resolution 12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080p, 1.3MP, 720p, D1, and more Decoding Capability 16-channel@1080P (30 fps) Video Output HDMI1: 3840 × 2160; 1920 × 1080; 1280 × 1024; 1280 × 720 VGA1: 1920 × 1080; 1280 × 1024; 1280 × 720 HDMI2/VGA2: 1920 × 1080 VGA1/HMDI1 homologous output, VGA2/HDMI2 homologous output, and VGA1/HDMI1 and VGA2/HDMI2 supports heterogeneous output Multi-screen Display 1st Screen: 16-channel: 1/4/8/9/16 32-channel: 1/4/8/9/16/25/36 64-channel: 1/4/8/9/16/25/36/64 2nd screen: 1/4/8/9/16 Third Party Camera Access Panasonic, Sony, Samsung, Axis, Pelco, Arecont, ONVIF, Canon and more Compression Video Smart H.265+; Smart H.264+; H.265; H.264; MJPEG Audio PCM; G.711A; G.711U; G.726 Network Network Protocol HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; SNMP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; PPPoE; DDNS; FTP; Alarm Server; IP Search (Supports Dahua IP camera, DVR, NVS, and more.) ; P2P Mobile Phone Access Android; iOS Interoperability ONVIF (profile T/S/G); CGI; SDK Browser Chrome; IE9 or later; Firefox Record Playback Multi-channel Playback 1/4/9/16 Record Mode Manual; schedule (general; MD; alarm; MD & alarm; intelligent; POS) Storage Method Local HDD and network Backup USB device Playback Function 1. Play; pause; stop; fast forward; fast backward; rewind; play by frame 2. Full screen; backup (cut/file) ; partially enlarge; audio on/off Storage Disk Group Yes Alarm General Alarm Motion detection; privacy masking; video loss; local alarm; PIR alarm; IPC alarm Anomaly Alarm Camera offline; storage error; full storage; IP conflict; MAC conflict; login lock; network security anomaly Intelligent Alarm Perimeter protection; face detection; face recognition; SMD; video metadata (human; motor-vehicle; non-motor vehicle) ; ANPR; people counting; stereo analysis; crowd distribution; heat map Alarm Linkage Record; snapshot; IPC external alarm output; buzzer; log; preset; email External Port Audio Input 1 channel, RCA connector Audio Output 2 channels, RCA connector, which supports voice intercom output HDD 4 SATA III ports, up to 10 TB for a single HDD. The maximum HDD capacity varies with environment temperature Alarm Input 16 channels Alarm Output 6 channels eSATA 1 eSATA RS-232 1 channel, used to debug and pass through serial data RS-485 1 channel, used to control PTZ, and it supports multiple protocols USB 1 front USB 2.0 port, 2 rear USB 3.0 ports HDMI 2 VGA 2 Network 1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet port PoE 16 ports (IEEE802.3af/at) 1-8 ports support ePoE & EoC General Parameter Power Supply Single, 100V–240V AC, 50 Hz–60 Hz Power Consumption NVR: < 17.5W (without HDD) PoE: Max 25.5W for single port 150W total rated power, 80% control for protection Net Weight 4.65 kg (10.3 lb) (without HDD) Gross Weight 7 kg (15.4 lb) (without HDD) Product Dimensions 440 mm × 412.2 mm × 76.0 mm (17.3" × 16.2" × 3.0") Package Dimensions 522 mm × 492 mm × 200 mm (20.6" × 19.4" × 7.9") Operating Temperature -10°C to +55°C (+14°F to +131°F) Storage Temperature 0°C to +40°C (+32°F to +104°F) Operating Humidity 10%–93% (RH) Storage Humidity 30%–85% (RH) Operating Altitude 3,000 m (9,843 ft) Certifications CE: EN55032; EN55024; EN50130-4; EN60950-1 FCC: Part 15 Subpart B; ANSI C63.4-2014 UL: UL 60950-1
